Technical data

5.1

Control unit

Note!
The following values apply for all control units:
– Permissible flow temperature:
– Permissible operating temperature:
– Permissible ambient temperature:
Type Power
output
(kW)
RC 200 0.75
RSC 200 0.75
RC 300 0.75
RSC 300 0.75
RC 400 0.75
RSC 400 0.75
RC 500 0.75
RSC 500 0.75
RS 90/1 0.75
individual
RS 90/1 0.75
firmly fitted
Power supply Degree of
(V / Hz , A) protection
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
230 / 50, 3 IP 54
Reflexomat with Basic controller — 20.06.2017 - Rev. C
120 °C
70 °C
0 °C – 45 °C
Number of RS- I/O
485 interfaces module
1 No
1 No
1 No
1 No
1 No
1 No
1 No
1 No
1 No
1 No
Electrical voltage Noise level
control unit (dB)
(V, A)
230, 2 72
< 59
230, 2
230, 2 72
< 59
230, 2
230, 2 72
< 59
230, 2
230, 2 72
< 59
230, 2
230, 2 72
230, 2 72
Technical data
Weight
(kg)
52
52
69
69
80
80
93
93
25
21
