Page 5: Table Of Contents
Ports for 1Gbps SFP, 10Gbps SFP+, or SP10TM Transceivers..................19 SFP and SFP+ Transceivers..........................19 LEDs ..................................20 Twisted Pair Ports on the x950-28XTQm and x950-52XTQm Switches ..............21 Cable Requirements .............................21 LEDs ..................................22 Ports for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or Breakout Cables ............24 QSFP28 Transceivers ............................24...
Page 6 Contents Overview..................................50 XEM2-8XSTm Line Card ............................. 53 Twisted Pair Ports ..............................53 Twisted Pair Port LEDs ............................54 Transceiver Ports ..............................55 Transceiver Port LEDs ............................56 XEM2-12XT Line Card ..............................57 Twisted Pair Ports ..............................57 LEDs..................................58 XEM2-12XTm Line Card..............................
Page 7 x950 Series Installation Guide for Standalone Switches Extension Brackets .............................137 Equipment Rack Requirements..........................139 Reviewing Safety Precautions............................140 Installation Overview ..............................143 Unpacking the Shipping Container ..........................144 Installing the Outer Rails on the Equipment Rack ......................146 Installing the Extension Brackets on the Inner Rails ....................148 Measuring the Extension Bracket Lengths......................148 Assembling the Extension Brackets ........................150 Installing the Inner Rails on the Switch........................154...
Page 8 Contents...
Page 9: Preface
For instructions on how to build a stack of switches with the VCStack feature, refer to the x950 Series Installation Guide for Virtual Chassis Stacking. This preface contains the following sections: “Document Conventions” on page 10  “Contacting Allied Telesis” on page 11 ...
Page 10: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.
Page 11: Contacting Allied Telesis
Series Installation Guide for Standalone Switches Contacting Allied Telesis For assistance with this product, visit Allied Telesis web site at www.alliedtelesis.com/support.
Page 12 Preface...
Page 13: Chapter 1: Overview
“Features” on page 16  “Ports for 1Gbps SFP, 10Gbps SFP+, or SP10TM Transceivers” on  page 19 “Twisted Pair Ports on the x950-28XTQm and x950-52XTQm  Switches” on page 21 “Ports for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or ...
Page 14: X950 Series Switches
Ports 25, 29, 33. 37 Supported Supported x950-52XSQ Ports 1 to 48 Ports 49, 53, 57, 61 x950-52XTQm Ports 1 to 48 Ports 49, 53, 57, 61 Figure 1 shows the front panels of the x950-28XSQ and x950-28XTQm switches. Management Panel...
Page 15 Series Installation Guide for Standalone Switches Figure 2 shows the front panels of the x950-52XSQ and x950-52XTQm switches. Management Panel x950-52XSQ Switch Ports 1 to 48: Ports 49, 53, 57, 61: 40G/100Gbps Transceivers, or 1/2.5/5/10Gbps SFP/SFP+ Transceivers 10Gbps Breakout Cables...
Page 16: Features
 transceivers. Refer to “Ports for 1Gbps SFP, 10Gbps SFP+, or SP10TM Transceivers” on page 19. 48 twisted pair ports on the x950-52XTQm Switch with speeds of  100Mbps and 1/2.5/5/10Gbps. Refer to “Twisted Pair Ports on the x950-28XTQm and x950-52XTQm Switches” on page 21.
Page 17: Xem2 Ethernet Line Cards
Refer to “XEM2-1CQ Line Card” on page 66. Line cards are ordered separately. Refer to the product data sheet on the Allied Telesis web site for a list of approved transceivers. Management Here are the management software and interfaces: Software and AlliedWare Plus management software.
Page 18: Management Panel
 reduce power consumption. Note The x950-52XSQ and x950-52XTQm switches do not have the eco-friendly button; however, the eco-friendly mode can be turned on or off with the ECOFRIENDLY LED or NO ECOFRIENDLY LED command in the Command Line Interface.
Page 19: Ports For 1Gbps Sfp, 10Gbps Sfp+, Or Sp10Tm Transceivers
They support full-duplex mode only.  You can set the port speeds with Auto-Negotiation or manually.  The default is Auto-Negotiation. Transceivers must be purchased separately. For a list of supported transceivers, refer to the product data sheet on the Allied Telesis web site.
Page 20: Leds
- The LEDs are turned off. To turn on the LEDs, use the eco-friendly button in the management panel or the NO ECOFRIENDLY LED command in the command line interface. Note The x950-52XSQ and x950-52XTQm switches do not have the eco-friendly button.
Page 21: Twisted Pair Ports On The X950-28Xtqm And X950-52Xtqm Switches
Twisted Pair Ports on the x950-28XTQm and x950-52XTQm Switches The specifications for twisted pair ports 1 to 24 on the x950-28XTQm switch and ports 1 to 48 on the x950-52XTQm switch are listed in Table 3. Table 3. Twisted Pair Ports on the x950-28XTQm and x950-52XTQm...
Page 22: Leds
Chapter 1: Overview LEDs This section explains the LEDs for the 100Mbps and 1/2.5/5/10Gbps twisted pair ports on the x950-28XTQm and x950-52XTQm switches. Each port has one LED that displays link and activity information. The LEDs are shown in Figure 5.
Page 23 Series Installation Guide for Standalone Switches Table 4. Link and Activity LEDs for Twisted Pair Ports on the x950-28XTQm and x950-52XTQm Switches (Continued) State Description Possible causes of this state are listed here: - The port has not established a link with another network device.
Page 24: Ports For 40Gbps Qsfp+ Or 100Gbps Qsfp28 Transceivers, Or Breakout Cables
25, 29, 33, 37 x950-28XTQm 25, 29, 33, 37 x950-52XSQ 49, 53, 57, 61 x950-52XTQm 49, 53, 57, 61 QSFP28 The ports support the following 100Gbps QSFP28 transceivers: Transceivers QSFP28SR4 transceiver - Maximum operating distance of 70m ...
Page 25: Leds
x950 Series Installation Guide for Standalone Switches Figure 6. QSFP-4SFP10G-3CU and QSFP-4SFP10G-5CU Copper Breakout Cables The fiber optic break-out cables are ET3-MPO08-4LC-5 and ET3-MPO08-4LC-10, in lengths of 5 and 10 meters, respectively. They have duplex LC connectors. Refer to Figure 7. Figure 7.
Page 26 Chapter 1: Overview Ports 49, 53, 57, and 61 on the x950-52XSQ and x950-52XTQm switches have one link and activity status LED each. Refer to Figure 9. Transceiver Port LED Figure 9. LEDs for Ports 49, 53, 57, and 61 on the x950-52XSQ and...
Page 27 NO ECOFRIENDLY LED command in the command line interface. Note The x950-52XSQ and x950-52XTQm switches do not have the eco-friendly button. LEDs for Breakout Cables The LED states for breakout cables are described in Table 7.
Page 28: Port Numbering For The X950-28Xsq And X950-28Xtqm Switches
NO ECOFRIENDLY LED command in the command line interface. Note The x950-52XSQ and x950-52XTQm switches do not have the eco-friendly button. Port Numbering Table 8 lists the port numbering system for ports 25, 29, 33, and 37 on the...
Page 29: Port Numbering For The X950-52Xsq And X950-52Xtqm Switches
Series Installation Guide for Standalone Switches Port Numbering Table 9 lists the port numbering system for ports 49, 53, 57, and 61 on the x950-52XSQ and x950-52XTQm switches when the switch is operating as for the a stand-alone unit (i.e., the VCStack feature is disabled):...
Page 30: Management Panel
USB Slot NET MGMT Port Figure 10. Management Panel for the x950-28XSQ and x950-28XTQm Switches The components on the management panel for the x950-52XSQ and x950-52XTQm switches are identified in Figure 11. Switch ID CONSOLE RS-232 Serial Port USB Slot NET MGMT Port Figure 11.
Page 31: Usb Port
x950 Series Installation Guide for Standalone Switches USB Port You can use the USB port with a flash drive for the following functions: Provide a centralized network backup location for Autonomous  Management Framework. Store backup copies of configuration files. ...
Page 32: Console (Rs-232) Port
Chapter 1: Overview Table 10. NET MGMT Port LED State Description Solid Green The port has established a 1000 Mbps link with a network device. Flashing Green The port is transmitting or receiving data at 1000 Mbps. Solid Amber The port has established a 10 or 100 Mbps link.
Page 33 x950 Series Installation Guide for Standalone Switches The switch is booting up. The switch has encountered a fault condition. The VCStack feature is disabled. The switch is operating as a stand-alone unit, with the ID number 1. The switch is a member of a VCStack and has an ID number in the range of 1 to 8.
Page 34: Eco-Friendly Button
