  • Page 1 Operating Instructions optoNCDT 1320 ILD 1320-10 ILD 1320-500 ILD 1320-25 ILD 1320-50 ILD 1320-100 ILD 1320-200...
  • Page 2 Intelligent laser optical displacement measurement MICRO-EPSILON MESSTECHNIK GmbH & Co. KG Koenigbacher Str. 15 94496 Ortenburg / Germany Tel. +49 (0) 8542 / 168-0 Fax +49 (0) 8542 / 168-90 e-mail info@micro-epsilon.com www.micro-epsilon.com...

  • Page 3: Table Of Contents

    Temperature Influences ....................20 5.1.2.4 Mechanical Vibration ....................20 5.1.2.5 Movement Blurs ......................20 5.1.2.6 Surface Roughness ....................21 5.1.2.7 Angle Influences ......................22 5.1.3 Optimizing the Measuring Accuracy ................... 23 Mounting, Dimensions ..........................24 Indicator Elements at Sensor ........................26 optoNCDT 1320...
  • Page 4 Triggering ............................50 7.4.4.1 General ........................50 7.4.4.2 Signal Processing - Value Output Trigger ..............52 7.4.5 Peak Selection ..........................52 7.4.6 Error Handling ..........................52 7.4.7 Zeroing and Mastering ......................... 53 7.4.7.1 Zeroing, Mastering with Select Key ................54 optoNCDT 1320...
  • Page 5 Digital Interfaces RS422 ......................77 Preliminary Remarks ............................77 Measurement Data Format ..........................77 Conversion of the Binary Data Format ......................78 Cleaning ..........................79 Software Support with MEDAQLib ..................79 Disclaimer ..........................80 Service, Repair ........................80 optoNCDT 1320...
  • Page 6 A 3.3.10.2 UNIT, Web Interface ..................... 95 A 3.3.10.3 MFIFUNC, Function Selection Multifunctional Input ........... 95 A 3.3.10.4 ERROROUT1, Activate Error Output ................95 A 3.3.10.5 ERRORLEVELOUT1, Output Level Digital Output ............96 A 3.3.10.6 ERRORLIMIT ....................... 96 optoNCDT 1320...
  • Page 7 Control Menu ............................... 104 A 4.1 Tab Home ..............................104 A 4.2 Tab Settings ..............................104 A 4.2.1 Inputs ............................104 A 4.2.2 Signal Processing ........................105 A 4.2.3 Outputs ............................107 A 4.2.4 System Settings .......................... 109 optoNCDT 1320...
  • Page 8 1320...

  • Page 9: Safety

    Caution - use of controls or adjustments or performance of procedures other than those specified may cause harm. Connect the power supply and the display/output device according to the safety regulations for electrical equip- ment. > Risk of injury > Damage to or destruction of the sensor optoNCDT 1320 Page 9...

  • Page 10: Notes On Ce Marking

    Avoid exposure of sensor to aggressive media (detergents, cooling emulsions). > Damage to or destruction of the sensor Notes on CE Marking The following apply to the optoNCDT 1320: - EU directive 2014/30/EU - EU directive 2011/65/EU Products which carry the CE mark satisfy the requirements of the EU directives cited and the relevant applicable harmonized Euro- pean standards (EN).

  • Page 11: Notes On Ukca Marking

    The UKCA Declaration of Conformity and the technical documentation are available to the responsible authorities according to the UKCA Directives. Intended Use - The optoNCDT 1320 system is designed for use in industrial and laboratory applications. - It is used ƒ for measuring displacement, distance, position and thickness ƒ...

  • Page 12: Laser Safety

    COMPLIES WITH 21 CFR 1040.10 AND 1040.11 EXCEPT FOR CONFORMANCE WITH IEC 60825-1 P 1mW; =670nm ED. 3., AS DESCRIBED IN LASER NOTICE NO. 56, DATED MAY 8, 2019. Fig. 1 Laser labels on the sensor cable optoNCDT 1320 Page 12...
  • Page 13 Fig. 3 Sensor cable and sensor with laser sign, ILD1320 If both warning labels are covered over when the unit is installed, the user must ensure that supplementary labels are applied. Please observe national regulations, e. g., Laser Notice No. 50 for the USA. optoNCDT 1320 Page 13...

