Installation and Assembly
capaNCDT 6228 / 6238
Put on the right housing cover (3).
Screw the sleeve nuts (4b) on the threaded rods on the right side of the controller and tighten the sleeve
nuts.
5
Wiring preceding demodulator
module
6
Wiring following demodulator
module
5
6
5
Fig. 14 Wiring demodulator modules
