Summary of Contents for Analog way BROAD SCAN HD BHD930-AG
- Page 1 User’s Manual BROAD SCAN HD MODEL: BHD930-AG & BHD930-DG BROAD SCAN SDI MODEL: BSD830-AG & BSD830-DG BROAD SCAN MODEL: BSC730 ANALOG WAY® BROAD SCAN (HD/SDI) – AW 5002 EDITION : 07 / 07...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS All of the safety and operating instructions should be read before the product is operated and should be retained for further reference. Please follow all of the warnings on this product and its operating instructions. CAUTION: WARNING: To prevent the risk of electric shock and fire, do not expose this device to rain, humidity or intense heat sources (such as heaters or direct sunlight). -
Page 3: Instructions De Sécurité
BROAD SCAN (HD/SDI) INSTRUCTIONS DE SÉCURITÉ Afin de mieux comprendre le fonctionnement de cet appareil nous vous conseillons de bien lire toutes les consignes de sécurité et de fonctionnement de l’appareil avant utilisation. Conserver les instructions de sécurité et de fonctionnement afin de pouvoir les consulter ultérieurement. Respecter toutes les consignes marquées dans la documentation, sur le produit et sur ce document. -
Page 4: Instrucciones De Seguridad
SICHERHEITSHINWEISE Um den Betrieb dieses Geräts zu verstehen, raten wir Ihnen vor der Inbetriebnahme alle Sicherheits- und Betriebsanweisungen genau zu lesen. Diese Sicherheits- und Betriebsanweisungen für einen späteren Gebrauch sicher aufbewahren. Alle in den Unterlagen, an dem Gerät und hier angegebenen Sicherheitsanweisungen einhalten. -
Page 5: Table Of Contents
6-4. USING THE SOFTWARE ...31 Chapter 7 : TECHNICAL SPECIFICATIONS ...34 7-1. COMPUTER INPUTS...34 7-2. VIDEO OUTPUTS ...34 7-3. ANALOG GENLOCK (MODELS: BHD930-AG, BSD830-AG & BSC730) ...36 7-4. DIGITAL GENLOCK (MODELS: BHD930-DG & BSD830-DG) ...36 7-5. COMMUNICATION PORTS ...36 7-6. ENVIRONMENTAL ...37 APPENDIX A: PROGRAMMER'S GUIDE...38... -
Page 6: Quick Start Guide - Broad Scan (Hd/Sdi)
Turn ON the BROAD SCAN (rear panel switch). Then turn ON your input source and then your display devices. * The SDI outputs are available on BHD930 & BSD830 models only. • Example of connection (Model: BHD930-AG): • RGB/COMPONENT output connection:... -
Page 7: Chapter 1 : Introduction
Broad Scan HD features a powerful broadcast Genlock. Two versions of the Broad Scan HD offer either a Digital HD/SD-SDI Genlock (Model BHD930-DG) or an Analog HD Black or Black Burst Genlock (Model BHD930-AG). Genlock input is fitted with a loop through output allowing chaining devices. The user can adjust phase and subcarrier delay according to the specific installation requirements. -
Page 8: Broad Scan Sdi Information
Chapter 1 : INTRODUCTION (continued) 1-3. BROAD SCAN SDI INFORMATION Broad Scan SDI by Analog Way is a Broadcast and Professional Computer to Video Scan Converter. Fitted with Digital DVI and Analog RGB input, it converts Workstation, PC or Mac graphic images up to1600x1200 @ 60Hz (1920x1200 RB) into NTSC or PAL Video. -
Page 9: Broad Scan Information
The exact adjustments of the frequently used formats are instantly recalled which makes the Broad Scan ideal and very useful for multi-computer applications or rental. 1-5. DEVICES & OPTIONS REFERENCES REFERENCE BHD930-AG BROAD SCAN HD with analog genlock. BHD930-DG BROAD SCAN HD with digital genlock. -
Page 10: Broad Scan Hd (Bhd930) & Broad Scan Sdi (Bsd830) Front Panel Description
Chapter 1 : INTRODUCTION (continued) 1-7. BROAD SCAN HD (BHD930) & BROAD SCAN SDI (BSD830) FRONT PANEL DESCRIPTION • BROAD SCAN HD ANALOG WAY • BROAD SCAN SDI ANALOG WAY ON / OFF: FRAME: FREEZE: UNDER/OVER: ASPECT RATIO: 1/1: Cropped: Full Screen: PAN &... -
Page 11: Broad Scan Hd (Bhd930) Rear Panel Description
