PCM-QUAD02 User's Guide

Interrupt controller

Controller type
Configuration
Interrupts
Interrupt enable
Interrupt sources

Environmental

Operating temperature range
Storage temperature range
Humidity

Pin out

Table 4. Interrupt Controller specifications
FPGA
Polled mode only
2 - 15
Programmable
All Carry/Borrow outputs from LS7266R1, all Index inputs
Table 5. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 90% non-condensing
AMP 15 position I/O connector
Pin # Function
1 Phase 1A+
2 Phase 1A–
3 Phase 1B+
4 Phase 1B–
5 Index 1+
6 Index 1–
7 Ground
8 +5 VDC
14
Pin # Function
9 +5 VDC
10 Phase 2A+
11 Phase 2A–
12 Phase 2B+
13 Phase 2B–
14 Index 2+
15 Index 2–
16
Specifications
