PCI-2511 User's Guide
Pin Function
68 ACH0
67 AGND
66 ACH9
65 ACH2
64 AGND
63 ACH11
62 SGND (low level sense – not for general use)
61 ACH12
60 ACH5
59 AGND
58 ACH14
57 ACH7
56 NC
55 NC
54 NC
53 GND
52 A1
51 A3
50 A5
49 A7
48 B1
47 B3
46 B5
45 B7
44 C1
43 C3
42 C5
41 C7
40 GND
39 CNT1
38 CNT3
37 TMR1
36 GND
35 GND
Note 4: 5 V output, up to 500 mA.
Table 13. 16-channel single-ended pinout
Pin
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
35
Function
ACH8
ACH1
AGND
ACH10
ACH3
AGND
ACH4
AGND
ACH13
ACH6
AGND
ACH15
NC
NC
NC
+5 V (refer to Note 4)
A0
A2
A4
A6
B0
B2
B4
B6
C0
C2
C4
C6
TTL TRG
CNT0
CNT2
TMR0
XAPCR (input scan clock)
XDPCR (output scan clock)
