8 Default programming assignments

8.1

IDC, NAC, and relay default function types

For information about the default function types assigned by the auto programming process to IDC, NAC and relays, see Table 4.
The function type determines how the device operates. For example, a function type of SSIG or SRELAY means the device is on until an
alarm silence is performed.
The function type is a programmable attribute that you can manually change.
Circuit
IDC1-8
NAC1 and NAC2
AUX1 (Relay 1)
AUX2 (Relay 2)
AUX3 (Relay 3)
AUX4 (Relay 4)
8.2

NAC, relay, and signal circuit output mode assignments

For the default output method, for example, steady or temporal assignments for the NAC and relay circuits, see Table 5.
The output mode is a programmable attribute that you can manually change.
Circuit Default function type
NAC1 and NAC2 Temporal code, is a three pulse coding pattern consisting of three 1/2 second pulses, each separated by 1/2
second silence. Each group of three pulses is separated by 1.5 seconds of silence
Relay 1 to 4 Steady on
SIGNAL modules Steady on
8.3

DACT defaults

The defaults for the DACT are as follows:
• Tone else pulse dialing
• AC Fail reporting delay is 2 hours.
• Reporting format is contact ID (CID).
• Primary and secondary phone number. There are no values for the primary and secondary phone numbers or account codes.
• Default event codes are shown in Table 6.
Function type Fire
FIRE 110
WATER 113
HEAT 114
DUCT 116
PULL 115
SMOKE 111
SO -
WSO 110
Note: Any other trouble not specifically mentioned would have a code of 330, for example, a trouble on an output device would report an
event code of 330.
page 18
Table 4: Default function types of IDC, NAC and relay
Table 5: Default operating modes of NAC, relay and signal circuit outputs
Table 6: Default CID event codes
Supervisory Trouble
- 330
- 330
- 330
- 330
- 330
- 330
200 330
200 330
2008 Foundation Series Fire Alarm Control Unit Operation Guide
Default function type
Fire
QALERT
Common Fail-Safe Trouble (non-programmable)
Common Alarm, On Until Reset (programmable)
Common Supervisory (Programmable)
Common Trouble (Programmable)
Function type Fire
SUPV -
UTIL -
TROUBLE -
VSMOKE 111
LATSUPV -
STYLEC 110
DRILL -
OTHER TRBL -
(see note)
Supervisory Trouble
200 330
- 330
- 330
- 330
200 330
- 330
- 330
- 330
579-1401 Rev A