  • Page 14: Functional Principle, Technical Data

    Functional Principle, Technical Data Short Description The optoNCDT 1320 uses the principle of optical triangulation, that is, a visible, modulated point of light is projected onto the target surface. The diffuse part of the reflection of this point of light is displayed depending on distance on a position-resolving element (CMOS) by an receiver optic which is arranged to the optical axis of the laser beam in a defined angle.

  • Page 15: Auto Target Compensation (Atc)

    Functional Principle, Technical Data Auto Target Compensation (ATC) The Auto Target Compensation (ATC) enables stable compensation independent of color and brightness of the measuring object. Also small objects can be detected reliably thanks to the small measuring spot. optoNCDT 1320 Page 15...

  • Page 16: Technical Data

    1 x HTL multifunction input: trigger in, zero setting, mastering, teach Digital interface RS422 (16 bit) / EtherCAT / PROFINET / EtherNet/IP Analog output 4 ... 20 mA (16 bit; freely scalable within the measuring range) optoNCDT 1320 Page 16...
  • Page 17 SMR = Start of measuring range, MMR = Mid of measuring range, EMR = End of measuring range [1] Factory setting 2 kHz, modifying the factory setting requires the IF2001/USB converter (see accessories) [2] FSO = Full Scale Output; the specified data apply to white, diffuse reflecting surfaces (Micro-Epsilon reference ceramic for ILD sensors) [3] Measuring rate 1 kHz, median 9 [4] The specified value is only achieved by mounting on a metallic sensor holder.

  • Page 18: Delivery

    Chap.3.3. They can be recognized by the serial number with the following structure: - 10xxxxxx = ILD1320-10, ILD1320-25, ILD1320-50 - 40xxxxxx = ILD1320-100, ILD1320-200, ILD1320-500 Serial numbers for sensors with the old design can be recognized by the following structure: JJMMxxxx (J = year, M = month) optoNCDT 1320 Page 18...

  • Page 19: Installation

    Chap.3.2. Dark or shiny objects being measured, e.g. black rubber, may require longer exposure times. The exposure time is dependent on the measuring rate and can only be increased by reducing the sensor’s measuring rate. optoNCDT 1320 Page 19...

  • Page 20: Error Influences

    Light from other Sources Thanks to their integrated optical interference filters the optoNCDT 1320 sensors offer outstanding performance in suppressing light from other sources. However, this does not preclude the possibility of interference from other light sources if the objects being mea- sured are shiny and if lower measuring rates are selected.

  • Page 21: Surface Roughness

    Ceramic reference surface Structured surface Recommendation for parameter choice: The averaging number should be selected in such a way that a surface area the size of which is comparable to those with mechanical measurements is averaged. optoNCDT 1320 Page 21...

  • Page 22: Angle Influences

    These influences have to be explicitly considered when scanning profiled surfaces. Basically the angle behavior of triangulation is li- able to the reflectivity of the measuring object surface. X-axis Y-axis Angle Fig. 6 Measurement errors through tilting with diffuse reflection optoNCDT 1320 Page 22...

  • Page 23: Optimizing The Measuring Accuracy

    In case of bore holes, blind holes and edges in the surface of moving targets the sensor must be arranged in such a way that the edges do not obscure the laser spot. incorrect correct (shadow) Fig. 8 Sensor arrangement for holes and ridges optoNCDT 1320 Page 23...

  • Page 24: Mounting, Dimensions

    Mounting, Dimensions The optoNCDT 1320 sensor is an optical system for measurements with micrometer accuracy. The laser beam must be directed perpendicularly onto the surface of the target. In case of misalignment it is possible that the measurement results will not always be accurate.
  • Page 25 EMR = End of measuring range their reflections FSO = Full scale output (.08) (.31) Fig. 10 Dimensional drawing and free space for optics and optical free space A: 2x M3 for direct fastening or 2x M2 for bolt connection optoNCDT 1320 Page 25...

  • Page 26: Indicator Elements At Sensor

    The programmable touch key select calls up the functions Masters and Teaching. By factory default this key is only active for the first 5 minutes after power up. After that it will be automatically locked. The keylock can be programmed via internal websites or ASCII commands. optoNCDT 1320 Page 26...