MGMT port. Additionally, the button does not control the LEDs on the power supplies. Note The x950-52XSQ and x950-52XTQm switches do not have the eco-friendly button; however, the eco-friendly mode can be turned on or off with the ECOFRIENDLY LED or NO ECOFRIENDLY LED...
Page 35: Optional Direct Attach Cables
QSFP3CU - 3 meters x950-28XTQm XEM2-1CQ 100Gbps QSFP28-1CU - 1 meter Ports 49, 53, 57, 61 QSFP28-3CU - 3 meters on x950-52XSQ and x950-52XTQm 1. The XEM2-12XS v2 Card supports the SP10TW1 and SP10TW3 cables. It does not support the SP10TW7 cable.
Page 36: Pwr600 Ac And Dc Power Supplies
Chapter 1: Overview PWR600 AC and DC Power Supplies The x950 series switch supports the PWR600 AC and PWR600 DC power supply units. See Figure 14 and Figure 15. Model Name on the Label Direction of Airflow Figure 14. PWR600 AC Power Supply Model Name on the Label Direction of Airflow...
Page 37: Power Supply Airflow And Fan Modules
x950 Series Installation Guide for Standalone Switches Power Supply The x950 series switch can be powered with the PWR600 AC power supply, PWR600 DC power supply, or both. These power supplies are Airflow and Fan available in two options: Modules Power supply unit with the embedded fan that blows air toward the ...
Page 38 Chapter 1: Overview Figure 16. AT-PWR600-80 Power Supplies and AT-FAN05 Modules See Figure 17 for another example. The two AT-PWR600R-80 DC power supplies and two AT-FAN05R modules are installed at the rear of the switch. The fans embedded in the power supplies and AT-FAN05R modules both blow air to the rear of the switch.
Page 39: Guidelines For Power Supply
 the rear panel of the chassis. If you are installing only one power supply, Allied Telesis recommends installing it in PSU A slot because that slot does not come with a blank slot cover. The switch does not come with power supply units. They are ...
Page 40: Leds
Chapter 1: Overview LEDs The two LEDs on the front panel of the power supply are described in Table 13. Table 13. LEDs on the PWR600 AC Power Supply Green LED Amber LED Description Solid green The power supply is operating normally.
Page 41: Pwr600 Dc Power Supply
x950 Series Installation Guide for Standalone Switches PWR600 DC The PWR600 DC module is a DC power supply for the switch. Refer to Figure 19. Power Supply LEDs Figure 19. PWR600 DC Power Supply LEDs The PWR600 DC power supply has the two LEDs on the front panel as shown in Figure 19.
Page 42 Chapter 1: Overview Table 14. LEDs on the PWR600 DC Power Supply (Continued) Green LED Amber LED Description Solid amber The power supply shut down because it experienced a fault condition. Possible causes are listed here: - The power supply overheated. - The power supply’s fan stopped or was too slow.
Page 43: Fan05 Cooling Fan
x950 Series Installation Guide for Standalone Switches FAN05 Cooling Fan The cooling unit for the chassis is the FAN05 fan module. Refer to Figure 20. Model Name Figure 20. FAN05 Fan Module FAN05 Airflow The FAN05 fan module is available in two options: and PWR600 AT-FAN05 module: the fan blows air toward the front of the switch ...
Page 44: Guidelines For The Cooling Fan Module
Chapter 1: Overview Guidelines for the Here is a list of guidelines for the fan modules: Cooling Fan The direction of airflow of the fan modules and power supply units  Module must be the same. The switch comes with two pre-installed fan modules in FAN A and ...
Page 45: Designating Ports In The Command Line Interface
Identifies the switch’s ID number. Please review the following: - The default value is 1. - Allied Telesis recommends using the default value for stand-alone switches. - A stand-alone switch that was previously a stack member retains its ID number from the stack.
Page 46: Base Ports And Line Card Ports
Slot Number 1 for XEM2 Line Card: port1.0.n port1.1.n Figure 22. Slot Numbers for Port Numbering Note The x950-52XSQ and x950-52XTQm switches have base ports only. Examples for the Here are examples of the PORT parameter on base ports in the INTERFACE command for stand-alone switches.
Page 47: Examples For The Port Parameter On An Xem2 Line Card
x950 Series Installation Guide for Standalone Switches Examples for the The x950-28XSQ and x950-28XTQm switches can have an XEM2 line card installed. PORT Parameter on an XEM2 Line This example enters the port Interface mode for ports 4 and 5 on an XEM2 Card Line Card in the expansion slot: awplus(config)# interface port1.1.4,port1.1.5...
Page 48: Software And Hardware Releases
XEM2-12XT Line Card - Added 100Mbps port speed v5.4.9-2 XEM2-8XSTm Line Card XEM2-12XS v2 Line Card v5.4.9-2.3 VCStack - Stacks up to eight switches.* v5.5.0-1 x950-52XSQ Switch v5.5.1-0.1 x950-52XTQm Switch * For more information, see the x950 Series Switches Installation Guide for Virtual Chassis Stacking.
Page 49: Chapter 2: Xem2 Ethernet Line Cards
Chapter 2 XEM2 Ethernet Line Cards The chapter contains the following sections: “Overview” on page 50  “XEM2-8XSTm Line Card” on page 53  “XEM2-12XT Line Card” on page 57  “XEM2-12XTm Line Card” on page 59  “XEM2-12XS and XEM2-12XS v2 Line Cards” on page 61 ...
Page 50: Overview
Overview The x950-28XSQ and x950-28XTQm switches have one expansion slot on the front panel for an optional XEM2 Ethernet line card. See Figure 23. Note The x950-52XSQ and x950-52XTQm switches do not support the XEM2 line cards. XEM2-8XSTm XEM2-12XT XEM2-12XTm...
Page 51 x950 Series Installation Guide for Standalone Switches The XEM2 Ethernet line cards are described in Table 18. Table 18. XEM2 Ethernet Line Cards Line Card Description XEM2-8XSTm Four twisted pair ports (1-4) with RJ-45 connectors that support the following speeds: - 100Mbps - 1/2.5/5/10Gbps Four ports (5-8) that support the following...
Page 52 Chapter 2: XEM2 Ethernet Line Cards Table 18. XEM2 Ethernet Line Cards (Continued) Line Card Description XEM2-12XS and 12 ports that support the following types of XEM2-12XS v2 transceivers: - 1Gbps SFP - 10Gbps SFP+ - 10Gbps one meter SP10TW1, three meter SP10TW3, and seven meter SP10TW7 direct connect twinax cables (The XEM2-12XS v2 Card does not...
Page 53: Xem2-8Xstm Line Card
x950 Series Installation Guide for Standalone Switches XEM2-8XSTm Line Card The XEM2-8XSTm Line Card is shown in Figure 24. Figure 24. XEM2-8XSTm Line Card Twisted Pair The XEM2-8XSTm Card has four twisted pair ports and four SFP ports. The specifications for the twisted pair ports are listed in Table 19. Ports Table 19.
Page 54: Twisted Pair Port Leds
Chapter 2: XEM2 Ethernet Line Cards Table 19. Twisted Pair Ports on the XEM2-8XSTm Line Card (Continued) Specification Description Cabling Minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B-compliant Category 3 unshielded cabling. - 1/2.5/5Gbps - Standard TIA/EIA 568-A-compliant Category 5 or TIA/EIA 568-B-compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 55: Transceiver Ports
You can set the port speeds with Auto-Negotiation or manually.  The default is Auto-Negotiation. SFP and SFP+ transceivers are purchased separately. For a list of supported transceivers, refer to the SBx908 GEN2 Series data sheet on the Allied Telesis web site.
Page 56: Transceiver Port Leds
Chapter 2: XEM2 Ethernet Line Cards Transceiver Port The ports have link and activity LEDs. The states of the LEDs are described in Table 21. LEDs Table 21. Link and Activity LEDs for the SFP Ports on the XEM2-8XSTm Line Card State Description Solid Green...
Page 57: Xem2-12Xt Line Card
x950 Series Installation Guide for Standalone Switches XEM2-12XT Line Card The XEM2-12XT Line Card is shown in Figure 25. Figure 25. XEM2-12XT Line Card Twisted Pair The card has 12 twisted pair ports with standard 8-pin RJ-45 ports. The specifications of the ports are listed in Table 22. Ports Table 22.
Page 58: Leds
Chapter 2: XEM2 Ethernet Line Cards Table 22. Twisted Pair Ports on the XEM2-12XT Line Card (Continued) Specification Description Cabling The minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B-compliant Category 3 unshielded cabling. - 1Gbps - Standard TIA/EIA 568-A-compliant Category 5 or TIA/EIA 568-B-compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 59: Xem2-12Xtm Line Card
x950 Series Installation Guide for Standalone Switches XEM2-12XTm Line Card The XEM2-12XTm Card is shown in Figure 26. Figure 26. XEM2-12XTm Line Card Twisted Pair The XEM2-12XTm Card has 12 twisted pair ports with standard 8-pin RJ-45 ports. The specifications of the ports are listed in Table 24. Ports Table 24.
Page 60: Leds
