PCI-2511 User's Guide

Digital I/O

Twenty-four TTL-level digital I/O lines are included in each PCI-2511. You program digital I/O in 8-bit groups
as either inputs or outputs and can scan them in several modes (refer to
can access input ports asynchronously from the PC at any time, including when a scanned acquisition is
occurring.

Digital input scanning

Digital input ports can be read asynchronously before, during, or after an analog input scan.
Digital input ports can be part of the scan group and scanned along with analog input channels. Two
synchronous modes are supported when digital inputs are scanned along with analog inputs. In both modes,
adding digital input scans has no effect on the analog scan rate limitations. If no analog inputs are being
scanned, the digital inputs can sustain rates up to 4 MHz. Higher rates—up to 12 MHz—are possible depending
on the platform and the amount of data being transferred.

Digital outputs and pattern generation

Digital outputs can be updated asynchronously any time before, during, or after an acquisition. You can use two
of the 8-bit ports to generate a digital pattern at up to 4 MHz. The PCI-2511 supports digital pattern generation
with bus mastering DMA. The digital pattern can be read from PC RAM.
Higher rates—up to 12 MHz—are possible depending on the platform and the amount of data being transferred.
Digital pattern generation is clocked using an internal clock. The on-board programmable clock generates
updates ranging from once every 1 second to 1 MHz, independent of any acquisition rate.

Triggering

Triggering can be the most critical aspect of a data acquisition application. The PCI-2511 supports the
following trigger modes to accommodate certain measurement situations.

Hardware analog triggering

The PCI-2511 uses true analog triggering in which the trigger level you program sets an analog DAC, which is
then compared in hardware to the analog input level on the selected channel. This guarantees an analog trigger
latency that is less than 1 µs.
You can select any analog channel as the trigger channel, but the selected channel must be the first channel in
the scan. You can program the trigger level, the rising or falling edge, and hysteresis.
Hardware analog level trigger and the comparator change state
When analog input voltage starts near the trigger level, and you are performing a rising or falling hardware
analog level trigger, the analog level comparator may have already tripped before the sweep was enabled. If this
is the case, the circuit waits for the comparator to change state. However, since the comparator has already
changed state, the circuit does not see the transition.
Perform the following procedure to resolve this issue:
1. Set the analog level trigger to the threshold you want.
2. Apply an analog input signal that is more than 2.5% of the full-scale range away from the desired
threshold. This ensures that the comparator is in the proper state at the beginning of the acquisition.
3. Bring the analog input signal toward the desired threshold. When the input signal is at the threshold
(± some tolerance) the sweep will be triggered.
4. Before re-arming the trigger, move the analog input signal to a level that is more than 2.5% of the full-scale
range away from the desired threshold.
For example, if you are using the ±2 V full-scale range (gain = 5), and you want to trigger at +1 V on the rising
edge, you would set the analog input voltage to a start value that is less than +0.9 V (1 V – (2 V * 2 * 2.5%)).
"Digital input
12
Functional Details
scanning" below). You
