Description of the device

4 Description of the device
4.1

Description

Reflexomat Compact RC
• One "RG" primary tank as an expansion tank with up to 600 litres nominal volume.
• The compact control unit is factory-installed on the primary tank.
• All electric and air connections between control unit and expansion tank are pre-installed.
Note!
It is not possible to connect secondary tanks to the Reflexomat Compact "RC".
Reflexomat RS 90 / 1
• One "RG" primary tank as an expansion tank with up to 600 litres nominal volume.
– The RS 90 / 1 compact control unit is factory-installed on the primary tank.
– All electric and air connections between control unit and expansion tank are pre-installed.
• "RG" primary tank with a nominal volume from 800 litres.
– The RS 90 / 1 control unit as stand-alone console.
• The connection of "RF" secondary tanks to the primary tank is available as an option