Chapter 2: XEM2 Ethernet Line Cards Table 24. Twisted Pair Ports on the XEM2-12XTm Line Card (Continued) Specification Description Cabling The minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B-compliant Category 3 unshielded cabling. - 1/2.5/5Gbps - Standard TIA/EIA 568-A-compliant Category 5 or TIA/EIA 568-B-compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 61: Xem2-12Xs And Xem2-12Xs V2 Line Cards
x950 Series Installation Guide for Standalone Switches XEM2-12XS and XEM2-12XS v2 Line Cards The XEM2-12XS Line Card is shown in Figure 27. Figure 27. XEM2-12XS Line Card Transceiver Ports The card has twelve ports that support the following types of 1Gbps SFP, 10Gbps SFP+, and 1/2.5/5/10Gbps transceivers with RJ-45 connectors: 1Gbps SX or LX SFP transceivers ...
Page 62: Card Versions
Chapter 2: XEM2 Ethernet Line Cards Guidelines about the ports are listed here: They do not support 100Mbps transceivers.  They support full-duplex mode only.  You can set the port speeds with Auto-Negotiation or manually.  The default is Auto-Negotiation. SFP or SFP+ transceivers must be purchased separately.
Page 63 x950 Series Installation Guide for Standalone Switches Table 26. Port Link and Activity LEDs on the XEM2-12XS Line Card State Description Solid Amber The transceiver has established a 1GBase link to a network device. Flashing Amber The transceiver is transmitting or receiving data at 1GBase.
Page 64: Xem2-4Qs Line Card
Chapter 2: XEM2 Ethernet Line Cards XEM2-4QS Line Card The XEM2-4QS Line Card is shown in Figure 29. Figure 29. XEM2-4QS Line Card Transceiver Ports The card supports the following types of 40Gbps QSFP+ transceivers in its four ports: QSFPSR4 transceiver - Maximum operating distance of 150 ...
Page 65: Leds
x950 Series Installation Guide for Standalone Switches LEDs The LED states for transceivers or direct attach cables in ports on the XEM2-4QS Line Card are described in Table 27. Table 27. Port Link and Activity Status LEDs on the XEM2-4QS Line Card State Description...
Page 66: Xem2-1Cq Line Card
Chapter 2: XEM2 Ethernet Line Cards XEM2-1CQ Line Card The XEM2-1CQ Line Card is shown in Figure 30. Figure 30. XEM2-1CQ Line Card Transceiver Port The one port on the card supports the following 100Gbps QSFP28 transceivers: QSFP28SR4 transceiver - Maximum operating distance of 70m ...
Page 67 x950 Series Installation Guide for Standalone Switches Table 29. Port Link and Activity Status LED on the XEM2-1CQ Line Card State Description Flashing Green The transceiver is transmitting or receiving data. Possible causes of this state are listed here: - The transceiver slot is empty. - The transceiver has not established a link to a network device.
Page 68 Chapter 2: XEM2 Ethernet Line Cards...
Page 69: Chapter 3: Beginning The Installation
Chapter 3 Beginning the Installation The chapter contains the following sections: “Reviewing Safety Precautions” on page 70  “Installation Options” on page 75  “Choosing a Site for the Chassis” on page 76  “Unpacking the Switch” on page 77 ...
Page 70: Reviewing Safety Precautions
Chapter 3: Beginning the Installation Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedure. Note Safety statements that have the  symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support. Warning Class 1 Laser product.
Page 71 x950 Series Installation Guide for Standalone Switches Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord.  E3 Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet.
Page 72 Mounting of the equipment in the rack should be such that a hazardous condition is not created due to uneven mechanical loading.  E25 Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28...
Page 73 x950 Series Installation Guide for Standalone Switches Note Use dedicated power circuits or power conditioners to supply reliable electrical power to the device.  E27 Warning This unit might have more than one power cord. To reduce the risk of electric shock, disconnect all power cords before servicing the unit.
Page 74 Chapter 3: Beginning the Installation Warning This equipment shall be installed in a Restricted Access location.  E45 Caution The unit does not contain serviceable components. Please return damaged units for servicing.  E42 Warning The temperature of an operational SFP or SFP+ transceiver may exceed 70°...
Page 75: Installation Options
x950 Series Installation Guide for Standalone Switches Installation Options Here are installation options for the x950 series switches: The x950-28XSQ and x950-28XTQm switches can have an XEM2  line card installed. Refer to “Installing an Optional XEM2 Ethernet Line Card” on page 103. The switch has four orientation options.
Page 76: Choosing A Site For The Chassis
Chapter 3: Beginning the Installation Choosing a Site for the Chassis Observe these site requirements. If you are installing the device in an equipment rack, check that the  rack is safely secured so that it will not tip over. Devices should be installed in the rack starting at the bottom, with the heavier devices near the bottom of the rack.
Page 77: Unpacking The Switch
x950 Series Installation Guide for Standalone Switches Unpacking the Switch To unpack the switch from its shipping box, perform the following procedure: 1. Remove the accessories and documents from the accessory box partition. Refer to Figure 32. Figure 32. Removing Accessories 2.
Page 78 Chapter 3: Beginning the Installation Figure 33. Removing the Shipping Box Partition 3. Lift the switch from the shipping box and place it on a level, secure table. Refer to Figure 34 on page 79. Warning The device is heavy. Always ask for assistance before moving or lifting it to avoid injure yourself or damage the equipment.
Page 79 x950 Series Installation Guide for Standalone Switches Figure 34. Lifting the Switch from the Shipping Box 4. Remove the switch from the shipping end-caps and protective bag. Refer to Figure 35. Figure 35. Removing the Switch from the Shipping End-caps and Protective Bag...
Page 80 Chapter 3: Beginning the Installation 5. Visually inspect the product for damage. 6. Visually inspect the front panel for the components shown in Figure 1 on page 14. 7. Verify that there are two pre-installed fan modules in FAN A and FAN B slots on the rear panel.
Page 81: Verifying The Accessory Kit
For the x950-28XSQ and x950-28XTQm switches, these brackets are for both equipment rack and wall mounting. Note For the x950-52XSQ and x950-52XTQm switches, these brackets are only for wall mounting. For equipment rack mounting, use the rack mounting brackets shown in Table 31 on page 82.
Page 82 In addition to the accessory kit listed in Table 30 on page 81, the x950-52XSQ and x950-52XTQm switches are shipped with the rack mounting brackets and screws as shown in Table 31. Table 31. Additional Accessory Kit for the x950-52XSQ and x950-52XTQm Switches Item Description...
Page 83: Unpacking The Pwr600 Ac Power Supply
x950 Series Installation Guide for Standalone Switches Unpacking the PWR600 AC Power Supply To unpack the PWR600 AC Power Supply, perform the following procedure: 1. Remove the power cord and any documents from the accessory box partition. Refer to Figure 36. Figure 36.
Page 84 Chapter 3: Beginning the Installation Figure 37. Removing the Partition from the PWR600 AC Power Supply Shipping Box 3. Lift the AC power supply from the shipping box and place it on a level, secure table. Refer to Figure 38 on page 85. Warning The device is heavy.
Page 85 x950 Series Installation Guide for Standalone Switches Figure 38. Removing the Power Supply from the Shipping Box 4. Remove the power supply from the shipping end-caps and protective shipping bag. Refer to Figure 39. Figure 39. Removing the Power Supply from the Shipping End-caps and Protective Bag 5.
Page 86: Unpacking The Pwr600 Dc Power Supply
Chapter 3: Beginning the Installation Unpacking the PWR600 DC Power Supply To unpack the PWR600 DC Power Supply, perform the following procedure: 1. Open the box and remove the PWR600 DC power supply. 2. Visually inspect the product for damage. 3.
Page 87: Chapter 4: Installing Power Supplies And Optional Xem2 Line Card
Chapter 4 Installing Power Supplies and Optional XEM2 Line Card This chapter has the following procedures: “Installing PWR600 AC Power Supplies” on page 88  “Installing PWR600 DC Power Supplies” on page 92  “Connecting the Grounding Wire” on page 95 ...
Page 88: Installing Pwr600 Ac Power Supplies
PSU A and PSU B on the left side of the rear panel. If you are installing only one power supply, you can install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel.