  • Page 27: Electrical Connections

    The different periphery devices can be connected to the sensor by the illustrated connections. The converters IF2001/USB and IF2004/USB also supply the supply voltage (24 VDC) of the sensor. Power to the converters is sup- plied e. g. by the optional power supply PS 2020. optoNCDT 1320 Page 27...
  • Page 28 IF2001/USB, RS422 USB converter IF2004/USB IF2035-PROFINET / -EIP / -EtherCAT one SPS, ILD 1320 or the like Functional input: trigger Switch, key, PLC or the like Switching input laser On/Off Fig. 12 Max. sensor channels on the peripheral devices optoNCDT 1320 Page 28...

  • Page 29: Pin Assignment

    4 ... 20 mA Load = 500 Ohm: U 2 ... 10 V with U > 17 V Load blue Ground potential Supply and signal ground Connector housing Shield Sensor housing Connect with potential equalization optoNCDT 1320 Page 29...

  • Page 30: Supply Voltage

    11 ... ence at the same time. 30 VDC ILD1320 MICRO-EPSILON recommends using an optional avail- able power supply unit PS2020 for the sensor. blue Ground Fig. 13 Connection of supply voltage 5.4.4...

  • Page 31: Rs422 Connection With Usb Converter If2001/Usb

    1 ... 5 V at U > 11 V 11... white R = 500 Ohm: 100 nF 30 VDC blue 2 ... 10 V at U > 17 V blue Fig. 16 Wiring for voltage output optoNCDT 1320 Page 31...

  • Page 32: Multifunctional Input

    High level≥ 8 V (max 30 V), Internal pull up resistance, an open input is noticed as High. violet Connect the input with GND to trigger the function. blue Fig. 17 Electrical wiring for multifunctional input optoNCDT 1320 Page 32...

  • Page 33: Digital Output

    PNP (High side) appr. GND Push-Pull Push-Pull, negated Fig. 19 Switching characteristic digital output The digital output is activated when measuring object is missing, measuring object too close/too far or when no valid measurement value can be determined. optoNCDT 1320 Page 33...

  • Page 34: Sensor Cable

    Never lay signal leads next to or together with power cables or pulse-loaded cables (e.g. for drive units and solenoid valves) in a bundle or in cable ducts. Always use separate ducts. Recommended strand cross-section for self-made connection cables: ≥ 0.14 mm² (AWG 25). optoNCDT 1320 Page 34...

  • Page 35: Operation

    Operation Operation Getting Ready for Operation Install and assemble the optoNCDT 1320 in accordance with the instructions set out, see Chap.5. Connect the sensor with the indicator or monitoring unit and the power supply. The laser diode in the sensor can only be activated if at the input Laser on/off Pin 8 is connected with Pin 12, see Chap.5.4.4.

  • Page 36: Parameterizing Via Web Interface

    The operation is only possible as long as an RS422 connection to the sensor exists. The sensor is connected to a PC/note- book via a RS422 converter, supply voltage persist. sensorTOOL by MICRO-EPSILON is a piece of software that you can use to apply settings to the sensor and to view and document measurement data.

  • Page 37: Access Via Web Interface

    Depending on the selected measuring rate and the PC used, measured values may be reduced dynamically in the display. That is, not all measured values are transmitted to the web interface for display and saving. optoNCDT 1320 Page 37...

  • Page 38: Calibration Protocol

    The area Diagram type enables the change between graphical display of the measurement value or the video signal. 6.2.3 Calibration Protocol You can download the calibration protocol under Download / Infor- mation in the Info menu item. optoNCDT 1320 Page 38...

  • Page 39: Presets, Setups, Measurement Configuration, Signal Quality

    Home > Measurement configuration You can select a setup in the tab Home > Measurement configuration or Settings in menu System settings > Load & save A setup can be stored permanently in the controller, see Chap.7.6.4. optoNCDT 1320 Page 39...
  • Page 40 After programming all the settings are to be stored permanently in a set of parameters. The next time you turn on the sensor they are available again. Therefore use the button Save settings. 1) Available for the sensor models ILD1320-10/25/50. optoNCDT 1320 Page 40...

