Specifications

8.4.3 Supplementary Fuses - High Power

Supplementary fuses
Frame size
D, E and F
Table 8.10 SMPS Fuse
Size/Type
P132–P250, 380–500 V
P315–P630, 380–500 V
Table 8.11 Fan Fuses
Size/Type
P450–P630, 380–500 V 2.5–4.0 A
P450–P630, 380–500 V 4.0–6.3 A
P450–P630, 380–500 V 6.3–10 A
P450–P630, 380–500 V 10–16 A
Table 8.12 Manual Motor Controller Fuses
Frame size Bussmann PN*
F LPJ-30 SP or SPI
Table 8.13 30 A Fuse Protected Terminal Fuse
Frame size
F
Table 8.14 Control Transformer Fuse
Frame size
F
Table 8.15 NAMUR Fuse
Frame size
F
Table 8.16 Safety Relay Coil Fuse with PILS Relay
Frame size
D, E, F
Table 8.17 Electrical Fuses (Power Card)
MG21B322
Installation Manual
Bussmann PN
KTK-4
Bussmann PN
KTK-4
Bussmann PN
LPJ-6 SP or SPI
LPJ-10 SP or SPI
LPJ-15 SP or SPI
LPJ-25 SP or SPI
Rating
30 A, 600 V
Bussmann PN*
LPJ-6 SP or SPI
Bussmann PN*
GMC-800MA
Bussmann PN*
LP-CC-6
Littelfuse PN
KLK-15
Danfoss A/S © 10/2015 All rights reserved.
Littelfuse
KLK-15
Rating
6 A, 600 V
10 A, 600 V
15 A, 600 V
25 A, 600 V
Alternative Fuses
Any listed Class J dual element, time delay, 30 A
Rating
6 A, 600 V Any listed class J dual element, time delay, 6 A
Rating
6 A, 600 V
Rating
4 A, 600 V
Rating
4 A, 600 V
15 A, 600 V
Alternative Fuses
Any listed class J dual
element, time delay, 6A
Any listed class J dual
element, time delay, 10 A
Any listed class J dual
element, time delay, 15 A
Any listed class J dual
element, time delay, 25 A
Alternative Fuses
Rating
800 mA, 250 V
Alternative Fuses
Any listed class CC, 6 A
Rating
15 A, 600 V
