11. Turn the winch drum one full revolution. Guide the cable against the flange at the bottom of the winch drum.

The cable must not wrap over itself on the drum, but should be wrapped as close as possible to each previous

wrap. See Figure 24.

Drop Installation

1. Attach a 3004 Pulley to each hook.

2. Thread the end of the 3/32" or 1/8" cable through the pulley toward the winch. Clamp this end to the 3/16"

winch cable about 6" (150 mm) from the last pulley, using a 3/16" cable clamp. See Figure 8 on page 12.

3. Allow enough cable length for installation of the Cable Lock.

Sufficient cable is included to provide "throwbacks" on drops located beneath and near the winch. See Figure

9 on page 12 for "throwback" arrangement.

4. Begin installing suspension drops at the winch and proceed to the ends of the feeder line.

Keep the main cable tight between drops. It may be necessary to hang a weight on the end of the cable to

maintain tension on the line.

Figure 24. Cable Installation (End View)

Pan Breeder Feeder

MF513J
