7.4 Live
You can load at any moment a frame or a logo in the same way into a frame or logo layer.
To activate the QUICK FRAME, simply press the Quick Frame button (located on the right side of each screen).
Remember that a preset saved into a screen with a 1024x768 resolution, will keep its size into a screen of
higher resolution. Therefore, it is best to save preset memories only after you have configured the output
resolution.
You still have access to the LOAD/SAVE/RESET preset feature.
Once your preset is ready to send, use the T-bar, or the TAKE button.
You still have access to STEP BACK button.
When you use several screens, you have the possibility to load a preset on one or several screens. To TAKE
only one screen separately, select which screens should be affected by the TAKE using this button:
SEQUENCE:
The sequence feature consists on a timeline composed by 16 scenes. Each scene can be filled by a preset
memory. Simply click on MM to choose the memory slot you want to put into the scene.
To select the memory, simply choose it into the list or drag and drop it into the scene box from the memories
selection (on the right).
This toolbar acts like a command for your timeline.
Simply click on play to launch the timeline.
You can stop the timeline at any moment using the pause or stop button.
Use the loop button to load again your timeline when it's finished.
Take a look at the global time of your timeline thanks to the clock on the right of the toolbar.
Note: To control the SmartMatriX², Analog Way also provides Crestron and AMX modules. For more details,
see appendices.
