Evaluation board for adgs1412 serially controlled, 1.5 ω on resistance, high voltage, quad spst switch

Advertisement

Quick Links

One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Evaluation Board for

FEATURES

SPI interface with error detection
Includes CRC, invalid read/write address, and SCLK count
error detection
Analog supply voltages
Dual-supply: ±4.5 V to ±16.5 V
Single-supply: 5 V to 20 V
PC control in conjunction with the evaluation software
EVAL-SDP-CB1Z
system demonstration platform (SDP)

PACKAGE CONTENTS

EVAL-ADGS1412SDZ

DOCUMENTS NEEDED

ADGS1412
data sheet

EQUIPMENT NEEDED

EVAL-SDP-CB1Z
controller board
ACE
software with
EVAL-ADGS1412SDZ
DC voltage source
±16.5 V for dual-supply
20 V for single-supply
Optional digital logic supply: 3.3 V
Analog signal source
Method to measure voltage, such as a digital multimeter (DMM)
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
ADGS1412
Serially Controlled, 1.5 Ω On Resistance, High
Voltage, Quad SPST Switch
plug-in
Rev. 0 | Page 1 of 12
EVAL-ADGS1412SDZ User Guide

GENERAL DESCRIPTION

The
EVAL-ADGS1412SDZ
ADGS1412. The
ADGS1412
single-throw (SPST) switch controlled by a serial peripheral
interface (SPI). The SPI has robust error detection features. These
are cyclic redundancy check (CRC) error detection, invalid
read/write address detection, and serial clock (SCLK) count
error detection. It is possible to daisy-chain multiple
devices together. This enables the configuration of multiple devices
with a minimal amount of digital lines. The
supports burst mode that decreases the time between SPI
commands.
Figure 1 shows the
EVAL-ADGS1412SDZ
setup. The
EVAL-ADGS1412SDZ
connects to a PC via a USB port. The
the evaluation board and wire screw terminals are provided to
connect to each of the source and drain pins. Three screw terminals
power the device and a fourth terminal provides users with a
defined digital logic supply voltage, if required. Alternatively, the
digital logic supply voltage can be supplied from the SDP.
Full specifications on the
ADGS1412
data sheet available from Analog Devices, Inc., and
should be consulted in conjunction with this user guide when
using the evaluation board.
The evaluation board interfaces to the USB port of a PC via the
SDP board. The
EVAL-SDP-CB1Z
board) is available to order on the Analog Devices website at
www.analog.com.
UG-1067
is the evaluation board for the
is an iCMOS, quad single-pole,
ADGS1412
ADGS1412
also
in a typical evaluation
is controlled by the SDP which
ADGS1412
is on the center of
ADGS1412
are available in the
board (SDP-B controller
