Reflex Reflexomat Compact RC Series Operating Manual page 30

Installation
Terminal
Signal
number
1 PE
2 N
3 L
4 PE
5N N
6 M1 M 1
7 Y2
8 N
9 PE
10 Y 1
11 N
12 PE
13 COM
14 NC
15 N.O.
16 Not assigned
17 Make-up (230 V)
18 Make-up (230 V)
19 PE shield
20 - Level (signal)
21 + Level (+ 18 V)
22 PE (shield)
23 - Pressure (signal)
24 + Pressure (+ 18 V)
25 0 – 10 V (correcting
variable)
26 0 – 10 V (feedback)
27 GND
28 + 24 V (supply)
29 A
30 B
31 GND
32 + 24 V (supply) E1
E1
33
E2
34
30 — English
230 V power supply via mains cable and plug.
Compressor for maintaining the pressure.
Overflow solenoid valve.
• For controlling pressure maintenance in the overflow line.
230 V output for make-up.
• To control a Reflex Fillcontrol, for example.
Group message (floating).
External make-up request.
• Not used with the Reflexomat.
Level analogue input.
• Display at the controller.
• Activation of the make-up.
Pressure analogue input.
• Display at the controller.
• Control of pressure maintenance.
Motor ball valve
• Not used with the Reflexomat.
RS-485 interface.
Supply for E1 and E2.
Contact water meter (in Fillset, for example), see chapter 4.6
"Optional equipment and accessories" on page 14 .
• Evaluation of the make-up.
– If contact 32/33 is closed = meter pulse.
Insufficient water switch.
• Not used with the Reflexomat.
– If contact 32/34 is closed = OK.
Reflexomat with Basic controller — 20.06.2017 - Rev. C
Function Wiring
Factory
Factory
Factory
User, optional
User, optional
---
Pre-wired, sensor plug
must be attached on-
site
Factory
---
User, optional
Factory
User, optional
---
