Controller
9.2.2

Messages

The display provides alarms in plain text and the ER codes shown in the list. Use the arrow buttons to scroll through multiple alarms
displayed at the same time, see chapter 9.1 "Operator panel" on page 38 .
The fault memory stores the last 20 alarms for review, see chapter 9.2 "Configuring settings in the controller" on page 39 .
Alarm causes can be eliminated by the operator or a specialist workshop. If this is not possible, contact the Reflex Customer Service.
Note!
Clearing of the cause must be confirmed by pressing the "Ack" button on the operator panel. All other alarms are
automatically reset as soon as the cause has been eliminated.
Note!
Floating contacts, setting in the Customer menu, see chapter 9.2 "Configuring settings in the controller" on page 39 .
ER Code Alarm
01 Minimum pressure
02.1 Insufficient water
03 High water
04.1 Compressor
44 — English
Floating Causes
contact
YES • Set value not reached.
• Water loss in the
system.
• Compressor fault.
• Controller in Manual
mode.
- • Set value not reached.
• Make-up disabled.
• Air in the system.
• Dirt trap clogged.
YES • Set value exceeded.
• Make-up disabled.
• Water intake through
a leak in a thermal
transfer medium of
the user.
• "RG" and "RG" tanks
too small.
YES • Compressor disabled.
• Fuse defective.
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Remedy
• Check set value in the
Customer or Service menu.
• Check water level.
• Check compressor.
• Set the controller to
Automatic mode.
• Check set value in the
Customer or Service menu.
• Clean the dirt trap.
• Check functioning of the
"PV1" solenoid valve.
• If necessary, manually add
water.
• Check set value in the
Customer or Service menu.
• Check functioning of the
"WV1" solenoid valve.
• Drain water from the "VG"
tank.
• Check user's thermal transfer
medium for leaks.
• Check set values in the
Customer or Service menu.
• Replace the fuse.
Alarm reset
"Quit"
-
-
"Quit"
