SmarTrax™ Installation Manual
Case IH MX 210, 230, 255, 285

Advertisement

Table of Contents
loading

Related Manuals for Raven SmarTrax Case IH MX 210

Summary of Contents for Raven SmarTrax Case IH MX 210

  • Page 1 SmarTrax™ Installation Manual Case IH MX 210, 230, 255, 285...
  • Page 2 GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or consequential damages or a loss of anticipated benefits or profits, work stoppage or loss or impairment of data arising out of the use, or inability to use, the SmarTrax or any of its components.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Important Safety Information..........1 Important Safety Information ..................... 1 Chapter 2 Introduction................3 Updates ............................. 4 Preparing for Installation ......................4 Hydraulic Fittings ........................5 Kit Contents ..........................5 Chapter 3 Mounting the SmarTrax Hydraulic Valve ......9 Mount the SmarTrax Hydraulic Valve ..................
  • Page 4 Table of Contents CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...

  • Page 5: Important Safety Information

    • Follow all safety information presented within this manual • If you require assistance with any portion of the installation or service of your Raven equipment, contact your local Raven dealer for support. • Follow all safety labels affixed to the SmarTrax components. Be sure to keep safety labels in condition and replace any missing or damaged labels.
  • Page 6 CAUTION Hydraulic Safety • Raven Industries recommends that appropriate protective equipment be worn at all times when working on the hydraulic system. • Never attempt to open or work on a hydraulic system with the equipment running. Care should always be taken when first opening a system that has previously been pressurized.

  • Page 7: Introduction

    CHAPTER C h a p t e r 2 Congratulations on your purchase of the Raven SmarTrax system. This system is designed to provide cutting- edge, hands-free steering of agricultural equipment via GPS (Global Positioning System) coordinates. This manual applies to the following machines. For future reference, write your serial number in the space below.

  • Page 8: Updates

    Updates for Raven manuals as well as software updates for Raven consoles are available at the Applied Technology Division web site: http://www.ravenprecision.com/Support/index2.jsp Sign up for e-mail alerts and we will notify you when updates for your Raven products are available on the Raven web site. http://www.ravenprecision.com Preparing for Installation Before installing SmarTrax, park the machine where the ground is level, clean, and dry.

  • Page 9: Hydraulic Fittings

    In addition to the following kits, a SmarTrax Controller or Node kit is required to complete installation of the SmarTrax system. Contact your local Raven dealer for available kits and ordering information. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060) TABLE 1.
  • Page 10 Chapter 2 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060) TABLE 1. Picture Item Description Part Number Bracket - Hydraulic Valve Mounting 116-0159-527 Switch - SmarTrax Pressure 422-0000-074 Valve - SmarTrax Hydraulic 334-0003-066 Label - Tampering Warning 041-0159-689 Bolt - 5/16”...
  • Page 11 Introduction CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060) TABLE 1. Picture Item Description Part Number Fitting - 9/16” JIC (M/F) 90° Swivel Elbow 333-0012-042 Fitting - -8 STC (F/F/F) Tee 333-0012-150 Fitting - -6 STC (F) to 11/16” ORFS (F) 45° Elbow 333-0012-151 Hose - -8 STC (M) TO -8 STC (M), 5"...
  • Page 12 Chapter 2 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...

  • Page 13: Mounting The Smartrax Hydraulic Valve

    M ounting the CHAPTER C h a p t e r 3 SmarTrax Hydraulic Valve Mount the SmarTrax Hydraulic Valve NOTICE The appearance of the SmarTrax hydraulic valve may vary slightly from the images contained in this manual. However, the fittings, hose connections, and cable connections remain the same.

  • Page 14: Affixing The Smartrax Tampering Warning Label

    Affixing the SmarTrax Tampering Warning Label Raven Industries supplies a tampering warning label (P/N 041-0159-689) with all SmarTrax kits. This label should be applied on or near the SmarTrax hydraulic valve or mounting bracket and in a location where anyone working on the machine is able to clearly see and read the label.

  • Page 15: Hydraulic Connections

    H ydraulic CHAPTER C h a p t e r 4 Connections WARNING Hydraulics may be under pressure. Never attempt to open or work on a hydraulic system with the equipment running. Care should always be taken when working on a system that has previously been pressurized.

  • Page 16: Install The Pressure, Tank, Left, And Right Hoses

    STC Quick release tools in order to remove the hydraulic fittings.A flat screwdriver may also be used to remove fittings, but may make removal difficult. These tools can be purchased from Aeroquip or Raven Industries. Release Tool Aeroquip P/N...
  • Page 17 Hydraulic Connections Install the provided extension hoses (P/N 214-1000-282) onto the steering orbitrol’s P, T, L, and R ports. Install the supplied run tees (P/N 333-0012-150) onto the ends of the extension hoses and reconnect the original hoses to their corresponding tee fittings. Supplied Hoses Installed on the Machine’s Steering Orbitrol FIGURE 2.