Page 89 x950 Series Installation Guide for Standalone Switches Release Tab Figure 40. Removing the Blank Power Supply Panel from Slot PSU B 3. Carefully align the power supply in the slot and slide it into the slot. Figure 41 on page 90 shows the module aligned for the PSU A slot.
Page 90 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Figure 41. Sliding the PWR600 AC Power Supply into the Chassis 4. When the power supply makes contact with the connector inside the switch, gently press on its faceplate to seat it on the connector. Refer to Figure 42 on page 91.
Page 91 x950 Series Installation Guide for Standalone Switches Figure 42. Seating the Power Supply on the Internal Connector 5. Visually inspect the power supply to be sure that its faceplate is flush against the rear panel of the chassis. 6. If you purchased two AC power supplies for the switch, repeat this procedure to install the second unit.
Page 92: Installing Pwr600 Dc Power Supplies
PSU A and PSU B on the left side of the rear panel. If you are installing only one power supply, you can install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel.
Page 93 x950 Series Installation Guide for Standalone Switches Figure 43. Sliding the PWR600 DC Power Supply into the Chassis 4. When the power supply makes contact with the connector inside the switch, gently press on its faceplate to seat it on the connector. 5.
Page 94 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card 10. After installing the power supplies and optional XEM2 Line Card, go to one of the following chapters: Chapter 5, “Installing the Switch on a Table” on page 107  Chapter 6, “Installing the Switch in an Equipment Rack”...
Page 95: Connecting The Grounding Wire
x950 Series Installation Guide for Standalone Switches Connecting the Grounding Wire Here are the guidelines for the grounding wire: The wire should be minimum #16 AWG solid wire.  The wire length should be as short as possible.  Continuity from the grounding screw to the earth ground must be ...
Page 96 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Warning Do not strip more than the recommended amount of wire. Stripping more than the recommended amount can create a safety hazard by leaving exposed wire on the terminal block after installation.  E10 2.
Page 97 x950 Series Installation Guide for Standalone Switches Figure 46. Accessing the Connectors 4. Loosen the ground screw with a Phillips-head screwdriver. Refer to Figure 47. Figure 47. Loosening the Ground Screw...
Page 98 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card 5. Wind the grounding wire clockwise around the base of the grounding screw. Refer to Figure 48. Figure 48. Wrapping the Grounding Wire and Tightening the Screw 6. Tighten the ground screw. 7.
Page 99: Connecting The Dc Power Wires
x950 Series Installation Guide for Standalone Switches Connecting the DC Power Wires Here are the materials and tools for connecting the DC power cables: 18 AWG stranded wires. Do not use wire heavier than 16 AWG.  solid wire. Wire insulation stripper ...
Page 100 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Note Allied Telesis recommends tinning the wires with solder for added protection against loose strands. This guide does not provide instructions on how to tin wires. 3. Loosen the middle screw for the negative (-) with a Phillips-head screwdriver.
Page 101 x950 Series Installation Guide for Standalone Switches 5. Loosen the top screw for the positive (+) with a Phillips-head screwdriver. Refer to Figure 53. Figure 53. Loosening the Screw for the Negative (+) 6. Wind the power wire and tighten the screw.Refer to Figure 54. Figure 54.
Page 102 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card 8. Place the cover panel back to cover the connectors. Refer to Figure Figure 55. Placing the Cover Panel 9. Tighten the screw for the cover panel. Refer to Figure 56. Figure 56.
Page 103: Installing An Optional Xem2 Ethernet Line Card
XEM2-12XT Line Card. The procedure is the same for all line cards. Note The x950-52XSQ and x950-52XTQm switches do not support the XEM2 line cards. Caution The device can be damaged by static electricity. Be sure to follow proper anti-static precautions when installing the device.
Page 104 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Figure 58. Removing the Ethernet Line Card from the Anti-static Bag 3. Position the line card with the notch on the faceplate in the bottom left corner, as shown in Figure 59, and carefully slide it into the slot. Notch Figure 59.
Page 105 x950 Series Installation Guide for Standalone Switches 4. When the line card makes contact with the internal connector in the switch, gently press on the sides of its faceplate to seat it on the connector. Refer to Figure 60. Figure 60. Seating the Ethernet Line Card in the Expansion Slot 5.
Page 106 Chapter 4: Installing Power Supplies and Optional XEM2 Line Card Figure 61. Tightening the Two Captive Screws on the Ethernet Line Card 7. After installing the power supplies and optional XEM2 Line Card, go to one of the following chapters: Chapter 5, “Installing the Switch on a Table”...
Page 107: Chapter 5: Installing The Switch On A Table
Chapter 5 Installing the Switch on a Table This chapter contains the instructions for installing the switch on a table or desktop. Warning Switches should not be stacked on a table or desktop. They could present a physical safety hazard if you need to move or replace switches.
Page 108 Chapter 5: Installing the Switch on a Table Rear of Chassis Front of Chassis Figure 63. Holes for Bumper Feet Note The following procedure assumes that you have already reviewed the information and performed the procedures in Chapter 3, “Beginning the Installation” on page 69. To install the switch on a table, perform the following procedure: 1.
Page 109 x950 Series Installation Guide for Standalone Switches 3. Place the bumper foot onto one of the holes in the base of the switch. Refer to Figure 65. Figure 65. Placing the Bumper Foot on a Base Corner Hole 4. Insert the rivet to secure the bumper foot to the base. Refer to Figure 66.
Page 110 Chapter 5: Installing the Switch on a Table 7. Do one of the following: To install AC power supplies, go to “Installing PWR600 AC Power  Supplies” on page 88. To install DC power supplies, go to “Installing PWR600 DC Power ...
Page 111: Chapter 6: Installing The Switch In An Equipment Rack
Chapter 6 Installing the Switch in an Equipment Rack This chapter contains instructions for installing the switch in a standard 19- inch equipment rack. The procedures are listed here: “Beginning the Installation” on page 112  “Removing the Bumper Feet” on page 114 ...
Page 112: Beginning The Installation
Standard Brackets Figure 67. Holes for the Equipment Rack Brackets on the x950-28XSQ and x950-28XTQm Switches Figure 68 identifies the holes for the equipment rack brackets on the x950-52XSQ and x950-52XTQm switches. Holes for Equipment Holes for Equipment Rack Brackets Rack Brackets Figure 68.
Page 113 x950 Series Installation Guide for Standalone Switches You can install the switch with its front panel flush with or extending in front of the equipment rack. The illustrations in Figure 69 show the possible switch orientations in the equipment rack. Figure 69.
Page 114: Removing The Bumper Feet
Chapter 6: Installing the Switch in an Equipment Rack Removing the Bumper Feet The bumper feet included with the switch should not be used when installing the device in an equipment rack. If they are already installed, perform the following procedure to remove them: 1.
Page 115: Installing The Switch
Please review the information and perform the procedures in Chapter 3, “Beginning the Installation” on page 69 before installing the switch. Caution The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28...
Page 116 Chapter 6: Installing the Switch in an Equipment Rack Figure 71. Attaching the Equipment Rack Brackets 4. Have another person hold the switch in the equipment rack while you secure it using standard equipment rack screws (not provided). Refer to Figure 72. Figure 72.
Page 117 x950 Series Installation Guide for Standalone Switches 5. Do one of the following: To install power supplies, go to “Installing PWR600 AC Power  Supplies” on page 88. To install an optional XEM2 Ethernet Line Card, go to “Installing an ...
Page 118 Chapter 6: Installing the Switch in an Equipment Rack...
Page 119: Chapter 7: Installing The Switch On A Wall
Chapter 7 Installing the Switch on a Wall The procedures in this chapter are listed here: “Switch Orientations on a Wall” on page 120  “Recommended Minimum Wall Area Dimensions” on page 121  “Plywood Base for a Wall with Wooden Studs” on page 123 ...
