Table A.49: Table A.49: CN31(DG), CN25(EF), DCIN1(HI): DC-IN
Part Number
Footprint
Description
Pin
1
2
Table A.50: CN29(D), CN23(EF), CN26(G): RJ11
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
UTC-318 User Manual
1652005624
PJ_2P_2DC-G213B200
DC POWER JACK 2.5mm 90D(M) DIP 2DC-G213B200
Pin Name
DC_IN
GND
1652005977-02
S RJ11_6P_RJ1201-66N024R0
PHONE JACK RJ11 6P6C 90D(F) DIP 6u RJ1201-66N024
Pin Name
GND
Drawer_A
Drawer_state
Power
Drawer_B
GND
76