  • Page 18: Install The Ls-Steer And Ls-Pv Hoses

    Chapter 4 Install the LS-Steer and LS-PV Hoses Disconnect the original load sense hose from the steering orbitrol. Machine’s Steering Orbitrol FIGURE 4. Connect the original load sense hose to the extension hose (P/N 214-1000-285) using the supplied 45 ° elbow (P/N 333-0012-151).

  • Page 19: Install The Pressure Switch

    Hydraulic Connections Install the Pressure Switch Attach the pressure switch (P/N 422-0000-074) directly to the ‘PS’ port on the SmarTrax hydraulic valve. Pressure Switch connected to SmarTrax Hydraulic Valve FIGURE 6. ‘PS’ Port Manual No. 016-0190-060...

  • Page 20: Hydraulic Connection Diagram

    Chapter 4 Hydraulic Connection Diagram CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...

  • Page 21: Wiring And Electrical Connections

    W iring and Electrical CHAPTER C h a p t e r 5 Connections CAUTION Ensure that the power cable is the last cable connected. Do not reverse the power leads. Doing so will cause severe damage to the equipment. Ensure the leads are connected to the correct polarity.

  • Page 22: Connecting The Pressure Override Switch

    Chapter 5 Connecting the Pressure Override Switch On the console cable harness (P/N 115-0171-775), identify the connector labeled ‘OVERRIDE’. Connect the ‘OVERRIDE’ connector to the pressure override switch. Tighten the bolt on the connector to secure the connection and to help prevent moisture penetration. Route the Console Cable Harness Once the SmarTrax hydraulic valve and pressure override switch are connected to the console cable harness, the remaining connectors must be routed into the cab.

  • Page 23: Mount The Smartrax Controller

    Wiring and Electrical Connections Mount the SmarTrax Controller When choosing the location for the SmarTrax controller, consider the following points: • The controller is not weatherproof. Mount the controller in the vehicle’s cab within easy reach of the operator. • Mount the controller in a location where it will not impede the operator’s ability to control the vehicle and where other components within the cab will not strike or jar the controller during normal operation.

  • Page 24: Install The Yaw Sensor

    Mount the yaw sensor to a flat, level surface. The floor of the cab is generally ideal. • Mount the yaw sensor so that the Raven logo faces up. • The SmarTrax yaw sensor does not need to be oriented toward the direction of vehicle travel.

  • Page 25: Install The Smartrax Node

    Wiring and Electrical Connections Install the SmarTrax Node When choosing the location for the SmarTrax node, consider the following points: • The node is not weatherproof. Mount the SmarTrax node inside the machine’s cab or driver’s compartment. • The node mounting location must not create tripping hazards and allow cable routing to avoid crimping or damaging the cables or the node connections.
  • Page 26 Chapter 5 Cable Harness Installation Schematic FIGURE 5. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...

  • Page 27: Start-Up Procedures

    S tart-Up Procedures CHAPTER C h a p t e r 6 WARNING When starting the machine for the first time, keep the area around the machine clear of people or bystanders in case a fitting or hose has not been fully tightened. WARNING DO NOT use hands to check for leaks.

  • Page 28: Verify The Smartrax Installation

    Hydraulic fluid is not leaking. If there are any problems, shutdown the machine and correct problems immediately. If you need additional assistance, contact your local Raven dealer or the Raven Customer Support Center at 1-800-243-5435. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...

  • Page 29: System Drawings

    Contact your local dealer for purchasing or more information on components shown in the following diagrams. Additional system diagrams are available from the Raven Industries web site: http://www.ravenprecision.com/Support/ApplicationDrawings/index2.jsp Manual No. 016-0190-060...
  • Page 30 Chapter 7 Can Node Wiring Diagram CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...
  • Page 31 System Drawings Envizio Pro/ Viper Pro Manual No. 016-0190-060...
  • Page 32 Chapter 7 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...
  • Page 33 System Drawings Manual No. 016-0190-060...
  • Page 34 Chapter 7 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...
  • Page 35 System Drawings Cruizer Manual No. 016-0190-060...
  • Page 36 Chapter 7 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...
  • Page 37 Index Affixing the SmarTrax Tampering Warning Label CAN Node Wiring Diagram Console Cable Harness Routing Hydraulic Connection Diagram Hydraulic Connections Installation Foot Switch 18 Recommendations SmarTrax Controller 19, 21 Yaw Sensor 20 Yaw Sensor 20 Kit Contents LS-Steer and LS-PV Hoses Installation 14 Mount the SmarTrax Hydraulic Valve Preparing for Installation...
  • Page 38 Index CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual...
  • Page 39 How Can I Get Service? Bring the defective part and proof of purchase to your Raven Dealer. If your Dealer agrees with the warranty claim, the Dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 40 P.O. Box 5107 Fax: 605-331-0426 Sioux Falls, SD 57117-5107 www.ravenprecision.com atdinfo@ravenind.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws.
