User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 8.

Reference Designator Description

10 μF ceramic capacitor, 10 V, 20%, X5R, 0603, low effective series

resistance (ESR)

C6, C7

1 μF ceramic capacitors, 16 V, 10%, X7R, 0603

DS1

630 nm light emitting diode (LED), surface-mount device (SMD), red

EXT_VCP, J1 to J4

PCB connectors, Subminiature Version B (SMB), coaxial straight jack

PCB connector, USB connector USB Type C

JP7, K1 to K4, P1 to P6 PCB connectors, 3-position, male header, unshrouded single row, 2.54

mm pitch, 3 mm solder tail

2-pin terminal block (5 mm pitch)

120-way, 0.6 mm pitch, 2 row straight PCB connector

R1 to R6

10 kΩ resistors, SMD, 0.01%, 1/16 W, 0603

R7, R9

100 kΩ resistors, SMD, 1%, 1/10 W, 0603

100 kΩ resistor, SMD, 1%, 1/10 W, 0603, do not insert (DNI)

R11

750 Ω resistor, SMD, 1%, 1/10 W, 0603, AEC-Q200

R10, R12

5.1 kΩ resistors, SMD, 0.1%, 1/10 W, 0603, AEC-Q200

RF1 to RF4, RFC,

Coaxial connectors, Subminiature Version A (SMA) right angle jack PCB Southwest Microwave 32K243-40ML5

RFC1, RFC2

IC, 32 kb serial EEPROM

IC, 50 mA, high voltage, micropower linear regulator

IC, 0 Hz to 18 GHz, SP4T MEMS switch

Not applicable

Wideband 50 Ω termination SMA loads

Screwed on at measurement time (see

ESD Caution

ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary

protection circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of

functionality.

Legal Terms and Conditions

By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the "Evaluation Board"), you are agreeing to be bound by the terms and

conditions set forth below ("Agreement") unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the

Evaluation Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you

("Customer") and Analog Devices, Inc. ("ADI"), with its principal place of business at Subject to the terms and conditions of the Agreement, ADI hereby grants to Customer a free, limited, personal,

temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and agrees that the Evaluation

Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted is expressly made

subject to the following additional limitations: Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board; and (ii) permit any Third Party to access

the Evaluation Board. As used herein, the term "Third Party" includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is NOT sold

to Customer; all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all be

considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation

of use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble,

decompile or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including

but not limited to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but

not limited to the RoHS Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board

at that time. LIMITATION OF LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED "AS IS" AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY

KIND WITH RESPECT TO IT. ADI SPECIFICALLY DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE

EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF

INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING

FROM CUSTOMER'S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL.

ADI'S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or

indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States federal laws and regulations relating to exports. GOVERNING LAW. This Agreement

shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts (excluding conflict of law rules). Any legal action regarding this Agreement will

be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits to the personal jurisdiction and venue of such courts. The United Nations

Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.

Figure

7).

registered trademarks are the property of their respective owners.

One Analog Way, Wilmington, MA 01887-2356, U.S.A.

EVAL-ADGM1144

Manufacturer

Manufacturer Number

TDK

C1608X5R1A106M080AC

AVX

0603YC105KAT2A
