9.10

Accessing the control functions

The control unit includes pre-programmed functions. For the list of pre-programmed functions, see Table 18.
To access the control functions, complete the following steps:
1. Press MENU.
2. Press the UP or DOWN keys until the control unit displays the following:
<ENTER>=Accept
Menu: [CTRL FUNCTION]
Press ENTER. Use the UP or DOWN keys to choose one of the options shown in Table 18.
3.
Function
City/DACT Disconnect
(Level 2)
Control Point Bypass
(Level 2)
Elevator Bypass
(Level 2)
Door holder Bypass
(Level 2)
Display Time
(Level 1)
4. Press ENTER to select the appropriate option.
9.11

Setting the time and date

To change the system time and date, complete the following steps:
Press MENU.
1.
Press the UP or DOWN keys until the control unit displays the following:
2.
<ENTER>=Accept
Menu: [Set Time/Date]
3. Press ENTER and the control unit displays the following:
<ENTER>=Accept
[11]:23 pm 11/12/19
4. Use the LEFT or RIGHT keys to move the focus from field-to-field for editing.
Use the UP or DOWN keys to change the currently selected fields.
5.
Note: You can only change the am/pm field by scrolling through the hour values.
Reset the Date and Time setting after every panel restart and at the time of maintenance.
page 44
Table 18: Control functions
Operations performed
Disconnects the city circuit or DACT (causes trouble)
Bypasses all the NAC and relay function types (causes trouble)
Bypasses elevator recall operation (causes trouble)
Bypasses the door holder operation (causes trouble)
Shows the current time and date
