Controller
Enter the value for the minimum operating pressure.
Notice!
Calculation of minimum operating pressure, see chapter 7.2
"Determining the P
page 33 .
Switch to the "Make-up" main menu.
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
If the water content is below the specified tank size, add water, see chapter 7.3 "Modifying
the controller's start routine" on page 34 .
• If an automatic make-up device (Fillcontrol for example) is installed, make-up will be
actuated automatically; otherwise the make-up must be manually activated.
Terminate the water make-up when the specified tank size is exceeded.
• If an automatic make-up device is installed, make-up will be shut off automatically;
otherwise the make-up must be manually deactivated.
• If you have selected "No" for automatic make-up, the system will not return any
further queries about the make-up.
Pre-selected time for a make-up cycle. Upon expiry of this set time, the system interrupts
the make-up and returns the "Make-up time" fault message.
If the set number of make-up cycles is exceeded within two hours, the system interrupts
the make-up and returns the "Make-up cycles" fault message.
FQIRA+ contact water meter is installed, see chapter 4.6 "Optional equipment and
yes:
accessories" on page 14 .
This is the prerequisite for the make-up quantity monitoring and the operation of a
softening system.
no: A contact water meter is not installed (standard model).
Only displayed if "YES" has been set in the "With water meter" menu option.
• Use "OK" to delete the counter.
– Press "YES" to reset the value displayed to "0".
– Press "No" to retain the displayed value.
40 — English
minimum operating pressure for the controller" on
0
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Min.op.pressure
01.8 bar
Make-up
Make-up: ON
at: 08 %
Make-up: OFF
at: 12 %
Max. make-up time
010 min.
Max. make-up cycl.
003 / 2 h
With water meter
YES
Make-up quantity
000020 l
