- Page 1 ST 85 Systems Operation & Maintenance Manual...
- Page 2 Tel.: (301) 490-9860 (888) 535-7223 (PACE) Fax (301) 498-3252 PACE EUROPE Sherbourne House, Sherbourne Drive Tilbrook, Milton Keynes MK7 8HX United Kingdom Tel.: (44)1908 277666 Fax: (44)1908 277777 www.paceworldwide.com © 2000 PACE Incorporated, Laurel MD. All rights reserved. Printed in the U.S.A.
- Page 3 MANUAL NUMBER 5050-0455 REV. C SYSTEM QUICK START The ST 85 system is very easy to operate and can be quickly set up for use in standard desoldering/soldering operations. To begin operation of your new system quickly, perform the "Set-Up" and "Quick Start - Basic Operation"...
-
Page 4: Table Of Contents
Table of Contents TITLE PAGE General Information ....................4 Introduction ....................4 Specifications ....................4 Parts Identification ..................5 Safety ........................6 Safety Guidelines, English Language ............6 Safety Guidelines, French Language ............7 Safety Guidelines, German Language ............8 Safety Guidelines, Italian Language ............. - Page 5 Table of Contents TITLE PAGE Set-Up Mode ......................29 Introduction ....................29 Entering Set-Up Mode ................. 29 Operation ..................... 30 Password ....................30 Temperature Scale .................. 30 Temperature Limits ................. 31 Offset Constant ..................32 Temperature Setback ................32 Auto Off ....................33 Temperature Display Impedance ............
-
Page 6: General Information
This manual will provide you with the information necessary to properly set up, operate and maintain the ST 85 system. The ST 85 systems are available in either the 115 VAC, or 230 VAC version which incorporates a highly responsive SensaTemp (closed loop) control system providing up to 80 Watts of total power to a single output channel. -
Page 7: Parts Identification
General Information EOS/ESD Specifications The specifications shown below apply except on "Soft Ground Systems" which have a 1 meg ohm current limiting resistance and a label placed on the power source front panel referring to EN 100015-1. Tip-To-Ground Resistance: Less than 2 ohms. AC Leakage: Less than 2 millivolts RMS from 50Hz to 10MHz. -
Page 8: Safety
Be sure to place the handpiece in its holder after use and allow to cool before storing. 5. Always use PACE systems in a well ventilated area. A fume extraction system such as those available from PACE are highly recommended to help protect personnel from solder flux fumes. - Page 9 Des brûlures sévères peuvent en résulter. 4. Les outils PACE et leurs pannes ainsi que le support sont dessinés de manière spécifique afin de protéger l'utilisateur/opérateur de brûlures accidentelles. Reposer toujours les outils après chaque utilisation dans leurs étuis/supports afin de permettre leur refroidissement.
- Page 10 Loetspitzen sind heiss wenn das System eingeschaltet ist oder erst vor kurzer Zeit ausgeschaltet wurde. Heizelement und Loetspitze nicht beruehren. Verbrennungsgefahr. 4. PACE Tip & Tool und andere Handwerkzeugablagen sind so konstruiert, dass ein versehentliches Beruehren des dazugehoerendes Handwerkzeuges vermieden wird. Bewahren Sie das Handwerkzeug nach Gebrauch stets in der Ablage auf.
- Page 11 Mettere sempre l’impugnatura nel propio supporto dopo l’utilizzo e lasciarla raffredare prima di riporla. 5. Utilizzare sempre I stazioni PACE in una zona be aerata per proteggere il personale dai fumi. É fortemente raccomandato un sistema di aspirazione (dei fumi) come quello disposta dalla PACE.
- Page 12 5. Utilize sempre os sistemas da PACE em locais bem ventilados. Um Sistema de extracção de fumos, como os Sistemas disponiveis na PACE, são altamente recomendados para a protecção dos utilizadores contra os fumos produzidos pela...
- Page 13 5. Siempre use sistemas de PACE en una área bien ventilada. Un sistema de extraccíon de humo como esos disponibles de PACE se recomiendan para ayudar a protejer al personal contra los humos de flujo de soldadura.
