4.5.5 Output Computer formats
The SmartMatriX² outputs support GTF (version 1.1), CVT (version 1.1) and DMT (version 1.0 rev 12) stan-
dards. Other non-standard formats are supported via the custom format capability of the framework.
The SmartMatriX² offers a list of pre-defined output formats. The list of output formats is always displayed
from increasing number of pixels per line and then number of lines.
Format Size
VGA 640x480
WVGA 848x480
SVGA 800x600
720p 1280x720
XGA 1024x768
WXGA 1280x768
SWXGA 1360x768
1366x768 1366x768
WXGA2 1280x800
SWXGAP 1366x800
1152x864
900p 1440x900
1440x900
1600x900
1280x960
SXGA 1280x1024
1360x1024
SXGAP 1400x1050

4.6 Input specifications

The SmartMatriX² offers 10 seamless inputs. Some inputs contain several plugs.
A plug corresponds to a socket or connector on the rear panel.
The following types of plugs are available on the rear panel:
- HDBaseT (only for Ref. SMX250-H)
- HDMI®
- Single DVI-D (HDMI®compatible),
- 3G/HD/SD-SDI (BNC),
- Universal Analog (HD-15)
Frequency
Aspect ratio
50 Hz 60 Hz
4/3 Yes Yes
16/9 Yes Yes
4/3 Yes Yes
16/9 Yes Yes
4/3 Yes Yes
5/3 Yes Yes
16/9 Yes Yes
16/9 Yes Yes
16/9 Yes Yes
5/3 Yes Yes
4/3 Yes Yes
16/10 Yes Yes
3/2 Yes Yes
16/9 Yes Yes
4/3 Yes Yes
5/4 Yes Yes
4/3 Yes Yes
5/3 Yes Yes
4.5.5 Output computer formats
Format Size Aspect ratio
WSXGAP 1680x1050
1080p 1920x1080
2K 2048x1080
UXGA 1600x1200
WUXGA 1920x1200
2048x1152
Frequency
50 Hz 60 Hz
16/9 Yes Yes
16/9 Yes Yes
17/9 Yes Yes
4/3 Yes Yes
16/9 Yes Yes
16/9 Yes Yes