AUDIO IN: RGB INPUT: RGB MONITOR OUT: DVI-D INPUT: DVI-D MONITOR OUT: Digital computer output (loop-through) on DVI-D female connector. ANALOG GENLOCK (Available on BHD930-AG model only). INPUT: LOOP OUT: DIGITAL GENLOCK (Available on BHD930-DG model only). INPUT: LOOP OUT:... -
Page 12: Broad Scan Sdi (Bsd830) Rear Panel Description
Chapter 1 : INTRODUCTION (continued) 1-9. BROAD SCAN SDI (BSD830) REAR PANEL DESCRIPTION O / I: POWER: RS-232: IP/LAN: COMPUTER INPUT & MONITOR AUDIO IN: RGB INPUT: RGB MONITOR OUT: DVI-D INPUT: DVI-D MONITOR OUT: Digital computer output (loop-through) on DVI-D female connector. ANALOG GENLOCK (Available on BSD830-AG model only). -
Page 13: Broad Scan (Bsc730) Front Panel Description
BROAD SCAN (HD/SDI) 1-10. BROAD SCAN (BSC730) FRONT PANEL DESCRIPTION ANALOG WAY ON / OFF: BLACK: FREEZE: UNDER/OVER: ASPECT RATIO: 1/1: Cropped: Full Screen: PAN & ZOOM POS. SIZE: ZOOM: FINDER: H/V: CENTERING: MENU CONTROL ENTER: EXIT MENU: Switch ON or OFF the device (Long push). Allows displaying a black screen onto the output. -
Page 14: Broad Scan (Bsc730) Rear Panel Description
Chapter 1 : INTRODUCTION (continued) 1-11. BROAD SCAN (BSC730) REAR PANEL DESCRIPTION O / I: POWER: RS-232: IP/LAN: COMPUTER INPUT & MONITOR RGB INPUT: RGB MONITOR OUT: DVI-D INPUT: DVI-D MONITOR OUT: Digital computer output (loop-through) on DVI-D female connector. ANALOG GENLOCK INPUT: LOOP OUT:... -
Page 15: Chapter 2 : Starting
Turn ON the BROAD SCAN (rear panel switch). Then turn ON your input source and then your display devices. * The SDI outputs are available on BHD930 & BSD830 models only. • Example of connection (Model: BHD930-AG): • RGB/COMPONENT output connection:... -
Page 16: Settings
Chapter 2 : STARTING (continued) 2-2. SETTINGS We recommend resetting the BROAD SCAN to all of its default values, with the front panel display menu (CONTROL default value yes) before proceeding. Select the auto-setting menu with the front panel display menu (INPUT Auto setting) and activate this function with ENTER. -
Page 17: Chapter 3 : Using Frame Store And Logo Insertion (Bhd930 & Bsd830)
BROAD SCAN (HD/SDI) Chapter 3 : USING FRAME STORE AND LOGO INSERTION 3-1. LOGO INSERTION This function allows storing up to 4 static logos & 1 animated logo in order to incrust them into the displayed image. • HOW TO STORE A STATIC LOGO: Connect the source of the logo to be stored to the input of the BROAD SCAN. -
Page 18: Using The Frame Store
3-2. USING THE FRAME STORE This function allows memorizing a frame (an image) in order to display it at any time during the show. • HOW TO STORE A FRAME: Connect the source of the frame to be stored to the input of the BROAD SCAN. Perform and auto-setting to display it onto the output. -
Page 19: Chapter 4 : Front Panel Display Menu Description
• From the STATUS MODE, press this button to enter in the CONTROL MODE. • From the CONTROL MODE, press this button to: - return to the previous menu without safeguarding the selection. - return to the STATUS MODE (press several times). BHD930-AG Version _._ Input : SVGA H = 37.9K... -
Page 20: Control Mode
Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) 4-4. CONTROL MODE The menus of the device are configured as follow: INPUT Auto Setting Input Status Input Type H. Sync. Load OUTPUT Status Format Genlock Tune Type Pedestral Test pattern IMAGE Auto Centering Optimize... - Page 21 BROAD SCAN (HD/SDI) Frame ON/OFF LOGOS/FRAME Logo Record Frame Record Logo Record Anim Erase Frame Erase Logo CONTROL Versions Zoom type Auto Frame ON/OFF RS232/LAN port LAN setup Key locking Stand-by Edit EDID DVI EDID Selection Erase memories Default value Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) Logo OFF Logo 1...
