Switch & Sense 8/8 User's Guide

USB connection

Captive pigtail cable
Length

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions
Case dimensions
Case material
Weight of complete unit
Weight of card alone

Screw terminal

Wire sizes

Miscellaneous

Case strain relief rating

Screw terminal pinouts

Pin Signal Name
IP0A Input 0 terminal A
IP0B Input 0 terminal B
IP1A Input 1 terminal A
IP1B Input 1 terminal B
IP2A Input 2 terminal A
IP2B Input 2 terminal B
IP3A Input 3 terminal A
IP3B Input 3 terminal B
0-NO Relay 0 Normally Open contact
0-C Relay 0 Common contact
0-NC Relay 0 Normally Closed contact
1-NO Relay 1 Normally Open contact
1-C Relay 1 Common contact
1-NC Relay 1 Normally Closed contact
2-NO Relay 2 Normally Open contact
2-C Relay 2 Common contact
2-NC Relay 2 Normally Closed contact
3-NO Relay 3 Normally Open contact
3-C Relay 3 Common contact
3-NC Relay 3 Normally Closed contact
USB Type A connector
2 meters
0 to 70 °C
-40 to 100 °C
0 to 95% non-condensing
165 mm long x 150 mm wide x 20 mm high, 6.5 in. long x 5.9
in. widex 0.8 in. high
185 mm long x 160 mm wide x 46 mm high, 7.3 in. long x 6.3
in. wide x 1.8 in. high
20 gage steel
2.1 lbs.
0.6 lbs.
12-22 AWG
20 lbs.
Pin Signal Name
IP4A Input 4 terminal A
IP4B Input 4 terminal B
IP5A Input 5 terminal A
IP5B Input 5 terminal B
IP6A Input 6 terminal A
IP6B Input 6 terminal B
IP7A Input 7 terminal A
IP7B Input 7 terminal B
4-NO Relay 4 Normally Open contact
4-C Relay 4 Common contact
4-NC Relay 4 Normally Closed contact
5-NO Relay 5 Normally Open contact
5-C Relay 5 Common contact
5-NC Relay 5 Normally Closed contact
6-NO Relay 6 Normally Open contact
6-C Relay 6 Common contact
6-NC Relay 6 Normally Closed contact
7-NO Relay 7 Normally Open contact
7-C Relay 7 Common contact
7-NC Relay 7 Normally Closed contact
16
Specifications
