This publication describes the installation procedure for 4100-5101 (120 VAC), 4100-5102
Introduction
(220/230/240 VAC), and 4100-5103 (120 VAC with battery disconnect) Expansion Power
Supplies (XPSs), and the 4100-5115 Expansion NAC Module (XNAC).
Inspecting Contents
Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If
of Shipment
damage is apparent, immediately file a claim with the carrier and notify Simplex.
In this Publication
This publication discusses the following topics:
2001, Simplex Time Recorder Co., Westminster, MA 01441-0001 USA
All specifications and other information shown were current as of publication, and are subject to change without notice.
Cautions and Warnings
Expansion Power Supply Modules
The Expansion Power Supply (XPS)
Step 1. Mounting the XPS
Step 2. XPS Configuration
Step 3. Internal Wiring
Step 4. XPS Field Wiring
Step 5. Installing the XNAC
Step 6. Troubleshooting
firealarmresources.com
4100U XPS and XNAC
Installation Instructions
Topic
See Page #
2
3
4
6
7
9
11
17
18
574-772
Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4100-5101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simplex 4100-5101

Summary of Contents for Simplex 4100-5101

  • Page 1 Supplies (XPSs), and the 4100-5115 Expansion NAC Module (XNAC). Inspecting Contents Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If of Shipment damage is apparent, immediately file a claim with the carrier and notify Simplex.

  • Page 2: Cautions And Warnings

    Product operation and reliability depends upon proper installation. DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS DAMAGED. Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify Simplex.
  • Page 3 Expansion Power Supply Modules Overview This publication describes the installation procedure for the following: • 4100-5101 Expansion Power Supply (XPS), 120 VAC, 60 Hz • 4100-5102 XPS, 220/230/240 VAC 50/60 Hz • 4100-5103 XPS, 120 VAC, 60 Hz, with battery disconnect (Canada) •...
  • Page 4 The Expansion Power Supply (XPS) XPS Features Figure 1, below, is an illustration of the XPS. POWER/ COMMS PDI CONNECTOR NAC TERMINAL AC STATUS LED OUTPUT TO (reverse side) BLOCK (TB1) (LED4) NEXT PDI (P2) XNAC 3 A (NAC) CONNECTOR (P3) 2 A (AUX) BATTERY...
  • Page 5 Table 1 summarizes the input and output specifications for the XPS. Specifications Table 1. Input and Output Specifications AC Input Specifications 120 VAC @ 60 Hz, nominal (102-132 VAC @ 60 Hz) 4100-5101 4 A Max 220/230/240 VAC @ 50 or 60 Hz 4100-5102 2 A Max...

  • Page 6: Expansion Power Supply

    Step 1. Mounting the XPS Guidelines The XPS is designed to be mounted on the rightmost top and bottom positions of the PDI in a 4100 expansion cabinet. Before mounting the XPS, follow these guidelines: • Disconnect power to the system or remove power at the breaker before mounting or installing anything in the unit.
  • Page 7 Step 2. XPS Configuration Overview XPS configuration consists of setting the address switch as described in this section. Setting the Address The XPS device address is set via DIP switch SW1, which is a bank of eight switches. From left to right (see Figure 3, below) these switches are designated as SW1-1 through SW1-8.
  • Page 8 Step 2. XPS Configuration, Continued Setting the Address, (continued) Table 2. XPS Card Addresses Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Continued on next page...

  • Page 9: Step 3. Internal Wiring

    Step 3. Internal Wiring Overview The XPS gets its power from the power distribution module (PDM). The PDM takes power directly from the AC mains and the two backup batteries, and distributes power to each bay in the cabinet. Figure 4, below, shows the PDM connecting to a host FACP with two XPSs. INCOMING AC POWER BTRY...
  • Page 10 Step 3. Internal Wiring, Continued Power Distribution The Power Distribution Module (PDM) connects to the XPS in each bay. One PDM is used per Module Connections back box. Use the instructions below to properly connect the PDM to the XPS. Connect the 734-012 Harness from the top connector on the PDM to the XPS.
  • Page 11 This table is calculated at 50 degrees Centigrade. If you are installing in locations that could be exposed to higher temperatures, refer to NEC Table 8, or contact Simplex Sales Engineering. • Distances are based on a 3 V drop, and take into account the worst-case panel output voltage.
  • Page 12 This table is calculated at 50 degrees Centigrade. If you are installing in locations that could be exposed to higher temperatures, refer to NEC Table 8, or contact Simplex Sales Engineering. • Distances are based on a 3 V drop, and take into account the worst-case panel output voltage.
  • Page 13 Step 4. XPS Field Wiring, Continued Overview The XPS provides three outputs for notification appliance circuits and four inputs for auxiliary power circuits. This section describes all types of wiring from the XPS to 4100-compatible appliances. Guidelines Review the following guidelines for NACs before you begin NAC field wiring. •...

  • Page 14: Notification Appliances

    Step 4. XPS Field Wiring, Continued Class A NAC Wiring To connect the XPS to appliances using Class A wiring, read the following instructions and refer to Figure 6, below. Route wire between 12 and 18 AWG from the B+ and B- outputs on TB1 of the XPS to the appropriate inputs on a peripheral notification appliance.
  • Page 15 Step 4. XPS Field Wiring, Continued Class B NAC Wiring To connect the XPS to appliances using Class B wiring, read the following instructions and refer to Figure 7, below. Use NAC1, NAC2, or NAC3 to route 12 to 18 AWG wire from B+ and B- on the XPS to the first appliance.
  • Page 16 Step 4. XPS Field Wiring, Continued Auxiliary Power The XPS can receive auxiliary power appliances via the dedicated auxiliary power tap (TB2). If Wiring additional power is needed, any of the three NAC outputs can be used as auxiliary power inputs. Figure 8, below, shows how the XPS should be wired for auxiliary power at any given terminal.
  • Page 17 Step 5. Installing the XNAC Overview The 4100-5115 Expansion NAC Module (XNAC) is an option board that provides three NACs in addition to the three NACs already on the XPS. The XNAC plugs onto the XPS. If you are not installing an XNAC, skip this section and continue on to “Step 6: Troubleshooting.” The XNAC The XNAC has three NACs, each rated at 3 A.

  • Page 18: Step 6. Troubleshooting

    Step 6. Troubleshooting Overview This section describes the messages that may appear on the 4100 display when using the XPS. Trouble messages appear on the left as titles, and possible causes are listed to the right in the text. AC Power Loss Voltage has fallen below an acceptable level.