Page 120: Switch Orientations On A Wall
Chapter 7: Installing the Switch on a Wall Switch Orientations on a Wall You can install the switch on a wall with the front panel on the left or right, as shown in Figure 73. Do not install it with the front panel on the top or bottom.
Page 121: Recommended Minimum Wall Area Dimensions
x950 Series Installation Guide for Standalone Switches Recommended Minimum Wall Area Dimensions The recommended minimum dimensions for the reserved wall area for the switch are listed here: Width: 96 centimeters (36 inches)  Height: 58 centimeters (23 inches)  Figure 74 and Figure 75 on page 122 illustrate the recommended positions of the switch in the reserved area when the front panel is on the left and right, respectively.
Page 122 Chapter 7: Installing the Switch on a Wall Figure 75. Minimum Wall Area Dimensions with the Front Panel on the Right...
Page 123: Plywood Base For A Wall With Wooden Studs
x950 Series Installation Guide for Standalone Switches Plywood Base for a Wall with Wooden Studs If you are installing the switch on a wall that has wooden studs, Allied Telesis recommends using a plywood base for the device. (A plywood base is not required for a concrete wall.) Refer to Figure 76.
Page 124 Chapter 7: Installing the Switch on a Wall The recommended minimum dimensions of the plywood base are listed here: Width: 58.4 centimeters (23 inches)  Height: 55.9 centimeters (22 inches)  Thickness: 5.1 centimeters (2 inches)  The dimensions assume the wall studs are 41 centimeters (16 inches) apart.
Page 125: Installation Guidelines
x950 Series Installation Guide for Standalone Switches Installation Guidelines Here are the guidelines to installing the switch on a wall: You may install the switch on a wall that has wooden studs.  You may install it on a concrete wall. ...
Page 126: Tools And Material
Chapter 7: Installing the Switch on a Wall Tools and Here are the required tools and material for installing the switch on a wall: Material Four standard brackets and 16 M3x6mm screws (included with the  switch) listed in Table 30 on page 81. Four wood or concrete wall screws (included with the switch) ...
Page 127: Installing The Plywood Base
x950 Series Installation Guide for Standalone Switches Installing the Plywood Base A plywood base is recommended when installing the switch on a wall that has wooden studs. Refer to “Plywood Base for a Wall with Wooden Studs” on page 123. Consult a qualified building contractor for installation instructions for the plywood base.
Page 128: Installing The Switch On The Plywood Base
This procedure assumes that the plywood base for the switch is already installed on the wall. Please review “Reviewing Safety Precautions” on page 70 and “Choosing a Site for the Chassis” on page 76 before performing this procedure. Allied Telesis recommends a minimum of three people for this procedure. Warning The device is heavy.
Page 129 x950 Series Installation Guide for Standalone Switches The sides of the switch have two sets of holes. One set is for installing the switch on a wall with the brackets and the other is for the RKMT- SL01 Rack Mounting Kit. For this procedure, you need to use the bracket holes, identified in Figure 67 on page 112.
Page 130 Chapter 7: Installing the Switch on a Wall 4. Do one of the following: To install the power supplies, go to “Installing PWR600 AC Power  Supplies” on page 88. To install an optional XEM2 Ethernet Line Card, go to “Installing an ...
Page 131: Installing The Switch On A Concrete Wall
Series Installation Guide for Standalone Switches Installing the Switch on a Concrete Wall Allied Telesis recommends a minimum of three people for this procedure. To install the switch on a concrete wall, perform the following procedure: Warning The device is heavy. Always ask for assistance before moving or lifting it to avoid injuring yourself or damaging the equipment.
Page 132 3. Please review the following guidelines: Prior to drilling, set the drill to hammer and rotation mode. The  modes break up the concrete and clean out the hole. Allied Telesis recommends cleaning out the holes with a brush or  compressed air.
Page 133 x950 Series Installation Guide for Standalone Switches 6. Insert the four anchors into the holes. 7. Have two people hold the switch at the selected wall location while you secure it to the wall with the four provided screws. Refer to Figure 81. Figure 81.
Page 134 Chapter 7: Installing the Switch on a Wall...
Page 135: Chapter 8: Installing The Switch In The Rkmt-Sl01 Sliding Rack
Chapter 8 Installing the Switch in the RKMT-SL01 Sliding Rack This appendix contains the following sections: “Introduction” on page 136  “Rack Mount Kit Components” on page 137  “Equipment Rack Requirements” on page 139  “Reviewing Safety Precautions” on page 140 ...
Page 136: Introduction
Introduction The RKMT-SL01 Rack Mount Kit is a slide-rail type rack-mount kit for Allied Telesis switches in EIA standard 19-inch equipment racks. The kit makes installation and maintenance of network equipment easier by letting you slide switches into or out of equipment racks, including server racks with deep dimensions.
Page 137: Rack Mount Kit Components
x950 Series Installation Guide for Standalone Switches Rack Mount Kit Components The kit has three main components. Adjustable Outer Two adjustable outer rails attach to the equipment rack. They are suitable for racks with depths of 600 mm (23.6 in) to 900 mm (35.4 in). Refer to Rails Figure 82.
Page 138 Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Figure 84. Extension Brackets...
Page 139: Equipment Rack Requirements
x950 Series Installation Guide for Standalone Switches Equipment Rack Requirements The Rack Mount Kit is designed for equipment racks that meet the following requirements: The depth can be from 600 mm (23.6 in) to 900 mm (35.4 in).  The width should be a minimum of 452 mm (17.8 in). ...
Page 140: Reviewing Safety Precautions
 available in a PDF document titled Translated Safety Statements posted on the Allied Telesis website at www.alliedtelesis.com/ support. Warning Mounting of the equipment in the rack should be such that a hazardous condition is not created due to uneven mechanical loading.
Page 141 x950 Series Installation Guide for Standalone Switches Caution Use the adjustment bracket screws supplied with the inner rail. Using screws other than those supplied may result in equipment damage.  Warning When installing the outer and inner rails, and adjustment bracket, ensure the components are securely attached with the appropriate screws.
Page 142 Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Warning Do not pull the switch out past the front rack posts. ...
Page 143: Installation Overview
x950 Series Installation Guide for Standalone Switches Installation Overview The following steps summarize the installation procedure for the RKMT- SL01 Rack Mount Kit: 1. Verify the contents of the shipping box. Refer to “Unpacking the Shipping Container” on page 144. 2.
Page 144: Unpacking The Shipping Container
Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Unpacking the Shipping Container The contents of the shipping container are shown in Figure 85. Two inner rails - They attach to Two outer rails - They attach to the the sides of the switch.
Page 145 x950 Series Installation Guide for Standalone Switches Note Store the packaging material in a safe location. You should use the original shipping material if you need to return the kit to Allied Telesis. Warning When installing the outer and inner rails, and extension brackets, ensure the components are securely attached with the appropriate screws.
Page 146: Installing The Outer Rails On The Equipment Rack
Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Installing the Outer Rails on the Equipment Rack To install the outer rails to the equipment rack, perform the following procedure. 1. Locate the FRONT and REAR labels on the sides of the rails. You have to install the rails with the FRONT labels at the front of the equipment rack and the REAR Labels at the back.
Page 147 x950 Series Installation Guide for Standalone Switches Front of Equipment Rack Figure 87. Installing the Outer Rails on the Equipment Rack...
Page 148: Installing The Extension Brackets On The Inner Rails
Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Installing the Extension Brackets on the Inner Rails The kit comes with two extension brackets. Refer to Figure 88. Figure 88. Extension Brackets You use the brackets to recess the switch in the equipment rack. The maximum distance will depend on the depth of the rack.
