8.1.4 Reseting default values
It is strongly recommended resetting all of the default values of your SmartMatriX² unit before setting up your
shows and events. This will help eliminate confusion caused by unneeded settings from a previous operator.
To do so, press the EXIT/MENU button and select Control in the menu by rotating the corresponding knob.
Then press the ENTER button to enter the Reset/Erase sub-menu. Select Default Values by rotating the scroll
knob, and press the ENTER button to enter your choice to restart your SmartMatriX² with its factory settings.
This operation should take approximately 30 seconds.
8.1.5 SmartMatriX² color codes
Analog Way engineers have developed a handy, user friendly way of identifying machine status on the front
panel, via the use of color codes on the buttons of the machine. All new Analog Way machines use the same
codes, for quick recognition of the status of any device of the range, at any given time.
For the SmartMatriX², button color codes are as follow:
• Sources on the Program output are indicated in
• Sources on the Preview output are indicated in
• Buttons in the layer section turn
respectively the Program or Preview window,
• menu buttons are indicated in green,
• Selecting a button with an available source or function will cause that button to blink
or red once it is on the Program output,
• TAKE button reacts as follows:
- If take function is available, the button will appear in green.
- When the take function is active, it will light up red.
#1 = Source is on the Program output
Solid red:
#2 = Freeze enable
#1 = Source is on Preview
Solid green:
#2 = Function available for modification
#3 = Current output on Matrix mode
Layer/source selected or is currently active
Blinking red:
on the Program output
Layer/source selected or is not currently
Blinking green:
active on the Program output

8.2 Settings in Matrix mode

8.2.1 Source Input selection
Plug your sources using the 4 multi-plug inputs, 2 HDMI®Inputs or 4 3G/HD/SD-SDI inputs.
Be sure that all connectors are firmly attached using all available locking screws.
8.2.2 Input selection settings
To set up your inputs automatically: Inputs menu > Auto settings
You can also do it manually on each input# using the ENTER and the Knob button and set up the inputs type
one by one.
You can also check your actual input configuration using the config status: Inputs menu > Config Status
red when active,
green when active,
red or green, depending on whether the selected layer is active in
8.1.4 Reseting default values
green on the preview,
