Controller
ER Code Alarm
15 Make-up valve
16 Power failure
Stop ˃ 4 hours
19
20 Max. Make-up volume
21 Maintenance
recommended
24 Softening
30 I/O module fault
31 EEPROM defective
32 Undervoltage
33 Adjustment parameters
faulty
34 Communication
Main board faulty
35 Digital input voltage
faulty
36 Analogue input voltage
faulty
46 — English
Floating Causes
contact
- Contact water meter
measures without make-
up request.
- No power.
- Device is in Stop mode for
more than 4 hours.
- Set value exceeded.
- Set value exceeded.
- • Set value for soft
water capacity
exceeded.
• Time interval for
replacement of the
softening cartridge
exceeded.
- • I/O module defective.
• Connection between
option card and
controller faulty.
• Option card defective.
YES • EEPROM defective.
• Internal calculation
error.
YES Supply voltage not
achieved.
- EPROM parameter memory
defective.
- • Connecting cable
defective.
• Main board defective.
- Short-circuit of input
voltage.
- Short-circuit of input
voltage.
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Remedy
Check the make-up valve for leaks.
Connect to power supply.
Set the controller to Automatic
mode.
Reset the "Make-up quantity"
meter in the Customer menu.
Perform maintenance and reset
the maintenance counter upon
completion.
Replace the softening cartridges.
Inform Reflex Customer Service.
Inform Reflex Customer Service.
Check power supply.
Inform Reflex Customer Service.
Inform Reflex Customer Service.
Check the wiring at the digital
inputs (water meter, for example).
Check the wiring at the analogue
inputs (pressure/level).
Alarm reset
"Quit"
-
-
"Quit"
"Quit"
"Quit"
-
"Quit"
-
-
-
-
-
