Ethernet Interface
6.4.2
There are three possible settings regarding the trigger
Irrespective of the trigger mode set, a single measured value per channel can be called up by means of a
software
ment values without interruption and with the adjusted data rate.
Command
Response
Index
Request Trigger mode
Command
Response
6.4.3
In the trigger mode, one measuring value is transmitted per channel.
Command
Response
capaNCDT 6228 / 6238

Trigger Mode (TRG)

command, see 6.4.3. If the trigger mode is turned off, the capaNCDT 62x8 will send the measure-
TRG
$TRGn<CR>
$TRGnOK<CRLF>
n = 0: Continuous transmission (default setting)
n = 1: Triggermode 1 (rising edge)
n = 2: Triggermode 2 (high level)
n = 3: Triggermode 3 (gate rising edge)
? = Request trigger mode
$TRG?<CR>
$TRG?nOK<CRLF>

Get Measured Data (GMD)

GMD
$GMD<CR>
$GMDOK<CRLF> + Measuring value in binary mode (format as in
operating mode "continuous transmission") via data port
input, see 5.4.
Page 54
