One Technology Way • P.O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
Advantiv
FEATURES
5 HDMI inputs, 2 HDMI outputs
PC communication via RS-232
ADSP-21487
or
ADSP-21489
EVALUATION BOARD KIT CONTENTS
EVAL-ADV7625-SMZ
Advantiv video evaluation board
ADDITIONAL EQUIPMENT/SOFTWARE NEEDED
Computer with RS-232 I/O for
Sending commands to the repeater software and viewing
software output of the board
Controlling the board via Advantiv video evaluation
software (AVES3 or newer) application
Updating the firmware of the board (if desired or necessary)
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
EVAL-ADV7625-SMZ
for audio processing
PHOTOGRAPH OF EVALUATION BOARD
Figure 1.
EVAL-ADV7625-SMZ
EVAL-ADV7625-SMZ User Guide
Video Evaluation Board
GENERAL DESCRIPTION
The
EVAL-ADV7625-SMZ
(AVEB) is a low cost solution for evaluating the performance of
the
ADV7625
HDMI® transceiver.
The evaluation board uses a Blackfin®
system control and includes software (firmware) that provides a
serial command interface to control the functionality of the board.
This evaluation board is available in one option:
•
With High Bandwidth Digital Content Protection (HDCP)
support (EVAL-ADV7625-SMZ), available only to
licensees of HDCP.
Advantiv Video Evaluation Board
Rev. 0 | Page 1 of 12
UG-603
Advantiv® video evaluation board
ADSP-BF524
processor for
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Analog Devices EVAL-ADV7625-SMZ
Summary of Contents for Analog Devices EVAL-ADV7625-SMZ
-
Page 1: Features
Computer with RS-232 I/O for • With High Bandwidth Digital Content Protection (HDCP) Sending commands to the repeater software and viewing support (EVAL-ADV7625-SMZ), available only to software output of the board licensees of HDCP. Controlling the board via Advantiv video evaluation... -
Page 2: Table Of Contents
UG-603 EVAL-ADV7625-SMZ User Guide TABLE OF CONTENTS Features ....................1 Evaluation Board Hardware .............4 Evaluation Board Kit Contents ............1 Configuring the Evaluation Board ..........6 Additional Equipment/Software Needed ........1 Upgrading the Software Driver ............7 General Description ................. 1 Using U-Boot .................7 Photograph of Evaluation Board ............ -
Page 3: Terminology
EVAL-ADV7625-SMZ User Guide UG-603 TERMINOLOGY Source Software driver A source outputs digital audio/video over a DVI/HDMI Within this user guide, this term refers to the software that runs interface. This can be a DVD/Blu-ray player, set-top box, game on the... -
Page 4: Evaluation Board Hardware
UG-603 EVAL-ADV7625-SMZ User Guide EVALUATION BOARD HARDWARE A block diagram of the EVAL-ADV7625-SMZ is shown in Figure 2, and the most frequently used connectors are shown in Figure 3. For more information about evaluation board hardware components, see Table 1. - Page 5 EVAL-ADV7625-SMZ User Guide UG-603 ADSP-BF524 RS-232 ADSP-BF524 JTAG Figure 3. Photograph of Board with Most Frequently Used Connectors Labeled Table 1. Evaluation Board Hardware Components Reference Designator Function Description Power connector J12 is where the 5 V, 3.6 A power supply is connected.
-
Page 6: Configuring The Evaluation Board
Registers can still be read/written an Analog Devices sales representative, ask your sales contact from the command line, but anything that is written to a about the AVES3 software and the AVES3 folder. -
Page 7: Upgrading The Software Driver
EVAL-ADV7625-SMZ User Guide UG-603 UPGRADING THE SOFTWARE DRIVER You should see the following: The software driver on the evaluation board can be updated using the U-Boot bootloader that comes with the evaluation SF: Detected M25P80 with page size 256, board. However, it is preferable to purchase VisualDSP++® 5.0... -
Page 8: Evaluation Board Artwork
UG-603 EVAL-ADV7625-SMZ User Guide EVALUATION BOARD ARTWORK Figure 4. Assembly Drawing (Top Side) of the EVAL-ADV7625-SMZ Rev. 0 | Page 8 of 12... -
Page 9: Related Links
Product Page: Dual Port, Xpressview, 225 MHz HDMI Receiver ADSP-BF524 Product Page: Low Power Blackfin Processor with Advanced Peripherals and Low Standby Power HPUSB-ICE Product Page: USB-Based Emulator and High Performance USB-Based Emulator ICE-100B Product Page: Analog Devices Blackfin Emulator Rev. 0 | Page 9 of 12... - Page 10 UG-603 EVAL-ADV7625-SMZ User Guide NOTES Rev. 0 | Page 10 of 12...
- Page 11 EVAL-ADV7625-SMZ User Guide UG-603 NOTES Rev. 0 | Page 11 of 12...
- Page 12 By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation Board until you have read and agreed to the Agreement.
