Installation and Assembly
4.7.2
PIN
1
2
3
4
Shield
PC6000-3/4 is a 3 m (13.12 ft) long, pre-assem-
bled power supply and trigger cable.
4.7.3
Pin
1
2
3
4
Shield
Analog grounds are connected internally.
SCACx/4 is a 3 m (13.12 ft) long, 4-wire output
cable. It is supplied as an optional accessory.
capaNCDT 6228 / 6238

Pin Assignment Supply, Trigger

Color Description
PC6200-3/4
Brown +24 VDC Supply
White GND Supply
Yellow Trigger IN+, TTL level
Green Trigger IN-

Pin Assignment Analog Output

Color
Description
SCACx/4
V ,
Brown
OUT
(Load min. 10 kOhm)
I ,
Yellow
OUT
(Load max. 500 Ohm)
Gray Analog ground
White Analog ground
4 1
2
3
View on solder pin side, Power supply input
4-pole ODU female on controller, 4-pole
cable connector male cable connector
View on solder pin Signal output on con-
side, 4-pole male troller, 4-pole male cable
cable connector
ETHERNET
POWER/TRIG.
DT62xx
Range
LP Filter
Zero
Zero
SENSOR/CP
SIGNAL OUT
DL62xx
connector