- Page 14 Följande säkerhetsföreskrifter måste förstås och följas av personal som använder eller utför service på PACE produkter. 1. RISK FÖR STRÖMSTÖT - Service / Reparation av PACE produkter får endast utföras av aktoriserad service personal. Strömförande delar kan kommas åt när produkten är isärplockad. Iaktag aksamhet när felsökning görs för att undvika strömstötar.
-
Page 15: Set-Up
Set-Up Set-up Set up the ST 85 system using the following steps and associated drawings. 1. Store the shipping container(s) in a convenient location. Reuse of these containers will prevent damage if you store or ship the system. 2. Place the Power Switch in the “OFF” or “0”... -
Page 16: Tip & Tool Stand
Tool Stand. Air Supply Connection The ST 85 system utilizes an integral air venturi system to provide air pressure and vacuum for any connected PACE SensaTemp air handpiece. Your in-house air supply (regulated to 5.48 Bar (80 P.S.I.); see "Specifications") must be connected to the system power source. -
Page 17: Handpiece Vacuum/Pressure
6 inches from the ends of the handpiece. c) If you have a PACE system incorporating 2 or more air handpieces, you may wish to leave the air hose assembly unattached to allow a quick change to... - Page 18 Vacuum Port. 3. When using air pressure, and/or utilizing multiple air handpieces, PACE recommends the use of the following set up procedure which utilizes additional quick connect hose mount fittings. An assortment of quick connect air fittings are supplied with each additional air handpiece.
-
Page 19: Handpiece Connection
Set-Up Handpiece Connection Connect the handpiece connector plug into the Power Receptacle in the following manner. 1. Align guide on connector with slot on power receptacle. 2. Insert connector into power receptacle. 3. Turn the connector housing clockwise to lock in place. System Power Up 1. -
Page 20: Heater Burn In
A Red tag is attached to each handpiece and with replacement heater assemblies which describes the proper procedure. The ST 85 system however, has a Burn In feature which, when activated will burn in the TJ-70 heater in a similar manner as is described on the tag. - Page 21 Set-Up 8.At the conclusion of the 15 minute time period, power is removed from the heater. The Display will read “End”. Press and release the Scroll Up Key ( ) to exit Heater Burn In and return the to normal operation. NOTE The microprocessor circuitry within the unit monitors the system to ensure proper results.
-
Page 22: Quick Start - Basic Operation
Quick Start - Basic Operation Introduction The ST 85 system is very easy to operate. As received from the factory, the system can be quickly set up for use in standard desoldering/soldering operations. Simply perform the following Quick Start Procedure to begin system operation. -
Page 23: Operation
Operation IMPORTANT PACE recommends that you not read the “Set-Up Mode” section until after you feel comfortable with system operation. Please read the following “Operation" section thoroughly before changing the system settings. Definitions Please read and become familiar with the definitions of each of the following terms which are used repeatedly in the following operational procedures. -
Page 24: Password
True Tip Temperatures can differ greatly from temperature settings when using larger SMT soldering tips. This difference is called Tip Temperature Offset. The ST 85 Auto Tip Temperature Compensation feature lets you set and display true tip temperatures regardless of size and type of tip or handpiece. PACE recommends the use of the Tip &... -
Page 25: Led Display, Normal Operation
Operation The ST 85 system is very easy to adjust and operate. The following instructions detail system features and operation of the system. Also included is a "Quick Tour" of system operation. Information regarding changing of system options (e.g., Temperature Setback time, Auto Off) is contained in the "Set-Up Mode"... -
Page 26: Led Display, Temperature Adjust Mode
Operation 8 Error messages ("OSE", "SSE" or "OCE") if a system fault is detected. Refer to the "Corrective Maintenance" portion of this manual. LED Display, Temperature Adjust Mode The LED Display will show the following when adjusting the desired Set Tip Temperature. -
Page 27: Temperature Setback
Operation Temperature Setback To preserve tip life and save energy, the ST 85 system can be programmed to automatically set back its Tip Temperature to 177°C (350°F) after a selected period of handpiece inactivity (adjustable 10-90 minutes in Set-Up Mode). As received from the factory, this feature is enabled. -
Page 28: Exiting Temperature Setback
Temperature. For optimum performance, do not attempt to use the attached handpiece until the Set Tip Temperature is achieved. Auto Off Safety System When enabled, the Auto Off safety system of the ST 85 system removes power 10-90 minutes (enabled/disabled and adjustable in Set-Up Mode) after entering Temperature Setback. -
Page 29: Quick Tour
Operation Quick Tour 1. Ensure that the Set-Up procedure has been performed; including the Heater Burn In procedure. Check for the following: a) Handpiece connection to the power source. b) Proper tip installed in handpiece. c) Power cord connection between house AC supply receptacle and the power source. - Page 30 This is especially important when using large soldering tips or other SensaTemp handpieces. 12. If you have a Sodr-X-Tractor or other PACE air handpiece connected to your system, press and hold the Vacuum Switch. You will hear a clicking noise as the air is turned on in the system.
