Functional Principle, Technical Data
Controller type
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Weight
Compatibility
No. of measurement
channels
1) RMS noise relates to mid of measuring range
2) Applies only to controller. The overall linearity of the measuring channel is given by adding up the values for the controller and the
sensor.
Controller type
Sensors
Sensor cable standard
Sensor cable (matched)
Trigger
FSO = Full Scale Output
capaNCDT 6228 / 6238
DT6228
0.75 mm / 10 ... 500 Hz in 3 axes, 2 directions each and 10 cycles each
2 g / 10 ... 500 Hz in 3 axes, 2 directions and 10 cycles each
approx. 720 g
+ 185 g / demodulator
compatible with all capaNCDT sensors
DT62x8 with DL6228
all sensors suitable
CCm1.4x; CCg2.0x
≤ 8 m (with CCgxx) ≤ 5.6 m (with
CCmxx)
TTL, 5 V
DT6238
IP40
approx. 720 g
+ 210 g / demodulator
max. 4