  • Page 41: Measurement Presentation Via Web Browser

    Pause/Start interrupts or starts recording. Save opens the Windows selection dialog for file name and storage location to save the last 10,000 values in a CSV file (separation with semicolon). This function starts or stops a relative measurement. The master value can also be defined in a submenu here. optoNCDT 1320 Page 41...
  • Page 42 If you leave the diagram display in a separate tab or window of the browser running, you do not have to restart the description each time. Click the button Start, for starting the display of the measurement results. optoNCDT 1320 Page 42...

  • Page 43: Video Signal Via Web Browser

    Pause/Start interrupts or starts recording. Save opens the Windows selection dialog for file name and storage location to save the last 10,000 values in a CSV file (separation with semicolon). This function starts or stops a relative measurement. The master value can also be defined in a submenu here. optoNCDT 1320 Page 43...
  • Page 44 By displaying the video signal, you can detect effect of the adjustable measurement task (target material), choice of peak and possible interfering signals by means of reflections. There is no linear relationship between the position of the peaks in the video signal and the output measurement value. optoNCDT 1320 Page 44...

  • Page 45: Programming Via Ascii Commands

    Each cycle takes 500 µs at a measuring rate of 2 kHz. The measured value N is available at the output after three cycles. The delay between acquisition and output is therefore 1500 µs. As the processing in the cycles occurs parallel, after another 500 µs, the next measured value (N+1) is output. optoNCDT 1320 Page 45...

  • Page 46: Set Sensor Parameter

    If you do not save the programming permanently in the sensor, you lost the settings after turning off the sensor. Overview Parameter The following parameters can be set or changed in the optoNCDT 1320, see tab Settings. Inputs Laser on/off, Multifunctional input, Key function...

  • Page 47: Inputs

    You can find references to the chosen setting below. The menus for the area Signal processing are located in the left part. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 47...

  • Page 48: Measurement Task

    This can also be seen in the diagram distance values (Meas) by means of the different distance values for the respective measurement tasks. 1) Available for the sensor models ILD1320-10/25/50. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 48...

  • Page 49: Measuring Rate

    With a maximum measuring rate of 4 kHz the CMOS element is exposed 4,000 times per second. The lower the measuring rate, the higher maximum exposure time. Measuring rate is set to 2 kHz ex works. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 49...

  • Page 50: Triggering

    Triggering 7.4.4.1 General The optoNCDT 1320 measurement output is controllable through an external trigger signal or a command. Triggering affects the ana- log and digital output. The measurement value at the time of triggering is output delayed, see Chap.6.5. - Triggering does not influence the timing so that between the trigger event (level change) and the start of output always lie 3 cycles + 1 cycle (Jitter).
  • Page 51 After the trigger event the sensor outputs the preset number of measurement values or starts a continuous measure- ment value output. If “0“ is selected for the number of measurement values, the sensor stops the triggering and the continuous value output. Measurement output can also be stopped by means of a command. optoNCDT 1320 Page 51...

  • Page 52: Signal Processing - Value Output Trigger

    After expiry of the chosen number an error value is output. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 52...

  • Page 53: Zeroing And Mastering

    An invalid master value, e. g. no peak available, will be acknowledged with the E602 Master value is out of range error. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 53...

  • Page 54: Zeroing, Mastering With Select Key

    1) The key Select remains without effect since key lock is active. 2) The master value is not applied when LED State is red, flash frequency 8 Hz for 2 s. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 54...

  • Page 55: Zeroing, Mastering With Hardware Input

    The function zeroing/mastering can be applied successive in several times. Between repeating the zeroing/mastering function a pause of 1 s is required. The zeroing/mastering function can also be combined with the select key. 1) With red State LED, the master value is not accepted, flashes with 8 Hz for 2 s. optoNCDT 1320 Page 55...

  • Page 56: Outputs

    Output Interface Web interface / Analog / RS422 Decides via the used interface for measurement output. A parallel measurement output via multiple channels is not possible. When choosing web interface measure- ment values are not output via RS422 or current output. optoNCDT 1320 Page 56...

  • Page 57: Digital Output, Rs422

    MV ≥ MP - 0.5MR: [-MP + MV; MR - MP+ MV] Exposure time 18 bits = digital value [1; 262143] [µs] ET = exposure time [µs] [0.1; 26214.3] Intensity 16 bits = digital value [0; 65472] 16368 = intensity [%] [0; 100] optoNCDT 1320 Page 57...
  • Page 58 262076 no peak available 262077 peak before the measurement range (MR) 262078 peak behind the measurement range (MR) 262080 measurement can not be evaluated, global error 262081 peak is to large 262082 Laser is off optoNCDT 1320 Page 58...

