Table 4.11: CN9(EF), CN14(G), CN18(HI): COM1, COM2 Ring
Part Number
Footprint
Description
Setting
(1-3)
(2-4)
(3-5)*
(4-6)*
(7-9)*
(8-10)*
Table 4.12: JCASH1: CASH DRAWER POWER SEL
Part Number
Footprint
Description
Setting
(1-2)
(2-3)*
UTC-318 User Manual
1653005261
HD_5x2P_79
PIN HEADER 5x2P 2.0mm 180D(M) SMD
21N22050
Function
COM1 RING
COM2 RING
COM1 RI output +5V
COM2 RI output +5V
COM1 RI output +12V
COM2 RI output +12V
1653003100
HD_3x1P_100_D
PIN HEADER 3x1P 2.54mm 180D(M) DIP 1130-
000-03S
Function
12V
24V
32
