PCI-2511 User's Guide

Environmental

Parameter
Operating temperature range
Storage temperature range
Relative humidity

Mechanical

Parameter
Vibration
Dimensions
Weight

Main connector and pinout

Parameter
Connector type
Compatible cables (for the 68-pin
SCSI connector)
Compatible accessory products
Table 10. Environmental specifications
Specification
0 °C to +60 °C
–40 °C to +80 °C
0 to 95% non-condensing
Table 11. Mechanical specifications
Specification
MIL STD 810E cat 1 and 10
165 mm W x 15 mm D x 108 mm H (6.5" x 0.6" x 4.2")
160 g (0.35 lbs)
Table 12. Main connector specifications
Specification
68-pin standard "SCSI TYPE III" female connector
HDMI connector (targeted for future expansion)
CA-68-3R — 68-pin ribbon cable; 3 feet.
CA-68-3S — 68-pin shielded round cable; 3 feet.
CA-68-6S — 68-pin shielded round cable; 6 feet.
TB-100 termination board with screw terminals
RM-TB-100, 19-inch rack mount kit for TB-100
34
Specifications