  • Page 59: Characteristics Digital Output

    10 % 60 % 100 % MR 60 % 100 % MR -8.00 mm 42.00 mm -30.0 mm 20.00 mm -20.0 mm 30.00 mm 22483 86717 58454 7066 71301 Digital minimum reached at 10 % MR optoNCDT 1320 Page 59...
  • Page 60 MP‘ mastering 32765 [mm] 50 % 100 % SMR‘ EMR‘ Reserve measuring range Fig. 32 Digital values of an ILD1320-50 with mastering, master value 100 mm Fig. 31 Digital values without zero setting or mastering optoNCDT 1320 Page 60...

  • Page 61: Analog Output Scaling

    - to close to the sensor - beyond SMR or - to far from the sensor - beyond EMR. LED State Error Error Measuring object Fig. 33 Default characteristic (black), reverse, within range Switching user defined characteristic (red) output optoNCDT 1320 Page 61...

  • Page 62: Output Scaling With Key Select

    If the key Select is pressed longer than 10 s or not within the timeframe while doing the return of the output scaling, an error is shown via State LED. In this case the State LED is blinking red with 8 Hz for 2 s. optoNCDT 1320 Page 62...

  • Page 63: Output Scaling Via Hardware Input

    200 ms t 5 - t 3 = 2 s Error  5 min 5 ... <10 s t 3 t 4 Fig. 37 Flow chart for the return of output scaling optoNCDT 1320 Page 63...

  • Page 64: Calculation Of Measuring Value Using Analog Current

    = current [mA] [4; 20] measuring range [>20; 20,2] EMR reserve [mA] - 4) [mm] [mm] - m [mm]| MR = measuring range [mm] {10/25/50/100} m, n = teachig area [mm] [0; MR] = distance [mm] [m; n] optoNCDT 1320 Page 64...
  • Page 65 MR = measuring range [mm] {10/25/50/100} = position object [mm] [0; MR] for MP £ 0.5MR: [-MP; 0.5MR] m, n = teaching area [mm] for MP > 0.5MR: [-0,5MR; MR - MP] = distance [mm] [m; n] optoNCDT 1320 Page 65...

  • Page 66: Characteristics Distance Value And Analog Output

    3.00 mA 4.00 mA 18.40 mA Analog maximum reached at 66 % MR Analog minimum reached at 10 % MR MR = measuring range, SMR = start of measuring range, EMR = end of measuring range optoNCDT 1320 Page 66...
  • Page 67 10 mm (30 mm) (-15 mm) (30 mm) 12 mA Out min 4 mA 3.8 mA 16 % 50 % 60 % 100 % Reserve measuring range Fig. 38 Analog output with zero setting or mastering optoNCDT 1320 Page 67...

  • Page 68: Mastering And Teaching Analog Output

    30 mm 50 mm -10 mm 0 mm 10 mm SMR’ 60 % EMR’ 100 % MR Fig. 39 Analog output characteristic after mastering and scaling with an ILD1320-50 -10.0 mm 10.00 mm 4.00 mA 20.00 mA optoNCDT 1320 Page 68...

  • Page 69: Error Output

    = Hysteresis value Switching output SMR = Start of measuring range Fig. 40 Switching output with function limit value, switching behavior (NPN) Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 69...

  • Page 70: Output Interface

    RS422 and analog is not possible. If web interface was selected, no measurement values are output via RS422 or current output. Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 70...

  • Page 71: System Settings

    The key Select is deactivated independent of the user level. The key Select is active independent of the user level. Inactive Value Grey shaded fields require a selection. Dark-bordered fields require you to specify a value. optoNCDT 1320 Page 71...

  • Page 72: Load, Save

    , e.g. The dialog Setup management The dialog Setup management rubber 1.05 and click opens. opens. the button Save. Click on the button Load. Click on the button Favorite. optoNCDT 1320 Page 72...
  • Page 73 The dialog Setup management opens. Click on the button Search. Click on the button Export. A Windows dialog for file selections opens. Choose the desired file and click on the button Open. Click the button Import in the setup management. optoNCDT 1320 Page 73...

