Danfoss VLT AQUA Drive FC 202 Installation Manual page 12

Introduction
1 1
1 Local control panel (LCP)
2 Active filter card (AFC)
3 Metal oxide varistor (MOV)
4 Soft-charge resistors
5 AC capacitors discharge board
6 Line power contactor
7 LC inductor
8 AC capacitors
9 Line power bus bars to drive input
10 IGBT fuses
11 RFI
Figure 1.3 Frame Size D13 Filter Enclosure
8
®
VLT
1
2
22
21
19
18
16
15
14
Danfoss A/S © 10/2015 All rights reserved.
AQUA Drive FC 202 Low Harmonic Drive
3
4
20
5
17
13 Electrical fuses
14 Line power disconnect
15 Line Power Terminals
16 Heatsink fan
17 DC capacitor bank
18 Current transformer
19 RFI differential mode filter
20 RFI common mode filter
21 HI inductor
22 Power card
6
7
8
9
10
11
12
13
MG21B322