-
Page 22: Functions Description
Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) 4-5. FUNCTIONS DESCRIPTION [INPUT] [Auto settings] This function detects automatically the input type of the source connected to the input connectors (DVI & RGB). Then the device performs an auto-centering function. [Input status] Indicates the status of the selected input. - Page 23 BROAD SCAN (HD/SDI) 4-5. FUNCTIONS DESCRIPTION (continued) [Genlock Tune]. This function is available only if the Output format selected is Genlock, and if a correct genlock signal is detected on the GENLOCK INPUT connector. This function allows adjusting the genlock horizontal phase. Adjust with [H Phase]: [SC.
- Page 24 Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) 4-5. FUNCTIONS DESCRIPTION (continued) [Gamma] Select one of the 8 levels of the anti-flicker with [Flicker filter] Select one of the 8 levels of the anti-flicker with [Sharpness] Adjust the image sharpness with [Preset] This function allows to set all the image parameters (flicker filter, Black level, RGB level, under/overscan, position &...
- Page 25 BROAD SCAN (HD/SDI) 4-5. FUNCTIONS DESCRIPTION (continued) [LOGOS/FRAME] Available on BHD930 & BSD830 models. [Frame ON/OFF]. Display ON or OFF the stored frame onto the output. [Logo] [Logo OFF]: Display off the logo. [Logo 1]: Display the logo 1. [Logo 2]: Display the logo 2. [Logo 3]: Display the logo 3.
- Page 26 Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) 4-5. FUNCTIONS DESCRIPTION (continued) [Record anim] This mode allows storing an animated logo in order to incrust them into the displayed image. Select an item with + ENTER. [Position] Adjust the position of the logo area with [Size] Adjust the size of the logo area with NOTE: The logo area is limited at an eighth (1/8) of the displayed area.
- Page 27 BROAD SCAN (HD/SDI) 4-5. FUNCTIONS DESCRIPTION (continued) [LAN setup] + ENTER. (Available with the LAN option only) Allows configuring the LAN communication port. Select the UDP or TCP protocol with select items with Every device connected to an IP network must have a unique IP address. This address is used [device addr.]: to reference the specific unit.
- Page 28 Chapter 4 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued) 4-5. FUNCTIONS DESCRIPTION (continued) [Edit EDID DVI] Extended Display Identification Data (EDID) is a data structure provided by a computer display to describe its capabilities to a graphics card. The Broad Scan allows to edit a format when none control monitor (computer display) is connected to the broad scan or when you need to work in another format than the native control monitor format.
-
Page 29: Chapter 5 : Updating The Device
BROAD SCAN (HD/SDI) Chapter 5 : UPDATING THE DEVICE The device can be updated thanks a computer (PC) via its RS-232 communication port or via its LAN communication port. 5-1. CONNECTIONS Connect the device to an AC power outlet. Switch ON the device (REAR PANEL SWITCH = I). Connect the device to the computer used for the update via the desired communication port. -
Page 30: Chapter 6 : Remote Control Software
Chapter 6 : REMOTE CONTROL SOFTWARE Your device is shipped with a Windows compatible Remote Control Software. This software allows you to control and make all adjustments by a simple mouse click. NOTE: Preferably use Windows NT, 2000 or XP for LAN operation. 6-1. -
Page 31: Using The Software
BROAD SCAN (HD/SDI) 6-3. COMMUNICATION SETUP (continued) • CASE OF LAN PORT: - With the front panel display menu of the device, verify the configuration of the LAN communication port (CONTROL > LAN setup), then activate the LAN communication port (CONTROL > RS232/LAN port > LAN). - Page 32 Chapter 6 : REMOTE CONTROL SOFTWARE (continued) 6-4. USING THE SOFTWARE (continued) Click on the Output tab and adjust your input. Click on the Image tab, and then adjust all the needed image parameters. PAGE 32 BROAD SCAN (HD/SDI)
- Page 33 BROAD SCAN (HD/SDI) 6-4. USING THE SOFTWARE (continued) Click on the Lumakey tab to accede to the Luma key adjustment. Click on the Logos Frame tab and make the genlock adjustments. NOTE: Transfer logo mode: The Remote Control Software allows transferring directly a logo from the controlling computer to the Broad scan.
