SmarTrax™ Installation Manual
Case IH Steiger and
New Holland TJ/T90X0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmarTrax Case IH Steiger Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Raven SmarTrax Case IH Steiger Series

  • Page 1 SmarTrax™ Installation Manual Case IH Steiger and New Holland TJ/T90X0...
  • Page 2 GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the accuracy, integrity, continuity, or availability of these services and cannot guarantee the ability to use Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Important Safety Information..........1 Hydraulic Safety ........................2 Electrical Safety ........................2 Chapter 2 Introduction................3 Updates ............................. 3 Preparing for Installation ......................4 Recommendations ......................4 Point of Reference ....................... 4 Kit Contents ..........................5 Chapter 3 Hydraulic System Installation..........
  • Page 4 Table of Contents Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 5: Important Safety Information

    • Follow all safety information presented within this manual. • If you require assistance with any portion of the installation or service of your Raven equipment, contact your local Raven dealer for support. • Follow all safety labels affixed to the SmarTrax system components. Be sure to keep safety labels in good condition and replace any missing or damaged labels.
  • Page 6: Hydraulic Safety

    CAUTION Hydraulic Safety • Raven Industries recommends that appropriate protective equipment be worn at all times when working on the hydraulic system. • Never attempt to open or work on a hydraulic system with the equipment running. Care should always be taken when opening a system that has been previously pressurized.
  • Page 7: Introduction

    MODEL: Steiger 335/385/435/485/535 and STX 280/330/380/430/480/530 MAKE: New Holland MODEL: TJ 280/330/380/430/480/530 and T9010/9020/9030/9040/9050/9060 New Holland T9050 and Case IH Steiger 535 FIGURE 1. Updates Software and manual updates are available on the Raven Applied Technology website: http://www.ravenhelp.com Manual No. 016-5032-004...
  • Page 8: Preparing For Installation

    Recommendations Raven Industries recommends the following best practices when installing or operating the SmarTrax system for the first time, at the start of the season, or when moving the SmarTrax system to another machine: •...
  • Page 9: Kit Contents

    SmarTrax installation, compare the items in the kit with the components on this list. If you have questions about the kit, contact your Raven dealer. Note: The SmarTrax node (P/N 063-0173-228) is sold separately. Contact your local Raven dealer for ordering information. SmarTrax Installation Kit (P/N 117-5032-004) TABLE 1.
  • Page 10 Chapter 2 SmarTrax Installation Kit (P/N 117-5032-004) TABLE 1. Picture Item Description Part Number Qty. Assembly - SmarTrax Enable Foot Switch 063-0172-470 Bolt - M6 x 1.00 x 20 mm Hex 311-0070-010 Bolt - M8 x 1.25 x 50 mm Hex 311-0070-044 Nut - 3/8”-16 Nylon Insert Lock 312-4000-061...
  • Page 11 Introduction Hydraulic Installation Kit (P/N 117-0199-109) TABLE 2. Picture Item Description Part Number Qty. Hydraulic Hose - -6 ORFS (M) to -6 ORFS 214-1000-776 (F) 90° - 13” Hydraulic Hose - -6 ORFS (F) to -6 ORFS (F) 214-1000-779 90° - 24” Manual No.
  • Page 12 Chapter 2 Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 13: Hydraulic System Installation

    H ydraulic System CHAPTER C h a p t e r 3 Installation WARNING Hydraulics are under pressure. Care should always be taken with a system that has been pressurized. Before beginning the SmarTrax hydraulic installation, turn off the machine and relieve pressure by turning the steering wheel left and right.
  • Page 14: Install The Proportional Valve (Pve)

    Chapter 3 Install the Proportional Valve (PVE) Steering Valve Location FIGURE 1. Steering Valve Location - Smaller Models Steering Valve Location - Larger Models (Behind Front Axle on Right Side of Frame) Locate the steering valve. Note: On smaller models, the steering valve is located under the hood, directly in front of the cab. On all larger models, the steering valve is located behind the front axle on the right side of the tractor frame.
  • Page 15 Hydraulic System Installation Shuttle Valve Installed in End Cap FIGURE 3. Install the tapered end of a shuttle valve (P/N 334-0002-163) into the end cap. Reinstall the end cap on the steering valve. Note: Ensure the O-rings remain seated during installation. Reinstall and tighten any previously removed mounting bolts, hoses, and/or tubes.
  • Page 16 Chapter 3 Shuttle Valve Installed in the PVE FIGURE 5. Install the tapered end of the remaining shuttle valve into the supplied PVE (P/N 334-0002-162). PVE Installed on Steering Valve FIGURE 6. Install the PVE in the removed end cap location. Note: Ensure the O-rings remain seated during installation.
  • Page 17: Install The Override Flow Switch

