MAX30001G Evaluation Kit
MAX30001G_EVSYS_EVKIT Bill of Materials
ITEM REF_DES DNI/DNP
1V8, 3V3, BB_SEL, GND1,
GND2, J_CSB, J_EXT_PWR,
1
J_INT2B, J_INTB,
J_SCLK, J_SDI, J_SDO, J_SYS
AGND, AGND1-AGND4,
AOUT, BB, BIN, BIP,
BUFF1_OUT, CSB,
2 DRVN, DRVP, ECGN, ECGP,
FCLK, FTHR_GND, INT2B,
INTB, RBIAS, SCLK, SDI,
SDO, VBG, VCM, VREF
AVDD, DVDD,
3
EXT_PWR, OVDD
BP_BN, BUFF1_IN, DN_BN,
DP_BP, EN_BN, EN_UNBAL,
EP_BP, EP_EN, EP_UNBAL,
J_AVDD, J_BIN, J_BIP, J_DRVN,
4
J_DRVP, J_DVDD, J_ECGN,
J_ECGP, J_OVDD, J_RBIAS,
ONBRD_FCLK, P_DOWN,
P_UP, RN, RP, XTL_PWR
5 C1, C2
6 C3, C30
7 C4
8 C5-C7, C16-C21, C23
9 C9, C10, C14, C15
10 C11-C13, C22
11 C27, C31
12 C32
C_BB, C_BIN, C_BIP, C_DRVN,
13
C_DRVP, C_ECGN, C_ECGP
14 D1
15 J8
16 J9
www.analog.com
QTY MFG PART #
— 13 PCC03SAAN
— 26 5011
— 4 5010
— 25 5-146280-2
— 2 C0805C473J3GACTU
— 2 C0805C224J3RAC
UMK107AB7105KA;
— 1
CC0603KRX7R9BB105
— 10 GRM188R61E106MA73
— 4 C3216X7R1H335M160AC
— 4 C1608X7R1E104K080AA
— 2 KRM31KR72A225KH01
C0603C102J5GAC;
— 1
06035A102JAT2A
— 7 41828-50
— 1 LTST-C194KGKT
— 1 PPPC161LFBN-RC
— 1 PPPC121LFBN-RC
MANUFACTURER VALUE
SULLINS PCC03SAAN
KEYSTONE N/A
KEYSTONE N/A
TE CONNECTIVITY 5-146280-2
KEMET 0.047UF
KEMET 0.22UF
TAIYO YUDEN;YAGEO 1UF
MURATA 10UF
TDK 3.3UF
TDK 0.1UF
MURATA 2.2UF
KEMET;AVX 1000PF
PLASTICS ONE 41828-50
LITE-ON
LTST-C194KGKT
ELECTRONICS INC
SULLINS
PPPC161LFBN-RC
ELECTRONICS CORP.
SULLINS
PPPC121LFBN-RC
ELECTRONICS CORP
Evaluates: MAX30001G
DESCRIPTION
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY;
STRAIGHT THROUGH; 3PINS; -65 DEGC TO +125 DEGC
TEST POINT; PIN DIA=0.125IN; TOTAL LENGTH=0.445IN;
BOARD HOLE=0.063IN; BLACK; PHOSPHOR BRONZE
WIRE SILVER PLATE FINISH;
TESTPOINT WITH 1.80MM HOLE DIA, RED, MULTIPURPOSE;
CONNECTOR; MALE; THROUGH HOLE; HEADER
ASSEMBLY; MOD II; BREAKWAY; SINGLE ROW;
HIGH TEMPERATURE; VERTICAL W/ 0.025 SQ POST;
0.100 C; STRAIGHT; 2PINS
CAP; SMT (0805); 0.047UF; 5%; 25V; C0G; CERAMIC
CAP; SMT (0805); 0.22UF; 5%; 25V; X7R; CERAMIC
CAP; SMT (0603); 1UF; 10%; 50V; X7R; CERAMIC
CAPACITOR; SMT (0603); CERAMIC; 10UF; 25V; TOL=20%;
TG=-55 DEGC TO +85 DEGC; TC=X5R; GRM SERIES;
MURATA;
CAP; SMT (1206); 3.3UF; 20%; 50V; X7R; CERAMIC;
CAPACITOR; SMT (0603); CERAMIC; 0.1UF; 25V; TOL=10%;
MODEL=C SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R;
CAP; SMT (1206); 2.2UF; 10%; 100V; X7R; CERAMIC
CAP; SMT (0603); 1000PF; 5%; 50V; C0G; CERAMIC;
CONNECTOR; FEMALE; THROUGH HOLE; JACK; PCB;
1.5MM; TOUCHPROOF WAVE SOLDER VERSION WITH
STAMPING; RIGHT ANGLE; 3PINS
DIODE; LED; SMD CHIP LED; WATER CLEAR LENS;
AlInGaP GREEN; GREEN; SMT (0603); VF=2.1V; IF=0.02A
CONNECTOR; FEMALE; THROUGH HOLE; LFB SERIES;
2.54MM CONTACT CENTER; STRAIGHT; 16PINS
CONNECTOR; FEMALE; THROUGH HOLE;
HEADER FEMALE; STRAIGHT; 12PINS