-
Page 34: Chapter 7 : Technical Specifications
Chapter 7 : TECHNICAL SPECIFICATIONS 7-1. COMPUTER INPUTS • ANALOG COMPUTER INPUT HD15 female. Connector: From 31.5 kHz to 130 kHz. Line frequency: Up to 130 Hz. Frame frequency: Up to 1600 x 1200 Resolution: Signal & Sync. type: RGBHV, RGB/S, RGsB (Sync On Green). R, G, B: 0.7 Vp/p. - Page 35 BROAD SCAN (HD/SDI) 7-2. VIDEO OUTPUTS (continued) • HD-YUV / HD-YCrCb (MODELS: BHD930-AG & BHD930-DG) 3 BNC female. Connectors: 720p @ 60, 59.94 & 50 Hz (SMPTE 296M) Format: 1080i @ 60, 59.94 & 50 Hz (SMPTE 274M) 1035i @ 60 & 59.94 Hz (SMPTE 260M) 1080sF @ 30, 29.97 &...
-
Page 36: Analog Genlock (Models: Bhd930-Ag, Bsd830-Ag & Bsc730)
Same format as the output. Format: 75 Ohm. Impedance: * Available on the BSD830 & BHD930 models only. 7-3. ANALOG GENLOCK (MODELS: BHD930-AG, BSD830-AG & BSC730) 2 BNC female. Connectors: Black Burst (PAL or NTSC) or 3-level HD black. Input signal type: 75 Ohm. -
Page 37: Environmental
BROAD SCAN (HD/SDI) 7-6. ENVIRONMENTAL Power Supply: Storage Temperature: Operating temperature: Hygrometry: Dimensions: Weight: 100VAC-250VAC ; 50-60Hz ; I = 0.5A Max. - 25 °C to + 85 °C (- 13 °F to + 185 °F) 0 °C to + 50 °C (32 °F to 122 °F) 10% to 80% (without condensation) Compatible with the 19"... -
Page 38: Appendix A: Programmer's Guide
APPENDIX A: PROGRAMMER'S GUIDE A-1: INTRODUCTION If you need to use your own Software Control program from a PC or WORKSTATION with an RS-232 port, the device allows communication through an ASCII code protocol. The device treats any character that it receives on the RS-232 as a possible command but only accepts legal commands. - Page 39 BROAD SCAN (HD/SDI) A-4: COMMANDS AND RESPONSES TABLE COMMAND RESPONSE COMMAND DESCRIPTION COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE FRONT PANEL COMMANDS / COMMANDES DE LA FACE AVANT Standby function (ON/OFF) Frame selection Black function Freeze function. Under/Overscan mode selection. Output aspect ratio Horizontal position adjustment.
-
Page 40: Command Response
APPENDIX A / ANNEXE A COMMAND RESPONSE COMMAND DESCRIPTION COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE IMAGE COMMANDS / COMMANDES DU MENU IMAGE Auto-centering Optimize Clock adjustment Optimize Phase adjustment Input aspect ratio selection Output aspect ratio Under/Overscan mode selection. Red level adjustment. Green level adjustment. - Page 41 BROAD SCAN (HD/SDI) COMMAND RESPONSE COMMAND DESCRIPTION COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE LOGOS/FRAME COMMANDS / COMMANDES DU LOGO/FRAME Frame/logo mode. Status of the logo programmer Logo assignment. • In logo recording mode: Number of the logo to be store (1 to 5). •...
- Page 42 APPENDIX A / ANNEXE A COMMAND RESPONSE COMMAND DESCRIPTION COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION Communication port selection Reset of the LAN parameters. Store the LAN parameters. IP address and port selection (for modification) First byte of the address selected by the na command.
- Page 43 7 = 800x600 9 = 720p 11 = 1280x768 13 = 1280x800 15 = 1280x1024 17 = 1035i 19 = 1680x1050 21 = 1080i 23 = 1080p 25 = 1920x1200 2 = Frame 60 = BHD930-AG 62 = BSD830-AG PAGE 43...
- Page 44 APPENDIX A / ANNEXE A A-5: ASCII / HEX / DEC TABLE ASCII space " & ’ < > PAGE 44 ASCII BROAD SCAN (HD/SDI) A-5: TABLE ASCII / HEX / DEC ASCII...
-
Page 45: Warranty
BROAD SCAN (HD/SDI) Analog Way warrants the product against any defects in materials and workmanship for a period of three years from the date of purchase (back to the factory). In the event of any malfunction during the warranty period, Analog Way will, at its discretion, repair or replace the defective units, including free materials and labor.
