Reflex Reflexomat Compact RC Series Operating Manual page 45

ER Code Alarm
05 Compressor run time
06 Make-up time
07 Make-up cycles
08 Pressure measurement
09 Level sensor
10 Maximum pressure
11 Make-up quantity
Floating Causes
contact
- • Set value exceeded.
• Severe water loss in
the system.
• Air lines leaking.
• Solenoid valve in the
overflow line does not
close.
- • Set value exceeded.
• Water loss in the
system.
• Make-up line not
connected.
• Make-up rate
insufficient.
• Make-up hysteresis
too low.
- Set value exceeded.
YES Controller receives
incorrect signal.
YES Controller receives
incorrect signal.
- • Set value exceeded.
• Overflow line
disabled.
• Dirt trap clogged.
- "With water meter" must
be activated in the
Customer menu.
• Set value exceeded.
• Severe water loss in
the system.
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Remedy
• Check set value in the
Customer or Service menu.
• Check the water loss and
correct, if necessary.
• Seal any leak in the air system.
• Check functioning of the
"PV1" solenoid valve.
• Check set value in the
Customer or Service menu.
• Check water level.
• Connect make-up line
• Check set value in the
Customer or Service menu.
• Seal any leak in the system.
• Connect the plug.
• Check functioning of the
pressure sensor.
• Check the cable for damage.
• Check the pressure sensor.
• Check functioning of the load
cell.
• Check the cable for damage.
• Connect the plug.
• Check set value in the
Customer or Service menu.
• Check functioning of the
overflow line.
• Clean the dirt trap.
• Check set value in the
Customer or Service menu.
• Check water loss in the system
and repair, if necessary.
Controller
Alarm reset
-
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
English — 45