  • Page 74: Import, Export

    Download. file. File name for the following example is <...\ Downloads\ILD1320_50BASICSETTINGS_ MEASSETTINGS_SCHALE_T1...SETTING_ Rubber 1.05.JSON> A security query, see adjacent figure, helps to avoid that an existing setup is inadvertently overwritten during import. optoNCDT 1320 Page 74...

  • Page 75: Access Authorization

    Type in the default password 000 or a user-defined password in the Password field and confirm with Login. Change with a click on the Logout button in the mode user. Fig. 45 Change in the professional user level optoNCDT 1320 Page 75...

  • Page 76: Sensor Reset

    Specifies the user level, with which the sensor starts after the re-starting. For this purpose, restarting Professional MICRO-EPSILON recommends the selection user. After configuration of the sensor the password protection is to be activated. Please note the password for later reference. 7.6.7...

  • Page 77: Digital Interfaces Rs422

    Data selection and output sequence is to be H-Byte queried with the GETOUTINFO_RS422 command. Output sequence: L-Byte, M-Byte, H-Byte. The output of distance measurement value and other measurement value via RS422 requires a subsequent conversion into the cor- responding unit, see Chap.7.5.2.1. optoNCDT 1320 Page 77...

  • Page 78: Conversion Of The Binary Data Format

    The sensor continues to deliver measurement values to the RS422 output even while communicating with the sensor. For the data transmission with a PC the MICRO-EPSILON IF2001/USB is suitable. The IF2001/USB combines the three bytes for the data word and saves them in the FIFO. The 18 bits are used for measurement values and error values. For further information, please refer to the descriptions of the IF2001/USB interface card and associated MEDAQlib driver program.

  • Page 79: Cleaning

    - features by identical functions for the communication (commands), - provides a consistent transmission format for all MICRO-EPSILON sensors. For C/C++ programmers MEDAQLib contains an additional header file and a library file. You will find the latest driver / program rou- tine at: www.micro-epsilon.de/download/...

  • Page 80: Disclaimer

    MICRO-EPSILON or to your distributor / retailer. MICRO-EPSILON undertakes no liability whatsoever for damage, loss or costs caused by or related in any way to the product, in par- ticular consequential damage, e.g., due to...

  • Page 81: Decommissioning, Disposal

    Here you can inform yourself about the respective national collection and return points. - Old devices can also be returned for disposal to MICRO-EPSILON at the address given in the imprint at https://www.micro-epsilon.com/impressum/. - We would like to point out that you are responsible for deleting the measurement-specific and personal data on the old devices to be disposed of.

  • Page 82: Appendix

    1x female connector 6-pin (cable clamp) type Würth 691361100006 IF2035-PROFINET Interface module for PROFINET connection of a Micro-Epsilon sensor with RS485 or RS422 interface, suitable for PCF1420-x/I or PCF1420-x/U cables, top-hat rail housing, incl. GSDML file for software integration in the PLC...
  • Page 83 Appendix| Optional Accessories IF2004/USB 1 channel converter RS422 to USB inclusive driver, connections: 1× terminal block 1) One channel with ILD 1320 possible only. optoNCDT 1320 Page 83...

  • Page 84: A 2 Factory Settings

    (t ... t key is released while the LED State is flashing yellow Dt = t ; Dt (key press period) must be at least 10 sec., max. 15 sec. optoNCDT 1320 Page 84...

  • Page 85: A 3 Ascii Communication With Sensor

    It requires that both parameters “P1“ and “P2“ are set. The parameters “P1“, “P2“ and “P3“ can be set, whereby “P2“ may only be set, if “P1“ is „ P1 [P2 [P3]]“ set and “P3“ only if “P1“ and “P2“ are set. optoNCDT 1320 Page 85...
  • Page 86 These are analogous to the error messages. In case of warnings the command is executed. The replies to the commands GETINFO and PRINT are useful for support requests to the sensor, because they contain sensor set- tings. optoNCDT 1320 Page 86...