Page 149 x950 Series Installation Guide for Standalone Switches Figure 90. Inserting an Inner Rail into an Outer Rail 2. Position the inner rail at the planned location for the front panel of switch in the sliding rack. Refer to Figure 91. Location of Front Panel of Switch Figure 91.
Page 150: Assembling The Extension Brackets
Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack 4. Remove the inner rail from the outer rail. Refer to Figure 93. Figure 93. Removing the Inner Rail 5. Go to “Assembling the Extension Brackets,” next. Assembling the Now that you know the approximate length for the extension brackets, you are ready to assemble them.
Page 151 x950 Series Installation Guide for Standalone Switches You adjust the lengths of the brackets by connecting them in different combinations. There are seven possible configurations. Refer to Figure 95. The default configuration is number 5. To adjust the extension brackets, perform the following procedure: 1.
Page 152 Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Note The long brackets have to be used between the fixed and short brackets. You cannot connect them directly to the inner rails. 2. Assemble the extension brackets to match the selected length in the table.
Page 153 x950 Series Installation Guide for Standalone Switches 4. To test the lengths of the extension brackets, slide the inner rails into the outer rails in the equipment rack. Refer to Figure 97. Figure 97. Testing the Inner Rails with the Extension Brackets 5.
Page 154: Installing The Inner Rails On The Switch
Figure 99. Inner Rail Screw Holes for the x950-28XSQ and x950-28XTQm Switches Figure 100 identifies the screw holes for the x950-52XSQ or x950-52XTQm switch and inner rails. Front of Switch Figure 100. Inner Rail Screw Holes for the x950-52XSQ and x950-...
Page 155 x950 Series Installation Guide for Standalone Switches Figure 101. Attaching the Inner Rails to the x950 Switch Go to “Installing the Switch in the Equipment Rack” on page 156.
Page 156: Installing The Switch In The Equipment Rack
Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Installing the Switch in the Equipment Rack After attaching the inner rails and extension brackets to the switch, perform the following procedure to install the switch in the sliding rack: Warning When installing or removing the switch from the rack, disconnect the media and power cables.
Page 157 x950 Series Installation Guide for Standalone Switches Figure 103. Affixing the Warning Labels 3. Slide the switch fully into the rack. 4. Tighten the two screws on the fixed brackets to secure the switch to the equipment rack. Refer to Figure 104. Figure 104.
Page 158 Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack Warning Pull the switch out slowly if you must remove it from the rack for maintenance. If you pull the switch out past the front of the rack posts, or if you pull it out too quickly, there is a risk that the weight of the switch will cause the sliding rail assemblies to fail and cause the switch to fall out.
Page 159: Chapter 9: Verifying And Configuring The Switch
Chapter 9 Verifying and Configuring the Switch This chapter contains the following procedures: “Powering On the Switch” on page 160  “Starting a Local Management Session” on page 164  “Verifying the Switch with AlliedWare Plus Commands” on page 166 ...
Page 160: Powering On The Switch
Chapter 9: Verifying and Configuring the Switch Powering On the Switch The procedure in this section explains how to power on the switch. If you have not installed the power supplies, refer to “Installing PWR600 AC Power Supplies” on page 88 or/and “Installing PWR600 DC Power Supplies”...
Page 161 x950 Series Installation Guide for Standalone Switches Figure 106. Connecting the AC Power Cord 2. Move the power cord into the restraining strap and secure the strap by feeding it into the tab slot. Refer to Figure 107. Tab Slot Figure 107.
Page 162: Powering On The Pwr600 Dc Power Supply
Chapter 9: Verifying and Configuring the Switch Figure 108. Connecting the Power Cord to an AC Power Source Note The illustration shows the North American power cord. Your power cord may be different. 4. If the switch has two AC power supplies, repeat this procedure to connect a power cord to the second power supply.
Page 163 x950 Series Installation Guide for Standalone Switches 5. If the switch has two DC power supplies installed, repeat this procedure to power on the second DC power supply. 6. If you have the PWR600 AC power supply installed on the switch, go to “Powering on the PWR600 AC Power Supply”...
Page 164: Starting A Local Management Session
Chapter 9: Verifying and Configuring the Switch Starting a Local Management Session After powering on the switch and waiting two minutes for it to initialize its management software, start a local management session using the Console port on the management panel, as explained in this section. Note The first management session of the switch can be either a local session, as explained in this section, or a remote session over your...
Page 165 x950 Series Installation Guide for Standalone Switches 3. Configure the VT-100 terminal or terminal emulation program as follows: Baud rate: 9600 bps  Data bits: 8  Parity: None  Stop bits: 1  Flow controller: None  Note The port settings are for a DEC VT100 or ANSI terminal, or an equivalent terminal emulator program.
Page 166: Verifying The Switch With Alliedware Plus Commands
3. Check the Status column. All components should have the status “OK.” For information about the command line interface, refer to the Software Reference for AT-x950 Switches on the Allied Telesis web site. 4. Go to “Disabling VCStack” on page 167.
Page 167: Disabling Vcstack
x950 Series Installation Guide for Standalone Switches Disabling VCStack The procedure in this section explains how to disable the VCStack feature so that you can use the unit as a stand-alone switch. In all likelihood you will not have to perform this procedure because the default setting for the feature is disabled.
Page 168 Chapter 9: Verifying and Configuring the Switch 5. Review the following items: If the Operational Status is “Stacking Hardware Disabled,” the  VCStack feature is already disabled on the switch. Go to “Configuring Ports for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or Breakout Cables”...
Page 169 x950 Series Installation Guide for Standalone Switches Figure 114. Returning to the Privileged Exec Mode 10. Enter the WRITE command to save your change in the configuration file. The switch displays the confirmation prompt in Figure 115. awplus# write Building configuration ... [OK] awplus# Figure 115.
Page 170: Configuring Ports For 40Gbps Qsfp+ Or 100Gbps Qsfp28 Transceivers, Or Breakout Cables
Configuring Ports for 40Gbps QSFP+ or 100Gbps QSFP28 Transceivers, or Breakout Cables Ports 25, 29, 33, and 37 on the x950-28XSQ and x950-28XTQm switches and ports 49, 53, 57, and 61 on the x950-52XSQ and x950-52XTQm switches support the following transceivers and cables: 40Gbps QSFP+ transceivers ...
Page 171 x950 Series Installation Guide for Standalone Switches This example configures ports 33 and 37 for 100Gbps QSFP28 transceivers: awplus(config)# platform portmode interface port1.0.33, port1.0.37 100g This example configures port 25 for a breakout cable: awplus(config)# platform portmode interface port1.0.25 10gx4 This example configures ports 25 and 29 for 40Gbps QSFP+ transceivers: awplus(config)# platform portmode interface...
Page 172: Saving Your Changes And Rebooting The Switch
Chapter 9: Verifying and Configuring the Switch Saving Your Changes and Rebooting the Switch After disabling the VCStack feature or configuring ports 25, 29, 33, and 37 or ports 49, 53, 57, and 61, you have to save your configuration changes and reboot the switch, as explained in the following procedure: 1.
Page 173: Chapter 10: Cabling The Networking Ports
Chapter 10 Cabling the Networking Ports This chapter contains the following procedures: “Cabling Twisted Pair Ports” on page 174  “Guidelines to Handling Twisted Pair or Fiber Optic Transceivers” on  page 175 “Installing Transceivers” on page 176  “Installing Direct Attach Cables” on page 182 ...
Page 174: Cabling Twisted Pair Ports
Chapter 10: Cabling the Networking Ports Cabling Twisted Pair Ports This section applies to the twisted pair ports on the following products: x950-28XTQm Switch  x950-52XTQm Switch  XEM2-8XSTm Line Card  XEM2-12XT Line Card  XEM2-12XTm Line Card ...
