Chore-Time G Plus Installation And Operator's Manual page 21

Pan Breeder Feeder
Use cotter pins, supplied, to secure the boot to the hopper.
The Hopper Cover, shown in Figure 23, is optional and must be ordered separately, if desired.
Secure the half of the cover with the tube opening on the top of the hopper. The other half of the cover will latch
in place.
MF513J
Figure 24. 200# Hopper Suspension components.
Figure 25. Assembled 200# Hopper w/o Cover.
Hopper Assembly Procedure
Item Description
1 Clevis Pin and Hair Pin
2 Cable Assembly
3 Adjustment Bracket
4 Hanger Bracket
21
