SMART SCALER
(SMS100)
User's Manual
TABLE OF CONTENTS
SAFETY INSTRUCTIONS ...........................................................................................................................................................2
Chapter 1 : INTRODUCTION .......................................................................................................................................................4
Chapter 2 : INSTALLING .............................................................................................................................................................5
Chapter 3 : TECHNICAL DESCRIPTION....................................................................................................................................6
Chapter 4 : STARTING .................................................................................................................................................................7
Chapter 5 : OPERATING MODE................................................................................................................................................10
Chapter 6 : LCD SCREEN...........................................................................................................................................................11
Chapter 7 : LCD MENUS DESCRIPTION .................................................................................................................................13
Chapter 8 : TECHNICAL SPECIFICATIONS ............................................................................................................................17
Chapter 9 : CONTROL SOFTWARE..........................................................................................................................................19
Chapter 10 : RS-232 PROGRAMMER'S GUIDE .......................................................................................................................22
Chapter 11 : TROUBLESHOOTING ..........................................................................................................................................30
Chapter 12 : OPTIONAL ACCESSORIES..................................................................................................................................31
WARRANTY...............................................................................................................................................................................32
®
ANALOG WAY
SMART SCALER™
EDITION : 02/02
.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Analog way SMART SCALER SMS100
Summary of Contents for Analog way SMART SCALER SMS100
-
Page 1: Table Of Contents
Chapter 7 : LCD MENUS DESCRIPTION ..........................13 Chapter 8 : TECHNICAL SPECIFICATIONS ..........................17 Chapter 9 : CONTROL SOFTWARE............................19 Chapter 10 : RS-232 PROGRAMMER'S GUIDE ........................22 Chapter 11 : TROUBLESHOOTING ............................30 Chapter 12 : OPTIONAL ACCESSORIES..........................31 WARRANTY....................................32 ® ANALOG WAY SMART SCALER™ EDITION : 02/02... -
Page 2: Safety Instructions
SMART SCALER™ SAFETY INSTRUCTIONS All of the safety and operating instructions should be read before the product is operated and should be retained for further reference. Please follow all of the warnings on this product and its operating instructions. CAUTION : WARNING : To prevent the risk of electric shock and fire, do not expose this device to rain, humidity or intense heat sources (such as radiators or direct sunlight). - Page 3 SMART SCALER™ SICHERHEITSHINWEISE : DEUTSCH Um den Betrieb dieses Geräts zu verstehen, raten wir Ihnen vor der Inbetriebnahme alle Sicherheits und Betriebsanweisungen genau zu lesen. Diese Sicherheits- und Betriebsanweisungen für einen späteren Gebrauch sicher aufbewahren. Alle in den Unterlagen, an dem Gerät und hier angegebenen Sicherheitsanweisungen einhalten.
-
Page 4: Chapter 1 : Introduction
Chapter 1 : INTRODUCTION SMART SCALER™ ™ SMART SCALER Chapter 1 : INTRODUCTION 1-1. SUPPLIED EQUIPMENT • 1 SMART SCALER (SMS100) • 1 Set of 19” Brackets • 1 AC Power supply cord • 1 VGA cable (HD15 Male / Male) •... -
Page 5: Chapter 2 : Installing
SMART SCALER™ Chapter 2 : INSTALLING Chapter 2 : INSTALLING • Table Top Mounting : The SMART SCALER™ can be used directly on a table: the unit is equipped with 4 plastic feet. • Rack Mounting : The SMART SCALER ™ is compatible with a 19" enclosure . Please follow the instructions below to install the SMART SCALER™... -
Page 6: Chapter 3 : Technical Description
Chapter 3 : TECHNICAL DESCRIPTION SMART SCALER™ Chapter 3 : TECHNICAL DESCRIPTION 3-1. FRONT PANEL COMPUTER : COMPUTER input selection. COMPOSITE 1 : COMPOSITE 1 input selection. COMPOSITE 2 : COMPOSITE 2 input selection. S.VIDEO 1 : S.VIDEO 1 input selection. S.VIDEO 2 : S.VIDEO 2 input selection. -
Page 7: Chapter 4 : Starting
SMART SCALER™ Chapter 4 : STARTING Chapter 4 : STARTING 4-1. CONNECTIONS Turn OFF all of your equipment before connecting, Connect the AC Power supply cord to the SMART SCALER™ and to an AC power outlet, Connect your video sources (VCR, DVD, camera, laser disc, ...) to the C.V1, C.V2, S.VIDEO 1, S.VIDEO 2 and RGB.S or COMPONENT (R-Y, Y, B-Y) inputs, Connect your computer source to the COMPUTER INPUT, Connect the "DISPLAY OUTPUT"... - Page 8 Chapter 4 : STARTING SMART SCALER™ 4-3. S.VIDEO INPUTS The S.VIDEO (Super Video) signal, also called Y/C, HI-8™, or S.VHS™, is available on most DVD players and high quality VCR (S.VHS). The S.VIDEO signal, in which the Luminance (Y) and Chrominance (C) informations are separately transmitted (2 wires), gives a higher quality picture than the Composite video signal.