Page 175: Guidelines To Handling Twisted Pair Or Fiber Optic Transceivers
For a list of supported transceivers, refer to the product data sheet  on the Allied Telesis web site. The operational specifications and fiber optic cable requirements  are provided in the documents included with the transceivers.
Page 176: Installing Transceivers
Ports 49, 53, 57, and 61 on (328 ft) with 12-strand OM3 or OM4 fiber the x950-52XSQ and optic cable, respectively. Requires a MPO x950-52XTQm Switches pluggable optical connector. - QSFP28LR4 transceiver - Operating range of 2m (6.6 ft) to 10km (6.2 mi). Requires single- mode fiber optic cable with a duplex LC connector.
Page 177 5CU breakout cables in lengths of 3 and 5 the x950-52XSQ and meters, respectively. x950-52XTQm Switches SP10T and SP10TM transceivers with RJ-45 connections require that adjacent ports be kept empty to prevent overheating. Refer to Figure 119. Figure 119. SP10T Transceivers Table 34 lists the types of transceivers supported by optional XEM2 Line Cards.
Page 178 Chapter 10: Cabling the Networking Ports Table 34. Transceivers for the Optional XEM2 Ethernet Line Cards Ethernet Line Card Transceiver XEM2-12XS 1Gbps SFP or 10Gbps SFP+ transceivers: - 1Gbps SX or LX SFP fiber optic transceivers - 10Gbps SR or LR SFP+ fiber optic transceivers - 10Gbps one meter SP10TW1, three meter SP10TW3, and seven meter...
Page 179 x950 Series Installation Guide for Standalone Switches Please review “Guidelines to Handling Twisted Pair or Fiber Optic Transceivers” on page 175 before performing the procedure. Your transceivers may look different than those shown in the following illustrations. Warning The temperature of an operational transceiver can exceed 70° C (158°...
Page 180 Chapter 10: Cabling the Networking Ports 40Gbps transceivers in XEM2-4QS Line Cards - refer to  Figure 121. Figure 121. Installing 40Gbps Fiber Optic Transceivers in XEM2-4QS Line Cards 100Gbps QSFP28 transceivers for base ports 25 to 37: refer to ...
Page 181 x950 Series Installation Guide for Standalone Switches 100Gbps QSFP28 transceivers for XEM2-1CQ Line Card: refer to  Figure 123. Figure 123. Installing 100Gbps QSFP28 Transceivers in XEM2-1CQ Line Cards Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step.
Page 182: Installing Direct Attach Cables
Chapter 10: Cabling the Networking Ports Installing Direct Attach Cables Table 11 on page 35 lists the direct attach cables for the base ports and XEM2 Line Cards. They offer an economical way to add 10Gbps, 40Gbps, or 100Gbps connections over short distances. To install direct attach cables, perform the following procedure: 1.
Page 183 x950 Series Installation Guide for Standalone Switches Release Tab Figure 125. Attaching QSFPCU Cables 5. Connect the other end of the cable into a compatible port on another network device. 6. Repeat this procedure to install additional direct attach cables. Note To remove a cable from the port, gently push on the connector, pull on the release tab, and slide the connector from the port.
Page 184 Chapter 10: Cabling the Networking Ports...
Page 185: Chapter 11: Replacing Modules
Chapter 11 Replacing Modules This chapter contains the following procedures: “Replacing XEM2 Ethernet Line Cards” on page 186  “Replacing PWR600 AC Power Supplies” on page 191  “Replacing PWR600 DC Power Supplies” on page 196  “Replacing FAN05 Modules” on page 199 ...
Page 186: Replacing Xem2 Ethernet Line Cards
 becoming fully operational after being powered on. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing line cards. For instructions, refer to the Software Reference for x950 Switch, AlliedWare Plus Operating System.
Page 187 x950 Series Installation Guide for Standalone Switches Note 100Gbps transceivers for the XEM2-1CQ line card have handles. Always use the handles when installing or removing transceivers. 4. Use a #2 Phillips-head screwdriver to loosen the two screws on the faceplate of the card. Refer to Figure 126. Figure 126.
Page 188 Chapter 11: Replacing Modules Figure 127. Disconnecting an Ethernet Line Card from the Switch 6. Carefully slide the card from the switch. Refer to Figure 128. Figure 128. Sliding an Ethernet Line Card from the Switch...
Page 189 x950 Series Installation Guide for Standalone Switches 7. If you are not installing the line card in another switch, store it in its anti-static bag and shipping container. Refer to Figure 129. Figure 129. Placing the Ethernet Line Card in its Anti-static Bag 8.
Page 190 Chapter 11: Replacing Modules 10. Tighten the two screws to secure it to the switch. Refer to Figure 131. Figure 131. Tightening the Two Screws on the Line Card Blank Panel...
Page 191: Replacing Pwr600 Ac Power Supplies
PSU A. The procedure is the same for replacing a power supply in slot PSU B. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing power supplies. For instructions, refer to the Software Reference for x950 Switch, AlliedWare Plus Operating System.
Page 192 Chapter 11: Replacing Modules Release Tab Figure 133. Opening the Restraining Strap on the Power Supply 3. Disconnect the power cord from the power supply. Refer to Figure 134. Figure 134. Disconnecting the Power Cord from the Power Supply...
Page 193 x950 Series Installation Guide for Standalone Switches 4. Press the release lever to the right and pull on the handle to release the power supply from the internal connector in the switch. Release Lever Figure 135. Removing the Power Supply 5.
Page 194 Chapter 11: Replacing Modules Figure 136. Removing a Power Supply 6. Do one of the following: To install a new power supply, refer to “Installing PWR600 AC  Power Supplies” on page 88 or “Replacing PWR600 DC Power Supplies” on page 196for instructions. If you are not installing a new power supply, continue with the next ...
Page 195 x950 Series Installation Guide for Standalone Switches Figure 137. Installing the Blank Power Supply Cover...
Page 196: Replacing Pwr600 Dc Power Supplies
This section contains the procedure for removing or replacing PWR600 DC Power Supplies. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing power supplies. For instructions, refer to the Software Reference for x950 Switch, AlliedWare Plus Operating System.
Page 197 x950 Series Installation Guide for Standalone Switches Figure 139. Accessing the Connecting Screws 4. Loosen all three screws for the ground wire, positive (+) and negative (-) wires. 5. Remove all three wires. 6. Press the release lever to the right and pull on the handle to release the power supply from the internal connector in the switch.
Page 198 Chapter 11: Replacing Modules Figure 141. Removing a DC Power Supply 8. Do one of the following: To install a new power supply, refer to “Installing PWR600 AC  Power Supplies” on page 88 or “Installing PWR600 DC Power Supplies” on page 92 for instructions. If you are not installing a new power supply, continue with the next ...
Page 199: Replacing Fan05 Modules
For background information, refer to “FAN05 Cooling Fan” on page 43. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before replacing a fan module. For instructions, refer to the Software Reference for x950 Switches.
Page 200 Chapter 11: Replacing Modules 2. Carefully pull on the handle to disconnect the line card from the internal connector in the switch. Refer to Figure 143. Figure 143. Disconnecting the FAN05 Module from the Switch 3. Slide the fan module out of the switch. Refer to Figure 144. Figure 144.
Page 201: Installing Fan Modules
x950 Series Installation Guide for Standalone Switches Installing Fan This procedure requires the following tool: Modules #2 Phillips-head screwdriver (not provided)  The illustrations show the installation of a fan module in FAN B slot on the back panel. The procedure is the same for installing a module in FAN A slot.
Page 202 Chapter 11: Replacing Modules Figure 146. Aligning the FAN05 Module in the Switch Slot 3. When you feel the module make contact with the internal connector, gently press on both sides to seat the module on the connector. Refer to Figure 147. Figure 147.
Page 203 x950 Series Installation Guide for Standalone Switches Figure 148. Tightening the Two Captive Screws on the FAN05 Module 5. To confirm the operations of the new fan module, start a local or remote management session and enter the SHOW SYSTEM ENVIRONMENT command in the User Exec or Privileged Exec mode.
Page 204 Chapter 11: Replacing Modules...
Page 205: Chapter 12: Troubleshooting
