Installation and Assembly
4.4
4.4.1
DT 62x8
Fig. 11 Dimensional drawing controller
Dimensions in mm (inches), not to scale
capaNCDT 6228 / 6238
Controller
Basic Unit, Demodulator Module
25 (.98)
34 (1.34)
DL 6228
125 (4.92)
Page 27
