SMARTRAX SUPPLEMENT
INSTALLATION MANUAL
MERTZ / TYLER 3300
117-0190-041

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRECISION Solutions SmarTrax Mertz 3300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Raven PRECISION Solutions SmarTrax Mertz 3300

  • Page 1 SMARTRAX SUPPLEMENT INSTALLATION MANUAL MERTZ / TYLER 3300 117-0190-041...
  • Page 2 GPS signal from the US Department of Defense/NAVSTAR GPS satellites, the OmniSTAR correction service or the WAAS correction service. Raven Industries accepts no responsibility for the use of the signal for other than the stated purpose. Raven Industries shall not be responsible or liable for incidental or...
  • Page 3 RAVEN INDUSTRIES LIMITED WARRANTY WHAT IS COVERED? This warranty covers all defects in workmanship or materials in your Raven Flow Control Product under normal use, maintenance, and service. HOW LONG IS THE COVERAGE PERIOD? This warranty coverage runs for 12 months from the purchase date of your Raven Flow Control Product.
  • Page 4 RAVEN INDUSTRIES FLOW CONTROL DIVISION 205 East Sixth Street - P.O. Box 5107 - Sioux Falls, South Dakota 57117-5107 E-mail: fcdinfo@ravenind.com www.ravenprecision.com Toll-free: 800-243-5435 - Fax: 605-331-0426 Supplement Installation Manual, Mertz / Tyler 3300 #016-0190-041 Rev A 08/04...
  • Page 5: Table Of Contents

    016-0190-041 TABLE OF CONTENTS 08/04 MOUNTING THE STEERING POSITION SENSOR ................2 MOUNTING THE UNIVERSAL BRACKET ..................3 MOUNTING THE HYDRAULIC VALVE ....................3 MOUNTING THE COUNTERBALANCE VALVE, PRESSURE SWITCH, AND NEEDLE VALVE ..4 HOSE CONNECTIONS AND ROUTINGS ................... 6 PRESSURE HOSE ........................
  • Page 6: Mounting The Steering Position Sensor

    Mertz / Tyler 3300 MOUNTING THE STEERING POSITION SENSOR Figure below shows the approximate mounting position of the steering position sensor. Attach the steering position sensor the the left side steering cylinder using the provided band clamps, screws and brackets. Note: It may be necessary to fabricate a shield so that mud and debris do not hit the sensor during operation.
  • Page 7: Mounting The Universal Bracket

    MOUNTING THE UNIVERSAL BRACKET Position the bracket on the steel cab support beam beneath the front of the cab. Drill holes to fit the mounting bracket pattern and attach the universal mounting bracket to the machine using the pro- vided 3/8” hex-head bolts. Figure below shows the bracket mounted to the machine with the valve and hoses attached, and cables run between the valve and mounting beam.
  • Page 8: Mounting The Counterbalance Valve, Pressure Switch, And Needle Valve

    MOUNTING THE COUNTERBALANCE VALVE, PRESSURE SWITCH, AND NEEDLE VALVE Note: A new bracket must be fabricated to attach the counterbalance valve to the machine. Attach the counterbalance valve to the bracket and secure the bracket to the machine in the approximate location shown in the figure below.
  • Page 9 In this picture, ports are labeled 1 - 5. 1 - Power Beyond port 2 - Right Steer port 3 - Tank port 4 - Left Steer port 5 - Pressure port...
  • Page 10: Hose Connections And Routings

    HOSE CONNECTIONS AND ROUTING Pressure Hose Remove the existing pump to orbital hose and attach it to the “P” port on the steering assist valve. It may be necessary to use the provided 90-degree 3/4” JIC elbow fittings to ensure the hoses are routed properly.
  • Page 11: Needle Valve Hose

    Needle Valve Hose Attach the Needle Valve to Tank hose to the remaining open port of the tee on the Tank port of the orbital. Attach the other end to the open port on the needle valve. It may be necessary to use one of the provided elbow fittings to ensure the tee is routed properly.
  • Page 12: B-Port To Counterbalance Hose

    B-Port to Counterbalance Hose Install a provided 3/4” JIC tee fitting to the “B” port on the steering assist valve. Connect the right steer hose that was disconnected from the orbital to one of the open ports on the tee. Connect the proper end of the B Port to Counterbalance hose to the remaining open port on the tee.