  • Page 87: A 3.2 Overview Commands

    Triggering Chap. A 3.3.9.1 TRIGGER Selection of trigger mode Chap. A 3.3.9.2 MFILEVEL Selection of level for multifunctional input Chap. A 3.3.9.3 TRIGGERCOUNT Number of measurement values displayed Chap. A 3.3.9.4 TRIGGERSW Software - trigger pulse optoNCDT 1320 Page 87...
  • Page 88 Load/save device settings Chap. A 3.3.11.5 SETDEFAULT Factory settings Scaling of analog output Chap. A 3.3.12 ANALOGSCALE Scaling analog output Key function Chap. A 3.3.13.1 KEYFUNC Selection of key function Chap. A 3.3.13.2 KEYLOC Selection of keylock optoNCDT 1320 Page 88...
  • Page 89 A 3.5.1 OUTPUT Selection measuring value output Chap. A 3.5.2 OUTHOLD Setting of error processing Select measurement values to be output Chap. A 3.5.3.1 GETOIUTINFO_RS422 Request data selection Chap. A 3.5.3.2 OUTADD_RS422 Selection of additional values optoNCDT 1320 Page 89...

  • Page 90: A 3.3 General Commands

    LANGUAGE DE | EN Determines the language for the web interface. - DE: set language to German - EN: set language to English - CN: set language to Chinese The chosen language setting applies to the website. optoNCDT 1320 Page 90...

  • Page 91: A 3.3.4 Reset, Boot Sensor

    ECHO, Switching the Command Reply, ASCII Interface ECHO ON|OFF Setting the command reply with a ASCII command: - ON: command reply on, for example <Kdo> ok (or notice of error) -> - OFF: command reply off, for example -> optoNCDT 1320 Page 91...

  • Page 92: A 3.3.7 Print, Sensor Settings

    GETOUTINFO_RS422 DIST1 UNIT MM OUTHOLD NONE LANGUAGE DE ERROROUT1 DIST MFIFUNC NONE ERRORLEVELOUT1 NPN MFILEVEL HTL_HIGH ANALOGSCALE STANDARD KEYFUNC NONE KEYLOCK AUTO 5 (IS_ACTIVE) MEASRATE 1.000 MEASPEAK DISTA TRIGGER NONE TRIGGERCOUNT INFINITE LASERPOW FULL MASTERMV NONE optoNCDT 1320 Page 92...

  • Page 93: A 3.3.8 User Level

    Type in the old password followed by the new password (2x). In case the new password is not typed in correctly, an error message is will be displayed. Password may only contain letters from A to Z, no numbers 0 to 9. Watch upper and lower case lettering. The maxi- mum length is limited to 31 characters. optoNCDT 1320 Page 93...

  • Page 94: A 3.3.9 Triggering

    - <n>: number of displayed measurement values after each trigger impulse n = 1 ... 16382 A 3.3.9.4 TRIGGERSW, Software Trigger Pulse TRIGGERSW Creats a trigger pulse. Error message is displayed if “SOFTWARE” is not selected in trigger selection. optoNCDT 1320 Page 94...

  • Page 95: A 3.3.10 Interfaces

    - NONE: digital ourput deactivated - DIST: no peak found or beyond measuring range (out of range) - TEACH: Distance is out of scaled analog range - LI1: Distance is greater than the limit value (ERRORLIMIT) optoNCDT 1320 Page 95...

  • Page 96: A 3.3.10.5 Errorlevelout1, Output Level Digital Output

    ERROROUTHOLD <hold period> Indicates in ms how long the digital output must be active at least when the limit value is exceeded. This time period starts when the limit value is exceeded. Range: 0 ... 1000 [ms]. optoNCDT 1320 Page 96...

  • Page 97: A 3.3.11 Handling Of Setups

    ƒ RENAME <NameOld> <NameNew> [FORCE]: Renaming a measurement setting. An existing measurement setting can be overwritten with FORCE. ƒ INITIAL <name> | AUTO: Loads a named or last saved measurement setting at the start of the sensor. Presets can not be speci- fied. optoNCDT 1320 Page 97...

  • Page 98: A 3.3.11.4 Basicsettings, Load / Save Device Settings

    ƒ Minimum value: measurement value in mm which is matched to the lower analog value (4 mA) ƒ Maximum value: measurement value in mm which is matched to the upper analog value (20 mA) The minimum value (in mm) can be higher than the maximum value (in mm), see Chap. 7.5.3. optoNCDT 1320 Page 98...

