Appendix A - Parameters
9.3.3 Digital In/Out 5-**
Par.
Parameter description
No. #
5-0* Digital I/O mode
5-00
Digital I/O Mode
5-01
Terminal 27 Mode
5-02
Terminal 29 Mode
5-1* Digital Inputs
5-10
Terminal 18 Digital Input
5-11
Terminal 19 Digital Input
5-12
Terminal 27 Digital Input
5-13
Terminal 29 Digital Input
5-14
Terminal 32 Digital Input
5-15
Terminal 33 Digital Input
5-16
Terminal X30/2 Digital Input
5-17
Terminal X30/3 Digital Input
5-18
Terminal X30/4 Digital Input
5-19
Terminal 37 Safe Stop
5-3* Digital Outputs
9
9
5-30
Terminal 27 Digital Output
5-31
Terminal 29 Digital Output
5-4* Relays
5-40
Function Relay
5-41
On Delay, Relay
5-42
Off Delay, Relay
108
®
VLT
AQUA Drive FC 202 Low Harmonic Drive
Default value
[0] PNP
[0] Input
[0] Input
[8] Start
[0] No operation
[0] No operation
[0] No operation
[90] AC Contactor
[91] DC Contactor
[0] No operation
[0] No operation
[0] No operation
[1] Safe Stop Alarm
[0] No operation
[0] No operation
[0] No operation
0.30 s
0.30 s
Danfoss A/S © 10/2015 All rights reserved.
4-set-up
Change
Conver-
during
sion index
operation
All set-ups
FALSE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
1 set-up
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
All set-ups
TRUE
Type
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-
Uint8
-2
Uint16
-2
Uint16
MG21B322
