Commissioning

5.4.3 Commissioning via [Main Menu]

Recommended parameter settings are intended for start-
up and check-out purposes. Application settings may vary.
Enter data with power ON, but before operating the
adjustable frequency drive.
1. Press [Main Menu] on the LCP.
5 5
2. Press the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
Figure 5.2 Main Menu
3. Press the navigation keys to scroll to parameter
group 0-0* Basic Settings and press [OK].
Figure 5.3 Operation/Display
4. Press the navigation keys to scroll to
parameter 0-03 Regional Settings and press [OK].
Figure 5.4 Basic Settings
5. Press the navigation keys to select [0] Interna-
tional or [1] North America as appropriate and
56
®
VLT
1107 RPM 3.84 A
Main Menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
0.0% 0.00A
Operation / Display
0-0 Basic Settings
*
0-1 * Set-up Operations
0-2 LCP Display
*
0-3 * LCP Custom Readout
0.0% 0.00A
Basic Settings
0-03 Regional Settings
[0] International
Danfoss A/S © 10/2015 All rights reserved.
AQUA Drive FC 202 Low Harmonic Drive
press [OK]. (This changes the default settings for
a number of basic parameters).
6. Press [Main Menu] on the LCP.
7. Press the navigation keys to scroll to
parameter 0-01 Language.
8. Select the language and press [OK].
9. If a jumper wire is in place between control
terminals 12 and 27, leave
parameter 5-12 Terminal 27 Digital Input at factory
default. Otherwise, select No Operation in
parameter 5-12 Terminal 27 Digital Input. For
adjustable frequency drives with an optional
1 (1)
bypass, no jumper wire is required between
control terminals 12 and 27.
10. Make the application-specific settings in the
following parameters:
10a
10b
10c
10d
10e
1(1)

5.4.4 Asynchronous Motor Set-up

0-
**
Enter the following motor data. The information can be
found on the motor nameplate.
1. Parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP].
2. Parameter 1-22 Motor Voltage.
3. Parameter 1-23 Motor Frequency.
4. Parameter 1-24 Motor Current.
5. Parameter 1-25 Motor Nominal Speed.
1(1)
When running in flux mode, or for optimum performance
0-0
*
+
in VVC mode, extra motor data is required to set up the
following parameters. The data can be found in the motor
datasheet (this data is typically not available on the motor
nameplate). Run a complete AMA using
parameter 1-29 Automatic Motor Adaptation (AMA) [1]
Enable Complete AMA or enter the parameters manually.
Parameter 1-36 Iron Loss Resistance (Rfe) is always entered
manually.
Parameter 1-30 Stator Resistance (Rs).
1.
2. Parameter 1-31 Rotor Resistance (Rr).
3. Parameter 1-33 Stator Leakage Reactance (X1).
Parameter 3-02 Minimum Reference.
Parameter 3-03 Maximum Reference.
Parameter 3-41 Ramp 1 Ramp-up Time.
Parameter 3-42 Ramp 1 Ramp-down Time.
Parameter 3-13 Reference Site. Linked to
Hand/Auto Local Remote.
MG21B322
