9.8.1

Viewing historical logs

To view a historical log, complete the following steps
1. Press MENU.
2. Press the UP or DOWN keys until the control unit displays the following:
<ENTER>=Accept
Menu: [History Logs]
3. Press ENTER and the control unit displays the following:
<ENTER>=Accept
Log: [ALOG]
Use the UP or DOWN keys to choose one of the logs:
4.
- ALOG
- Supervisory Log
- TLOG
- User Log
- CLOG
5. Press ENTER to access the contents of the log.
6. Use the UP or DOWN keys to scroll through each log entry.
9.8.2

Clearing logs

To clear a log, complete the following steps:
1. Press ENTER to clear the log you are currently viewing. The control unit displays the following:
<ENTER>=Clear Log
<EXIT> to cancel
Press ENTER to clear the current log.
2.
The control unit adds an entry to the log to indicate that it is cleared.
9.9

Viewing and controlling points

You can view each point in the system for the following reasons:
• Obtain additional information
• Control an operation
• Enable an operation
• Disable an operation
You can view points at access level 1, but only an operator with a level 2 login or higher can control and disable or enable operations.
9.9.1

Viewing points

To view a point, complete the following steps:
1. Press MENU.
2. Press the UP or DOWN keys until the control unit displays the following:
<ENTER>=Accept
Menu: [Control/View]
3. Press ENTER and the control unit displays the following:
<ENTER>=Accept
Ctrl/View: [IDC]