-
Page 9: Computer Input
SMART SCALER™ Chapter 4 : STARTING COMPONENT VIDEO SIGNAL (Y, R-Y, B-Y) The Component Video signal, also called YUV (Y, R-Y, B-Y), or BETACAM™, is widely used in broadcasting and is available on high-quality DVD players. The COMPONENT signal is transmitted with 3 coaxial cables, and also has a better picture quality than COMPOSITE and S.VIDEO signals. -
Page 10: Chapter 5 : Operating Mode
Chapter 5 : OPERATING MODE SMART SCALER™ Chapter 5 : OPERATING MODE 5-1. SETTINGS We recommend to reset the SMART SCALER™ to all of its default values, with the LCD menu # 4-5, before proceeding. Select the video type of the signal connected to the RGB/YUV input (LCD menu # 1-3). Select the type of screen (4/3 or 16/9) in LCD menu # 2-4. -
Page 11: Chapter 6 : Lcd Screen
SMART SCALER™ Chapter 6 : LCD SCREEN Chapter 6 : LCD SCREEN 6-1. LCD DESCRIPTION The LCD screen is composed of 2 modes: the STATUS MODE and the CONTROL MODE. • The STATUS MODE indicates the input and output status of the SMART SCALER™. •... -
Page 12: Control Mode
Chapter 6 : LCD SCREEN SMART SCALER™ 6-3. CONTROL MODE The menus of the CONTROL MODE are configured as follow : 1 input menu 1 video standard video standard auto manual c.video 1 auto c.video 2 NTSC 2 video status The LCD displays the s.video 1 selected video status... -
Page 13: Chapter 7 : Lcd Menus Description
SMART SCALER™ Chapter 7 : LCD MENUS DESCRIPTION Chapter 7 : LCD MENUS DESCRIPTION [INPUT MENU] + ENTER [video standard] + ENTER Select an item with + ENTER • [auto] = Automatic recognition of the video standard for each input. If the standard is not detected correctly, please use the [MANUAL] setting. - Page 14 Chapter 7 : LCD MENUS DESCRIPTION SMART SCALER™ [output format] + ENTER The output formats available depend on the "OUTPUT RATE" selection (LCD menu #2-3) Select an output format with + ENTER • If [output rate] = [video in rate], the LCD window displays the following formats : •...
- Page 15 SMART SCALER™ Chapter 7 : LCD MENUS DESCRIPTION [IMAGE MENU] + ENTER NOTE : This menu is available and active only on the selected video source. This menu is not available for the COMPUTER INPUT. The image settings and adjustments can be different and separately memorized for each video input. [H position] + ENTER Adjust the Horizontal position with + ENTER...
- Page 16 Chapter 7 : LCD MENUS DESCRIPTION SMART SCALER™ [CONTROL MENU] + ENTER [languages] + ENTER [panel locking] + ENTER Select which locking function you need with + ENTER • [all unlock] = All front panel switches are Unlocked. • [all lock] = All front panel switches are Locked. [black delay] + ENTER This function allows to adjust the duration of the black delay when switching between sources.
-
Page 17: Chapter 8 : Technical Specifications
SMART SCALER™ Chapter 8 : TECHNICAL SPECIFICATIONS Chapter 8 : TECHNICAL SPECIFICATIONS 8-1. VIDEO INPUTS • RGB.S (4 BNC connectors) 15.625 kHz / 50 Hz ..15.735 kHz / 60 Hz (625L ..525L) Levels: R, G, B = 3 x 0.7 Vp/p SYNC. - Page 18 Chapter 8 : TECHNICAL SPECIFICATIONS SMART SCALER™ 8-4. REMOTE PORT (DB 9 female connector) Levels: RS-232 Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control. 8-5. ROOM CONTROL (3.5 jack female connector) NOTE: The ROOM (+12 Vdc Trigger) Control is activated by the AC Power Switch (ON/OFF). •...
