Tanks - Reflex Reflexomat Compact RC Series Operating Manual

Technical data
5.2

Tanks

Type Diameter Ø "D"
(mm)
6 bar - 200 634
6 bar - 300 634
6 bar - 400 740
6 bar - 500 740
6 bar - 600 740
6 bar - 800 740
6 bar - 1000 1000
6 bar - 1500 1200
6 bar - 2000 1200
6 bar - 3000 1500
6 bar - 4000 1500
6 bar - 5000 1500
10 bar - 350 750
10 bar - 500 750
10 bar - 750 750
10 bar - 1000 1000
10 bar - 1500 1200
10 bar - 2000 1200
10 bar - 3000 1500
10 bar - 4000 1500
10 bar - 5000 1500
16 — English
Primary vessel
Weight Connection
(kg)
37
54
65
78
94
149
156
465
565
795
1080
1115
230
275
345
580
800
960
1425
1950
2035
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Secondary tank
Height "H"
(inches) (mm)
R1 970
R1 1270
R1 1255
R1 1475
R1 1720
R1 2185
DN65 2025
DN65 2025
DN65 2480
DN65 2480
DN65 3065
DN65 3590
DN40 1340
DN40 1600
DN50 2185
DN65 2065
DN65 2055
DN65 2515
DN65 2520
DN65 3100
DN65 3630
Height "h" Height "h1"
(mm) (mm)
115 155
115 155
100 140
100 140
100 140
100 140
195 305
185 305
185 305
220 334
220 334
220 334
190 190
190 190
180 180
165 285
165 285
165 285
195 310
195 310
195 310
