Null balancing of the level sensor.
•
The controller checks whether the level measuring signal matches the dimensional
data of the primary tank. The primary tank must be fully emptied, see chapter 6.3.5
"Fitting the level sensor" on page 25 .
Upon successful conclusion of the null balancing, confirm with "OK" on the controller
operator panel.
Select "Yes" or "No" on the controller display and confirm with "OK" on the controller
operator panel.
yes:
The primary tank is fully emptied and the device is installed as per the instructions.
•
If null balancing is still not possible, confirm with "Yes". The start routine is
terminated. Use the customer menu to repeat the null balancing.
•
Subsequently contact your Reflex Customer Service, see chapter 12.1 "Reflex
Customer Service" on page 55 .
no:
The start routine restarts.
•
Check the prerequisites for the commissioning, see chapter 7.1 "Checking the
requirements for commissioning" on page 32 .
This message appears on the display only after null balancing has been successful.
Select "Yes" or "No" on the controller display and confirm with "OK" on the controller
operator panel.
yes:
The start routine is terminated, the device automatically switches to Stop mode.
no:
The start routine restarts.
The level indication is at 0 %.
Notice!
After successful conclusion of the start routine, you are in Stop mode.
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Commissioning
1 %
1.7 bar
Null balancing!
0 %
1.0 bar
Null balancing concluded
successfully
Cancel null balancing?
No
Terminate routine?
No
0 %
2.0 bar
STOP
English — 35