-
Page 19: Chapter 9 : Control Software
SMART SCALER™ Chapter 9 : CONTROL SOFTWARE Chapter 9 : CONTROL SOFTWARE 9-1. CONNECTION • CONNECTING THE RS-232: Connect the serial port of your Controlling Device to the REMOTE CONTROL (RS-232) connector (DB 9 Female) of the SMART SCALER™ with a straight cable (DB 9 Female / DB 9 Male). •... -
Page 20: Software Setup
Chapter 9 : CONTROL SOFTWARE SMART SCALER™ 9-3. SOFTWARE SET UP Select the Serial port in the Control menu, The SMART SCALER™ is now connected to the computer ; do a Reset to default values (Control menu) if necessary. In the Input menu, select the video type for the RGB / YUV input, and select the video standard for all of the other video inputs. - Page 21 SMART SCALER™ Chapter 9 : CONTROL SOFTWARE In the Output menu, select the Output rate, the Output format, the Output Sync and the Type of screen. In the Image and Process menus, do the adjustments for all of your video TV inputs. NOTE : •...
-
Page 22: Chapter 10 : Rs-232 Programmer's Guide
Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART SCALER™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE 10-1. INTRODUCTION If you need to use your own Software Control program from a PC or WORKSTATION with an RS-232 port, the SMART ™ SCALER allows communication through an ASCII code protocol. ™... - Page 23 SMART SCALER™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE 10-4. COMMANDS AND RESPONSES TABLE The following table resumes commands which are recognized as valid and the responses that will be returned to the host (on the RS-232 port). COMMAND RESPONSE COMMAND VALUE EXAMPLE ASCII...
-
Page 24: Input Commands
Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART SCALER™ 10-5. COMMANDS DESCRIPTION Values sent or received are in decimal. Depending on the command letter, the value can be used as a linear control (ex : 255W to set the horizontal size to the maximum) or as a set of bits (ex : P command with multiple controls). In this case, the value must be converted in binary base to understand every bit action. -
Page 25: Output Commands
SMART SCALER™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE OUTPUT COMMANDS • o command is used to select the Output Sync. type. DECIMAL VALUE SELECTION RESPONSE (OUTPUT SYNC TYPE) SEPARATE H & V SYNC. OSIG0 COMPOSITE SYNC. OSIG1 • O command is used to select the output format. Use the following table when the u command (Output Frame Rate) is set on Video In Rate (SSYNC3). -
Page 26: Image Commands
Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART SCALER™ IMAGE COMMANDS The following commands are active only on the selected (displayed) video input. They are not active for the COMPUTER input. • H, V, W, S, B, C, s, T, commands are used to control the output adjustments. 0 = minimum 255 = maximum •... - Page 27 SMART SCALER™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE • P command returns the Computer status. (RESPONSE : CSTA__). Bit 2 Bit 1 Bit 0 0 = No sync. detected 1 = Sync. detected 0 = H & V sync. detected 1 = COMP sync.
-
Page 28: Miscellaneous Commands
Chapter 10 : RS-232 PROGRAMMER'S GUIDE SMART SCALER™ MISCELLANEOUS COMMANDS • Y command is used to control different menus like the FRONT PANEL LOCK, the FREEZE… (RESPONSE : CMD----). Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7... - Page 29 SMART SCALER™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE 10-6. ASCII / HEX / DEC TABLE ASCII ASCII ASCII space " & ’ < > PAGE 29...
-
Page 30: Chapter 11 : Troubleshooting
Chapter 11 : TROUBLESHOOTING SMART SCALER™ Chapter 11 : TROUBLESHOOTING SYMPTOM CAUSE CORRECTION PLEASE SEE • NO POWER • The power cord is disconnect. • Connect the AC power cord to the • Chapter 4-1 The LCD is OFF SMART SCALER and to the power outlet. •... -
Page 31: Chapter 12 : Optional Accessories
SMART SCALER™ Chapter 12 : OPTIONAL ACCESSORIES Chapter 12 : OPTIONAL ACCESSORIES DESIGNATION LENGTH REFERENCE S-VIDEO (Y/C) CABLE (4 pin mini DIN M/M) 5 m / 16 ft 10093 S-VIDEO (Y/C) CABLE (4 pin mini DIN M/M) 10 m / 33 ft 10094 S-VIDEO (Y/C) TO 2 BNC CABLE (4 pin mini DIN M/ BNC M) 1.8 m / 6 ft... -
Page 32: Warranty
SMART SCALER™ WARRANTY Analog Way warrants the product against any defects in material and workmanship for a period of three years from the date of purchase (back to the factory). In the event of any malfunction during the warranty period, Analog Way will, at its discretion, repair or replace the defective unit, including free material and labor.
