9.4.2

Enabling or disabling the DACT

To enable or disable the DACT, complete the following steps:
1. See Accessing the DACT program menu
2. Press ENTER. The control unit displays the following:
<ENTER>=Accept
Opt: [Enable DACT]
3. Press ENTER. The control unit displays the following:
Enable DACT
[ON]
Use the UP and DOWN keys to change the setting to OFF, if you want to disable the DACT.
4.
5. Press ENTER. The control unit displays a prompt to confirm the choice.
6. Press ENTER to confirm the selection. The prompt shown in Step 2 reappears.
7. Press DOWN key to move to next option [Pri Phone #].
Note: By default, the DACT is enabled, but unconfigured. The DACT will report a configuration trouble until the phone numbers
and account numbers are programmed, or until it is disabled if it will not be used.
9.4.3

Setting the primary phone number

To set the primary phone number, complete the following steps:
1. See the Accessing the DACT program menu
Press ENTER and then press the UP and DOWN keys until [Pri Phone #] is displayed.
2.
<ENTER>=Accept
Opt: [Pri Phone #]
Note: The user can set the primary phone number of the supervising station. This is the number that the DACT dials first. When
connecting to a TL300, enter any telephone number.
3. Press ENTER. The following prompt appears.
Pri Phone #
[X]XXXXXXXXXXXXXXX
4. Use the LEFT and RIGHT keys to move the cursor from one digit to another. Use the keypad numbers, or use the UP and DOWN
keys to enter each number. Press ENTER when the number is correctly entered. The control unit displays a prompt to confirm
the number that you entered.
Press ENTER. The prompt shown in Step 2 reappears.
5.
6. Press the DOWN key to move to next option [Pri Account #]
Note: The following special characters are available for use when setting the primary and secondary phone numbers.
- B: Use if it is necessary to input a DTMF (touchtone) asterisk (*) into the phone number.
- C: Use if it is necessary to input a DTMF pound sign (#) into the phone number.
- D: Inserting this character into the phone number causes a three second delay at the point at which the D appears.
- E: With this character, DACT can start dialing as soon as a dial tone is detected.
If E is not the first character of the number, the DACT waits seven additional seconds before dialing.
Do not use E after the first digit unless a secondary dial tone is expected.
page 31
2008 Foundation Series Fire Alarm Control Unit Operation Guide
and repeat the steps from 1 to 4.
section and repeat the steps from 1 to 4.
579-1401 Rev A