  • Page 99: A 3.3.13 Key Function

    - DISTL: output of last peak A 3.4.2 MEASRATE, Measuring Rate MEASRATE 0.25|0.5|1|2|4 Choice of measuring rate in kHz. A 3.4.3 LASERPOW, Laser Power LASERPOW FULL|OFF - FULL: laser power is set to 100 % - OFF: laser is switched off optoNCDT 1320 Page 99...

  • Page 100: A 3.4.4 Measurement Value Processing

    - NONE: no holding of the last measurement value, output of error value - INFINITE: infinite holding of the last measurement value - <n>: holding of the last measurement value on the number of measurement cycles; then an error value is output, n = (1 ... 1024) optoNCDT 1320 Page 100...

  • Page 101: A 3.5.3 Selection Of Measurement Values To Be Output

    Measuring rate (under consideration of reflectivity and movement of the target) OUTPUT Selection of the output channel OUTHOLD Output characteristic during measurement errors OUTADD_RS422 Selection of the additional values to be output for RS422 interface BAUDRATE Baud rate settings RS422 interface optoNCDT 1320 Page 101...

  • Page 102: A 3.7 Error Messages

    Error during processing the import data E333 No overwrite during import allowed No overwrite of measurement and device settings allowed through import, set the checkbox. E350 The new passwords are not identical Password and verification password do not match. optoNCDT 1320 Page 102...
  • Page 103 E602 Master value is out of range Master value is out of valid range E616 Software triggering is not active Software triggering is not active. Warning Description W320 The measuring output has been adapted The measuring output has been adapted automatically. automatically. optoNCDT 1320 Page 103...

  • Page 104: A 4 Control Menu

    Teaching scales the analog output. HTL is defined as Teaching active input level. Inactive Key function Zeroing (Mastering) Sets the function of the sensor key. Inactive means keylock. Teaching Inactive 1) Available for the sensor models ILD1320-10/25/50. optoNCDT 1320 Page 104...

  • Page 105: Signal Processing

    Software infinite Software triggering is started by clicking the button Release trigger. „0“ end trigger, „1 ... 16382“ values per trigger, „16383“ infinite trigger manual Number Value Inactive No triggering 1) Available for the sensor models ILD1320-10/25/50. optoNCDT 1320 Page 105...
  • Page 106 Hold last value 1 ... 1024 Value Zeroing/ Inactive Normal measurement value or Zeroing/Mastering is undone. Mastering Active Value Indication e.g. of thickness of a master part. Value range 0 up to max. + 2 x measuring range optoNCDT 1320 Page 106...

  • Page 107: Outputs

    Decides on the used interface for measurement value output. A parallel physical measurement value output via RS422 and analog is not pos- sible. If web interface was selected, no measure- ment values are output via RS422 or current output. optoNCDT 1320 Page 107...
  • Page 108 Appendix| Control Menu Web interface LED Output RS422 Current output Parametrization Measurement chart Web inteface yellow • • Selected output RS422 green • • interface Analog • • • optoNCDT 1320 Page 108...

  • Page 109: A 4.2.4 System Settings

    Saves changed device settings. Search You load the device settings from a PC or the like to the ILD 1320 with both buttons. Import Export Saves the device settings on a connected PC or the like. optoNCDT 1320 Page 109...
  • Page 110 Button starts change of access permission. Sets the user level the sensor starts with after re- User level reboot Professional / User boot. In this case MICRO-EPSILON recommends the selection user. Old password Value Case-sensitive rules are observed for all passwords.
  • Page 111 The settings will be effective, if you click on the button Apply. After the pro- gramming all settings must be permanently stored under a parameter set so that they are available again when the sensor is switched on the next time. Value Specification of a value required optoNCDT 1320 Page 111...
  • Page 112 MICRO-EPSILON MESSTECHNIK GmbH & Co. KG Koenigbacher Str. 15 · 94496 Ortenburg / Germany Tel. +49 (0) 8542 / 168-0 · Fax +49 (0) 8542 / 168-90 X9751350-A102044MSC info@micro-epsilon.com · www.micro-epsilon.com www.micro-epsilon.com/contact/worldwide/ MICRO-EPSILON MESSTECHNIK Your local contact:...

This manual is also suitable for:

Ild 1320-10Ild 1320-25Ild 1320-50Ild 1320-100Ild 1320-200Ild 1320-500

Table of Contents
