4090-9116 Addressable IDNet Isolator
READ AND SAVE THESE INSTRUCTIONS - Follow the instructions in this
Installation manual. These instructions must be followed to avoid damage to this product
and associated equipment. Product operation and reliability depend upon proper
installation.
DO NOT INSTALL ANY SIMPLEX
Upon unpacking your Simplex product, inspect the contents of the carton for shipping
damage. If damage is apparent, immediately file a claim with the carrier and notify an
authorized Simplex product supplier.
ELECTRICAL HAZARD - Disconnect electrical field power when making any internal
adjustments or repairs. All repairs should be performed by a representative or authorized
agent of your local Simplex product supplier.
STATIC HAZARD - Static electricity can damage components. Handle as follows:
Ground yourself before opening or installing components.
Prior to installation, keep components wrapped in anti-static material at all times.
The 4090-9116 IDNet Isolator is a line powered addressable device that provides short
circuit protection on an IDNet channel. When a short is detected on the IDNet channel,
an IDNet Isolator connected between the 4100ES, 4100U, 4010ES, or 4008 Fire Alarm
Control Panel (FACP) and the short shall automatically open the IDNet channel. The
FACP is able to command the Isolator to open or close the lines, which enables the FACP
to locate earths or shorts on the IDNet channel. The IDNet channel provides the
communication link between Addressable IDNet Isolator and FACP and powers the
circuit.
The in and out IDNet wiring (Style 6) must be wired through the 4090-9116 IDNet
Isolator to provide segregation between fire and non-fire alarm devices in the following
non-fire applications:
A 4090-9001 or -9051 Supervised IAM is configured for monitoring single-station
smoke detectors
A 4090-9121 Security IAM is connected to the same IDNet channel as other IDNet
loop devices
When the IDNet channel is wired Style 4, the non-fire IAM(s) must be wired as the last
devices on the loop and the input to the first non-fire IAM must be wired through a 4090-
9116 IDNet Isolator.
The range of possible temperatures under which the 4090-9116 Addressable IDNet
Isolator may function are between 0° C (32° F) and 49° C (120° F).
The 4090-9116 Addressable IDNet Isolator operates normally under non-condensing
humidity conditions up to 93% with relative humidity at 32° C (90° F).
Installation Instructions
®
PRODUCT THAT APPEARS DAMAGED -
574-872
Rev. G

Advertisement

loading

Summary of Contents for Simplex 4090-9116

  • Page 1 574-872 Specifications and other information shown were current as of publication and are subject to change without notice. TYCO, SIMPLEX, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. Rev. G...
  • Page 2 4090-9116 Addressable IDNet Isolator Installation Instructions Installation Addressable IDNet Isolator installation consists of the following: • Setting the Addressable IDNet Isolator address • Making electrical connections to the Addressable IDNet Isolator • Mechanically installing the Addressable IDNet Isolator Mounting Bracket...
  • Page 3 4090-9116 Addressable IDNet Isolator Installation Instructions Panel Configuration Configure the Addressable IDNet Isolator to the 4100 panel using the ES Panel Programmer’s Manual (574-849). Configure the Addressable IDNet Isolator to the 4008 panel using programming manuals 579-716 or 579-717. Making Electrical Terminal connections for the Addressable IDNet Isolator are illustrated in Figure 3.
  • Page 4 FD4-872-04 Wiring Notes: 1. Operation of the 4090-9116 Addressable IDNet Isolator requires connection to a compatible 4100ES, 4100U, 4010ES, or 4008 IDNet communications channel.
  • Page 5 4090-9116 Addressable IDNet Isolator Installation Instructions Multi-Floor Isolator Class A Wiring: Figure 5 is a modification of Figure 4. Each floor is wired as a Class A Examples (Style 6) connection. Diagnostic Assistance: For Class A wiring, it is recommended that isolators be located as the first and last devices in the loop (as shown below in figure 5).
  • Page 6 Addressable IDNet Isolator #8/32 Flathead Screw (Not Supplied) Note: Simplex offers semi-flush and surface covers (ordered separately) with a light pipe. The cover(s) with light pipe allow viewing of the communications LED without taking the cover off. Installation of the 4090-9806 semi-flush cover and 4090-9807 surface cover are detailed in ™...
