Commissioning
Callout Indicator
15
16 WARN
5 5
17 ALARM
Table 5.5 Legend to Figure 5.1, Indicator Lights (LEDs)
D. Operation keys and reset
Operation keys are located at the bottom of the LCP.
Callout
18 Hand On
19
20 Auto On
21
Table 5.6 Legend to Figure 5.1, Operation Keys and Reset
NOTICE!
The display contrast can be adjusted by pressing [Status]
▲ ▼
and [ ]/[ ] keys.

5.3.3 Parameter Settings

Establishing the correct programming for applications
often requires setting functions in several related
parameters.
Programming data are stored internally in the adjustable
frequency drive.
54
Light Function
ON Green The ON light activates when the
frequency converter receives
power from mains voltage, a DC
bus terminal, or an external 24 V
supply.
Yellow When a warning is issued, the
yellow WARN light comes on
and text appears in the display
area identifying the problem.
Red A fault condition causes the red
alarm light to flash and an alarm
text is displayed.
Key Function
Starts the frequency converter in local
control.
•
An external stop signal by control
input or serial communication
overrides the local hand on.
Off Stops the operation but does not remove
power to the frequency converter.
Puts the system in remote operational
mode.
•
Responds to an external start
command by control terminals or
serial communication.
Reset Resets the frequency converter or active
filter manually after a fault has been
cleared.
Danfoss A/S © 10/2015 All rights reserved.
®
VLT AQUA Drive FC 202 Low Harmonic Drive
•
•
•
5.3.4 Uploading/Downloading Data to/from
the LCP
1.
2.
3.
4.
5.

5.3.5 Changing Parameter Settings

Parameter settings can be accessed and changed from the
Quick Menu or from the Main Menu. The Quick Menu only
gives access to a limited number of parameters.
1.
2.
3.
4.
5.
6.
7.
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
•
For backup, upload data into the LCP memory
To download data to another adjustable
frequency drive, connect the LCP to that unit and
download the stored settings
Restoring factory default settings does not
change data stored in the LCP memory
Press [Off] to stop operation before uploading or
downloading data.
Press [Main Menu] parameter 0-50 LCP Copy and
press [OK].
Select [1] All to LCP to upload data to the LCP or
select [2] All from LCP to download data from the
LCP.
Press [OK]. A progress bar shows the uploading or
downloading progress.
Press [Hand On] or [Auto On] to return to normal
operation.
Press [Quick Menu] or [Main Menu] on the LCP.
▲ ▼
Press [ ] [ ] to browse through the parameter
groups, press [OK] to select a parameter group.
▲ ▼
Press [ ] [ ] to browse through the parameters,
press [OK] to select a parameter.
▲ ▼
Press [ ] [ ] to change the value of a parameter
setting.
Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
Press [OK] to accept the change.
Press either [Back] twice to enter Status, or press
[Main Menu] once to enter the Main Menu.
The list only shows parameters, which have been
changed in the current edit set-up.
Parameters, which have been reset to default
values, are not listed.