    Hydraulic System Installation Install the Override Flow Switch Fittings and Transducers Installed in the Flow Switch FIGURE 7. Install the ORFS (M) to SAE O-Ring (M) straight adapter fittings in the ends of the flow switch (P/N 334-0003-085), one in an A port and one in a B port. Install pressure transducers into the remaining A and B ports.
  • Page 18 Chapter 3 Pressure Hose Removed from the Steering Valve FIGURE 9. PS Port Circled at the Axle Mounting Location PS Port Circled at the Cab Mounting Location (Bottom View) (Top View) Front of Machine Remove the pressure hose from the fitting installed in port PS of the steering valve fitting as shown in the figure below.
  • Page 19 Hydraulic System Installation Hoses Installed on Flow Switch FIGURE 11. Hose 214-1000-775 or 214- Hose 214-1000-776 1000-779 Connected to PS Connected to Previously Port on Steering Valve Disconnected Pressure Hose Front of Machine Install the supplied 24” hydraulic hose on the pressure port of the steering valve. Note: Two 24”...
  • Page 20 Chapter 3 Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 21: Cab Component Installation

    Installation Install the SmarTrax Node Mount the SmarTrax Node Note: The SmarTrax node (P/N 063-0173-228) is sold separately. Contact your local Raven dealer for ordering information. SmarTrax Node Installed FIGURE 1. Mount the SmarTrax node to the node mounting bracket (P/N 107-0172-084) using three 3/8”-16 nylon insert lock nuts (P/N 312-4000-061).
  • Page 22: Node Mounting Locations

    Chapter 4 Node Mounting Locations Node Mounting FIGURE 2. Direction Arrows Any two arrows must be parallel with level ground Mounting Tabs When choosing the location for the SmarTrax node, consider the following points: • Mount the SmarTrax node inside the machine’s cab on a flat, level surface for proper performance and cable connection.
  • Page 23: Install The Foot Switch

    Cab Component Installation Install the Foot Switch Foot Switch Installed FIGURE 3. Select a suitable location for the foot switch (P/N 063-0172-470) to be installed. Note: The foot switch should be installed in a location where the operator has easy access to it and is able to fully press the pedal.
  • Page 24 Chapter 4 Valve Harness Connected to PVE FIGURE 4. Plug the PVES connector from the valve harness into the PVE. Valve Harness Connected to Flow Switch FIGURE 5. Plug the 3-pin TRANSDUCER 1 and TRANSDUCER 2 connectors from the valve harness into the pressure transducers installed on the flow switch.
  • Page 25 Cab Component Installation Valve Harness Wiring Diagram FIGURE 6. NOTE: TRANSDUCER LOCATION ON FLOW SWITCH MAY VARY Manual No. 016-5032-004...
  • Page 26: Install The Chassis Cable - Smartrax-Only Systems (If Applicable)

    Connect SmarTrax to an Existing Chassis Cable (If Applicable) Locate and disconnect the connection between the Raven console cable and chassis cable on the machine’s existing CAN system. Install the SmarTrax node harness (P/N 115-4001-126) between the chassis and Raven console harness.
  • Page 27: System Diagrams

    Cab Component Installation System Diagrams Existing Chassis System Wiring Diagram FIGURE 7. Manual No. 016-5032-004...
  • Page 28 Chapter 4 Envizio Pro II with Slingshot FIGURE 8. Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 29 Cab Component Installation Viper Pro/Envizio Pro with Slingshot FIGURE 9. Manual No. 016-5032-004...
  • Page 30 Chapter 4 Cruizer II with Slingshot FIGURE 10. Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 31: Startup Procedures

    S tartup Procedures CHAPTER C h a p t e r 5 WARNING When starting the machine for the first time after installing SmarTrax, be sure that all persons stand clear in case a hose has not been properly tightened. WARNING Do not use hands to check for leaks.
  • Page 32: Calibrate The Smartrax System

    Chapter 5 Access the System Diagnostic screen by selecting the MACHINE TEST option on the Machine Type screen and turn the wheels using the Raven console. Note: If there are issues with the SmarTrax system, turn off the machine and correct them immediately.
  • Page 33 Index Cab Component Installation Connecting SmarTrax to an Existing Chassis Cable 22 Installing the Chassis Cable - SmarTrax-Only Systems 22 Installing the Foot Switch 19 Installing the SmarTrax Node 17 Mounting the SmarTrax Node 17 Node Mounting Locations 18 Installing the Valve Harness 19 Routing the Node Harness 18 System Diagrams 23 Hydraulic Installation...
  • Page 34 Index Case IH Steiger & New Holland TJ/T90X0 SmarTrax™ Installation Manual...
  • Page 35 How Can I Get Service? Bring the defective part and proof of purchase to your Raven dealer. If your dealer agrees with the warranty claim, the dealer will send the part and proof of purchase to their distributor or to Raven Industries for final approval.
  • Page 36 Sioux Falls, SD 57117-5107 Fax: 605-331-0426 www.ravenprecision.com www.ravenhelp.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws. ©Raven Industries, Inc. 2012...