This chapter contains suggestions on how to troubleshoot problems with the switch. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: The unit is not receiving power. All the port LEDs and Switch ID LED are off, and the fans are not operating.
Page 206 Problem 4: A 40Gbps or 100Gbps fiber optic transceiver in port 25, 29, 33, or 37 on the x950-28XSQ or x950-28XTQm switch or port 49, 53, 57, or 61 on the x950-52XSQ or x950-52XTQm switch cannot establish a link with a network device.
Page 207 Problem 5: A 4x10Gbps breakout cable in port 25, 29, 33, or 37 on the x950-28XSQ or x950-28XTQm switch, or port 49, 53, 57, or 61 on the x950-52XSQ or x950-52XTQm switch cannot establish links with network devices. Solutions: Try the following: Check that the cable is fully inserted in the port in the switch.
Page 208 Chapter 12: Troubleshooting Problem 8: A twisted pair port on x950-28XTQm or x950-52XTQm switches, or the XEM2-12XT or XEM2-12XTm Line Card cannot establish a link with a network device. Solutions: Try the following: Verify that the network device connected to the twisted pair port is ...
Page 209 Solutions: One of the following problems has occurred: A cooling fan has failed.  The internal temperature of the switch is outside the normal  operating range and the unit might shut down. Contact your Allied Telesis sales representative for assistance.
Page 210 Chapter 12: Troubleshooting...
Page 211: Appendix A: Technical Specifications
Appendix A Technical Specifications This appendix contains the following sections: ”Physical Specifications” on page 212  ”Environmental Specifications” on page 216  ”Power Specifications” on page 217  ”Certifications” on page 227  ”RJ-45 Twisted Pair Port Pinouts” on page 228 ...
Page 212: Physical Specifications
4.4 cm x 44.0 cm x 44.5 cm x950-28XTQm (1.7 in. x 17.3 in. x 17.5 in.) x950-52XSQ 4.4 cm x 44.0 cm x 44.7 cm x950-52XTQm (1.7 in. x 17.3 in. x 17.6 in.) XEM2-8XSTm Line Card 4.0 x 13.0 x 16.6 cm XEM2-12XT Line Card (1.57 x 5.11 x 6.53 in.)
Page 213 33.83 mm (1.332 in.) 35.84 mm (1.411 in.) Figure 150. Switch Depth and Locations of Bracket Holes for the x950-28XSQ and x950-28XTQm Switches The side dimension and bracket holes for the x950-52XSQ and x950-52XTQm Switches are shown in Figure 151 on page 214.
Page 214 Appendix A: Technical Specifications Depth (x950-52XSQ and x950-52XTQm) 44.7 cm (17.6 in.) Bracket Hole Locations (x950-52XSQ and x950-52XTQm) Front 0.00 mm (0.00 in.) 7.85 mm (0.309 in.) 9.78 mm (0.385 in.) 33.83 mm (1.332 in.) 35.84 mm (1.411 in.) Rear Figure 151.
Page 215 Switch 7.21 kg (15.90 lb.) x950-28XTQm Switch 7.33 kg (16.15 lb.) x950-52XSQ Switch 7.35 kg (16.2 lb.) x950-52XTQm Switch 8.20 kg (18.08 lb.) XEM2-8XSTm Line Card 0.70 kg (1.54 lb.) XEM2-12XT Line Card 0.75 kg (1.65 lb.) XEM2-12XTm Line Card 1.04 kg (2.3 lb.)
Page 216: Environmental Specifications
Appendix A: Technical Specifications Environmental Specifications Table 38 lists the environmental specifications of the switches. Table 38. Environmental Specifications Operating Temperature 0° C to 45° C (32° F to 113° F) (with QSFP28 transceivers) Operating Temperature 0° C to 50° C (32° F to 122° F) (without QSFP28 transceivers) Storage Temperature -25°...
Page 217: Power Specifications
x950 Series Installation Guide for Standalone Switches Power Specifications This section contains the maximum power consumption values and input voltages. Maximum Power Consumptions Table 39 lists the maximum power consumptions for the x950-28XSQ Switch. Table 39. Maximum Power Consumptions (Watts) for the x950-28XSQ Switch Number of Maximum...
Page 218 Appendix A: Technical Specifications Table 39. Maximum Power Consumptions (Watts) for the x950-28XSQ Switch (Continued) Number of Maximum x950-28XSQ Switch and Line PWR600 Power Power Card Supplies Consumption Switch plus XEM2-1CQ Card 213.63 W 238.19 W 209.36 W 226.04 W Switch plus XEM2-12XTm Card 239.96 W 261.64 W...
Page 219 x950 Series Installation Guide for Standalone Switches Table 40 lists the maximum power consumptions for the x950-28XTQm Switch. Table 40. Maximum Power Consumptions (Watts) for the x950-28XTQm Switch Number of Maximum x950-28XTQm Switch and Line PWR600 Power Power Card Supplies Consumption Switch - No card 234.55 W...
Page 220 Appendix A: Technical Specifications Table 40. Maximum Power Consumptions (Watts) for the x950-28XTQm Switch (Continued) Number of Maximum x950-28XTQm Switch and Line PWR600 Power Power Card Supplies Consumption Switch plus XEM2-12XTm Card 267.89 W 284.63 W 254.83 W 269.90 W Switch plus XEM2-12XS v2 Card AC 261.97 W 280.37 W...
Page 221 Series Installation Guide for Standalone Switches Table 42 lists the maximum power consumptions for the x950-52XTQm Switch. Table 42. Maximum Power Consumptions (Watts) for the x950-52XTQm Switch Number of Maximum PWR600 Power Power Supplies Consumption 274.04 W 291.09 W x950-52XTQm Switch 263.10 W...
Page 222 50/60 Hz (per inputx2) x950-52XSQ Switch 100-240 VAC , 4A maximum, 40-60V DC, 6.0A (per Input x2) 50/60 Hz (per inputx2) x950-52XTQm Switch 100-240 VAC , 4A maximum, 40-60V DC, 6.0A (per Input x2) 50/60 Hz (per inputx2) PWR600 AC 100-240 VAC , 8.7A maximum,...
Page 223 x950 Series Installation Guide for Standalone Switches Maximum Power Supply Efficiency Table 46 lists the maximum power supply efficiency. Table 46. Maximum Power Supply Efficiency (Based on 100V Input Voltage) PWR600 AC Power Supply Up to 85% Heat Dissipations Table 47 lists the heat dissipations for the x950-28XSQ Switch. Table 47.
Page 224 Appendix A: Technical Specifications Table 47. Heat Dissipations for the x950-28XSQ Switch (Continued) Number of Heat Dissipation x950-28XSQ Switch and PWR600 Power (British Thermal Line Card Supplies Units/Hour) Switch plus XEM2-1CQ 729.01 BTU/hr Card 812.82 BTU/hr 714.43 BTU/hr 771.36 BTU/hr Switch plus XEM2-12XTm 818.86 BTU/hr Card...
Page 225 x950 Series Installation Guide for Standalone Switches Table 48. Heat Dissipations for the x950-28XTQm Switch (Continued) Number of Heat Dissipation x950-28XTQm Switch and PWR600 Power (British Thermal Line Card Supplies Units/Hour) Switch plus XEM2-4QS 864.01 BTU/hr Card 927.10 BTU/hr 821.00 BTU/hr 874.12 BTU/hr Switch plus XEM2-12XT 957.23 BTU/hr...
Page 226 (British Thermal Supplies Units/Hour) 840.36 BTU/hr 908.13 BTU/hr x950-52XSQ Switch 784.53 BTU/hr 844.25 BTU/hr Table 50 list the heat dissipations for the x950-52XTQm Switch. Table 50. Heat Dissipations for the x950-52XTQm Switch Number of Heat Dissipation PWR600 Power (British Thermal Supplies Units/Hour) 935.16 BTU/hr...
Page 227: Certifications
x950 Series Installation Guide for Standalone Switches Certifications Table 51 lists the product certificates. Table 51. Product Certifications EMI (Emissions) FCC Class A CISPR 22 Class A EN 55032 Class A VCCI Class A ICES-003 Class A EMC (Immunity) EN 55024 EN 61000-3-2 EN 61000-3-3 Electrical and Laser Safety...
Page 228: Twisted Pair Port Pinouts
Appendix A: Technical Specifications RJ-45 Twisted Pair Port Pinouts Figure 152 illustrates the pin layout of the RJ-45 connectors on the following products: x950-28XTQm Switch  x950-52XTQm Switch  XEM2-8XSTm Line Card  XEM2-12XT Line Card  XEM2-12XTm Line Card ...
Page 229 x950 Series Installation Guide for Standalone Switches Table 53 lists the pin signals at 1/2.5/5/10Gbps. Table 53. Pin Signals on Twisted Pair Ports at 1/2.5/5/10Gbps Pair Signal TX and RX+ TX and RX- TX and RX+ TX and RX+ TX and RX- TX and RX- TX and RX+ TX and RX-...
Page 230: Style Serial Console Port Pinouts
Appendix A: Technical Specifications RJ-45 Style Serial Console Port Pinouts Table 54 lists the pin signals of the RJ-45 style serial Console port. Table 54. RJ-45 Style Serial Console Port Pin Signals Signal Looped to pin 8. Looped to pin 7. Transmit Data Ground Ground...

This manual is also suitable for:

X950-28xsq X950-28xtqm X950-52xsq X950 series Xem2-4qs Xem2-1cq ... Show all

Allied Telesis x950-52XTQm Installation Manual

Chapter 1: Overview

Chapter 2: XEM2 Ethernet Line Cards

Chapter 3: Beginning the Installation

Chapter 4: Installing Power Supplies and Optional XEM2 Line Card

Chapter 5: Installing the Switch on a Table

Chapter 6: Installing the Switch in an Equipment Rack

Chapter 7: Installing the Switch on a Wall

Chapter 8: Installing the Switch in the RKMT-SL01 Sliding Rack

Chapter 9: Verifying and Configuring the Switch

Chapter 10: Cabling the Networking Ports

Chapter 11: Replacing Modules

Chapter 12: Troubleshooting

Appendix A: Technical Specifications

Quick Links

Related Manuals for Allied Telesis x950-52XTQm

Summary of Contents for Allied Telesis x950-52XTQm

This manual is also suitable for:

Table of Contents