-
Page 31: Factory Settings
Operation FACTORY SETTINGS The ST 85 system comes equipped with a number of features which may be adjusted, enabled or disabled as desired by the user. Listed below are the features and factory settings of each. To change and/or learn about any of these features, refer to the applicable part of the “Set-Up Mode”... -
Page 32: Set-Up Mode
Set-Up Mode Introduction The menu driven LED Display of the ST 85 system in the Set-Up Mode allows you to easily customize your system. No calibration adjustments are necessary to maintain the accuracy of the system. In Set-Up Mode, you can: 1. -
Page 33: Operation
Set-Up Mode Operation Password 4. The LED Display will display the version of the microprocessor and change to read “P--” or "EP0". 5. If the display reads "EP0", a Password has been stored in system memory. Enter the 5 key sequence Password. -
Page 34: Temperature Limits
Set-Up Mode Temperature Limits 9. The LED Display now shows the stored default High ("Hi") Temperature Limit with the display alternating to show "Hi" and the stored limit. Choose one of the following: a) Press and release the Program Key ( ) to keep the stored High Temperature Limit. -
Page 35: Offset Constant
Set-Up Mode Offset Constant 11. The LED Display now shows the stored Offset Constant with the display alternating to show "OF" and the stored Offset Constant. Choose one of the following: a) Press and release the Program Key ( ) to keep the currently stored Offset Constant. -
Page 36: Auto Off
Set-Up Mode Auto Off 13. The LED Display now shows the stored Auto Off time as "AOx" (x=0 thru 9). Time is shown as tens of minutes (e.g., "AO3" equals 30 minutes). A display of "AO0" indicates that Auto Off is disabled. Choose one of the following: a) Press and release the Program Key ( ) to keep the... -
Page 37: Corrective Maintenance
Corrective Maintenance LED Display Message Codes Listed below are message codes which may be shown on the LED Display if a mistake is made by the operator (e.g., wrong Password entry) or if the system has malfunctioned. LED Display Description Message The incorrect Password has been entered. -
Page 38: Power Source
Corrective Maintenance Power Source Most malfunctions are simple and easy to correct. Refer to Table 3. Symptom Probable Cause Solution No power to system. Blown Fuse Check handpiece using Table 2. Replace the fuse (located in the AC Receptacle/Fuse Holder) with one of same value (see Table 4, Spare Parts). -
Page 39: Handpieces
Handpieces The following “Heater Assembly Checkout Procedures” (Table 4) is applicable to all PACE SensaTemp handpieces used with the ST 85 system except for the TT- 65 and DTP-80 handpieces. Refer to the applicable manuals for troubleshooting procedures pertinent to that handpiece. -
Page 40: Packing List/Spare Parts
1259-0081 Operation & Maintenance Manual 5050-0455 Table 5. Packing List Spare Parts Item # Description Part Number 1.0 Amp Time Lag (ST 85) 1159-0246 Fuse, 0.5 Amp Time Lag (ST 85E) 1159-0213 SX-80 Heater Assembly 6010-0107-P1 Replacement PCB Assembly 6020-0127-P1 Tip &... - Page 41 Do NOT return defective equipm ent or parts to PACE without obtaining prior authorization. Any warranty or other claim with respect to the equipm ent m ust be m ade in writing and delivered to PACE (or local authorized PACE Distributor outside the U.S.) within a reasonable tim e of the expiration date of this warranty.
