9.2.1

Default settings

The device controller is shipped with the following default settings. Use the Customer menu to adjust these values to local conditions. In
specific cases, it is possible to further adjust the values in the Service menu.
Customer menu
Parameter
Language
Minimum operating pressure "P
Next maintenance
Floating alarm contact
Make-up
Make-up "ON"
Make-up "OFF"
Maximum make-up quantity
Maximum make-up time
Maximum make-up cycles
Softening (Only if "With softening Yes")
Lock make-up
Hardness reduction
Maximum make-up quantity
Soft water capacity
Cartridge replacement
Service menu
Parameter
Pressurisation
Compressor "ON"
Compressor "OFF"
"Compressor run time exceeded" message
Overflow line "CLOSED"
Overflow line "OPEN"
Maximum pressure
Filling levels
Insufficient water "ON"
Insufficient water "OFF"
Solenoid valve in overflow line "CLOSED"
Setting
EN
" 1.8 bar
0
12 months
YES
8 %
12 %
0 Litres
30 minutes
6 cycles within 2 hours
No
8°dH
0 Litres
0 Litres
18 months
Setting
P + 0.3 bar
0
P + 0.4 bar
0
240 minutes
P + 0.4 bar
0
P + 0.5 bar
0
P + 3 bar
0
5 %
12 %
90 %
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Remarks
Display language.
see chapter 7.2 "Determining the P
pressure for the controller" on page 33 .
Time left to the next due maintenance.
see chapter 9.2.2 "Messages" on page 44 .
Only if make-up has been selected in the customer menu
with "With water meter Yes".
In the case of soft water residual capacity = 0
= Target – Actual
Replace cartridge.
Remarks
Differential pressured added to the "P
operating pressure.
Differential pressured added to the "P
operating pressure.
The message is displayed after the compressor runs for
240 minutes.
Differential pressured added to the "P
operating pressure.
Differential pressured added to the "P
operating pressure.
Differential pressured added to the "P
operating pressure.
Controller
minimum operating
0
" minimum
0
" minimum
0
" minimum
0
" minimum
0
" minimum
0
English — 43
